Panduit LCA2-38-Q Pan-Lug™ LCA2-38-Q Comp. Lug, Tin Plt Copper, Strt, One 3/8" Stud, PK25

Panduit LCA2-38-Q Pan-Lug Compression Lug, 2 AWG Tin-Plated Copper, 3/8" Stud

(No reviews yet) Write a Review

Model: LCA2-38-Q

In Stock (leaves warehouse same day if ordered before 3pm ET)

$55.81
$5.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit LCA2-38-Q Pan-Lug Compression Lug, 2 AWG Tin-Plated Copper, 3/8" Stud

The Panduit Pan-Lug™ compression lug delivers professional-grade electrical termination for 2 AWG copper conductors. Built with tin-plated copper construction, a straight tongue design, and a single 3/8" stud hole, this UL Listed lug features a beveled barrel entry for secure connections rated up to 35 kV. Each package contains 25 pieces (Std Pkg Qty: 25), making it an efficient choice for industrial and commercial termination projects.

Key Features

  • 2 AWG Copper Conductor Compatibility: Precisely engineered for reliable termination of 2 AWG copper conductors with proper compression connection.
  • Durable Construction: Tin-plated copper base material provides excellent corrosion resistance and enhanced conductivity for long-term electrical performance.
  • 3/8" Stud Hole: Single stud hole (9.5 mm) with straight tongue and standard tongue type for secure mechanical connection.
  • 35 kV Maximum Voltage Rating: Supports high-voltage applications with professional-grade construction.
  • Beveled Barrel Entry Design: Facilitates smooth conductor insertion and proper seating for consistent compression results.
  • Inspection Window: Allows visual verification of proper conductor insertion before compression for quality assurance.
  • 90°C Temperature Rating: UL and CSA temperature rating of 90°C for demanding thermal conditions.
  • Finish: Tin-Plated coating for enhanced corrosion resistance.

Certifications & Compliance

  • UL Listed
  • RoHS Compliant
  • ARRA Compliant

Technical Specifications

  • Any Reason Not To Sell: N
  • Arra Compliant: Y
  • Burndy Die Index Number: 10
  • California Pro65 Cancer: No
  • Copper Code Conductor Size Awg: 2
  • Csa Temperature Rating C: 90
  • Hazardous Material Flag: N
  • Inspection Window: Yes
  • Lead Content Indicator: N
  • Maximum Voltage Kv: 35
  • Mercury Content Indicator: N
  • Min Order Qty: 1
  • Number Of Stud Holes: 1
  • Overall Length Mm: 50
  • Panduit Die Index Number: P33
  • Product Segment: IEI
  • Reach Status: N
  • Restricted Use Of Hazardous Substances: N
  • Std Pkg Qty: 25
  • Stud Hole Size Mm: 9.5
  • Stud Hole Spacing Mm: 0
  • Sub Brand: Pan-Lug™
  • T B Die Index Number: 33
  • Tongue Thickness In: 0.1
  • Tongue Thickness Mm: 2.5
  • Ul Temperature Rating C: 90
  • Uom Ea Pk: PK

Typical Applications

  • Industrial Power Distribution Systems
  • Commercial Electrical Installations
  • High-Voltage Equipment Terminations
  • Electrical Panel and Switchgear Connections
  • Motor Control Centers
  • Utility and Infrastructure Projects

Why Panduit?

Panduit Pan-Lug™ compression lugs deliver proven reliability with UL Listed certification and RoHS compliant construction. The tin-plated copper material and 90°C temperature rating ensure long-term performance in demanding electrical applications, giving professionals confidence in every termination.

