Sta-Kon NW14-12 NON-INS HITEMP RING TERM 16-14 No12

The NW14-12 is sized for 16 to 14 AWG stranded conductors. Anything thinner than 16 AWG won't get a reliable grip in the barrel, and 12 AWG won't seat. For 12-10 AWG runs you need the next barrel size up in the same non-insulated ring family.

The ring is a No. 12 stud size, so it drops over a #12 screw or stud. It will also pass over a #10 or smaller stud, but on anything undersized add a washer so the ring can't shift off the contact face.

That's exactly what the NW14-12 is built for. It's a high temperature, non-insulated nickel alloy ring terminal, so there's no plastic or nylon sleeve to soften or char near a heating element, motor lead, or oven. Because the barrel is bare metal, the connection has no built-in insulation, so sleeve it with high temp fiberglass or ceramic beading if the terminal sits where it could touch another conductor or a grounded surface.

Yes. The terminal carries a 600 V rating, which covers 120/208, 277 and 480 V control and motor work. The rating is on the terminal itself, so the limiting factor becomes the insulation rating of the wire you crimp into it.

Pick by temperature and by whether you need a solder or heat-shrink finish. The NW14-12 is non-insulated nickel alloy and rated for high temperature service, so it belongs on appliance, heater, oven and motor leads where a vinyl or nylon sleeve would break down. A vinyl insulated ring is the better choice for ordinary panel and automotive work at room temperature, because the sleeve gives you strain relief and shock protection out of the box.

It needs a non-insulated crimp die, not the color-coded nests used for vinyl terminals. The barrel is bare nickel alloy, so it takes an indenter or oval die sized for 16-14 AWG non-insulated barrels. A nylon or vinyl nest will over-form the bare barrel and leave a loose crimp.

A ring terminal has to be fully unscrewed to come off, so it cannot vibrate loose off the stud the way a fork can. That makes the NW14-12 the right call on motor terminal boards, grounding studs and any high vibration equipment. Use a fork or spade only where you need to pull leads without backing the screw all the way out.

Country of origin on the NW14-12 ring terminal is the United States, which is what institutional and government buyers working to a domestic-content line item need on the submittal.