Manufacturer Resources

Product Specs

Any Reason Not to Sell:
N
Arra Compliant:
Y
Barrel Entry:
Beveled
Barrel Length In:
0.88
Barrel Length (mm):
22.4
Barrel Type:
Standard
Base Material:
Copper
Burndy Die Index Number:
10
California Pro65 Cancer:
No
Color Code:
Brown
Copper Code Conductor Size Awg:
2
Ean:
74983900176
GTIN Package:
74983900176
Hazardous Material Flag:
N
Inspection Window:
Yes
Lead Content Indicator:
N
Mercury Content Indicator:
N
Min Order Qty:
1
Number of Stud Holes:
1
Overall Length (In.):
1.97
Overall Length (mm):
50
Pallet Quantity:
0
Pallet Volume:
0
Pallet Weight:
0
Panduit Die Index Number:
P33
Product Segment:
IEI
Product Type:
Compression Lug
REACH Status:
N
Restricted Use of Hazardous Substances:
N
Rohs Compliant:
Compliant
Standard Carton Volume Ft3:
0
Standard Carton Weight Pounds:
0
Standard Package Volume Ft3:
0.0328
Standard Package Weight Pounds:
1.01
Std Ctn Qty:
0
Std Package Height In:
3.35
Std Package Height MM:
85.09
Std Package Length In:
4.75
Std Package Length MM:
120.65
Std Package Width In:
3.35
Std Package Width MM:
85.09
Sub Brand:
Pan-Lug™
T & B Die Index Number:
33
Tongue Angle:
Straight
Tongue Thickness (In.):
0.1
Tongue Thickness (mm):
2.5
Tongue Type:
Standard
Tongue Width In:
0.66
Tongue Width Mm:
16.8
UOM EA PK:
PK
Wire Strip Length (In.):
15/16
Wire Strip Length Mm:
23.6
Department:
Electrical
Product Group:
Wire Connectors & Terminals
Product Subgroup:
Lugs & Terminals
UL Temperature Rating (°C):
90
Std. Pkg. Qty.:
25
Stud Hole Size (In.):
3/8
Finish/Coating:
Tin-Plated
CSA Temperature Rating (°C):
90
Std. Pkg. UOM:
Piece
Maximum Voltage (kV):
35
Stud Hole Size (mm):
9.5
Min. Order UOM:
Piece
Stud Hole Spacing (mm):
0

Panduit LCA2-38-Q – Frequently Asked Questions

1) What die index do I set my crimper to for the Panduit LCA2-38-Q lug?
The LCA2-38-Q crimps with Panduit die index P33. If you're running other brands of tooling, the cross-reference on the lug is Burndy die index 10 and T&B die index 33. Match the die to the tool you have in the truck rather than guessing by conductor size.
2) Can I use this lug on aluminum conductor?
No. The LCA2-38-Q is a copper-bodied, tin-plated lug coded for 2 AWG copper conductor. Use a dual-rated AL9CU or an aluminum-bodied compression lug for aluminum feeders. The tin plating here is for corrosion resistance on the copper body, not an aluminum rating.
3) Can the Burndy YA31L be used in place of the Panduit LCA2-38-Q compression lug?
No - they terminate very different conductors. The Panduit LCA2-38-Q is sized for 2 AWG copper and has one 3/8 inch stud hole. The Burndy YA31L Hylug is a 350 kcmil copper one-hole lug with a 1/2 inch stud hole, so it will neither grip a 2 AWG conductor nor land on a 3/8 inch stud. Match the lug to the conductor size and the stud diameter at the bus or pad.
4) What is the temperature rating on the Panduit Pan-Lug LCA2-38-Q, and is it good for 90C conductor?
Rated 90 C by both UL and CSA, so it will not derate a 90 C insulated conductor such as THHN or XHHW at the termination. Maximum voltage is 35 kV, which covers low-voltage gear and medium-voltage terminations alike.
5) Is this compression lug RoHS and Buy American (ARRA) compliant for a government or institutional job?
The Pan-Lug LCA2-38-Q is UL Listed, RoHS compliant, and flagged ARRA compliant. It carries no lead or mercury content indicators and no Prop 65 cancer listing. Country of origin is Mexico, which is the detail a federal procurement officer will want on the submittal.
6) My crimper die chart is set up for Burndy and Thomas & Betts tooling - will it work on the Panduit LCA2-38-Q?
Yes. The Panduit LCA2-38-Q crimps with Panduit die index P33, Burndy die index 10, and Thomas & Betts die index 33, so a shop already tooled for Burndy Hylug-style terminations such as the YA31L can compress this lug without buying a new die set - just select the index that matches the 2 AWG barrel.
7) What makes the Panduit LCA2-38-Q different from a plain Burndy Hylug barrel lug for inspection purposes?
The Panduit LCA2-38-Q Pan-Lug has an inspection window in the barrel plus a beveled barrel entry, so you can visually confirm the 2 AWG conductor is fully seated before you crimp, and it carries a 15/16 inch strip length. The Burndy YA31L is a Hylug series 350 kcmil copper one-hole lug - a different size class for larger feeders rather than a like-for-like alternative.
8) How many lugs come in a pack of Panduit LCA2-38-Q, and can I buy just one?
Standard package is 25 pieces. Minimum order is 1, so you are not forced into multiple packs for a small job.
9) What color code identifies the die group on this 2 AWG Panduit lug?
Brown is the color code for this one. On a panel where several conductor sizes are being terminated, the brown marking is the quick field check that the crew grabbed the 2 AWG lug and not an adjacent size before they set the P33 die.
