Panduit Pan-Lug LCD3/0-38D-X C...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$2,077.14
Panduit Pan-Lug LCD3/0-38D-X Copper Two-Hole Compression Lug, 3/0 AWG

Panduit Pan-Lug LCD3/0-38D-X Copper Two-Hole Compression Lug, 3/0 AWG

(No reviews yet) Write a Review

Model: LCD3/0-38D-X

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,077.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit Pan-Lug™ LCD3/0-38D-X Copper Two-Hole Compression Lug, 3/0 AWG

The Panduit Pan-Lug™ LCD3/0-38D-X is a two-hole, standard barrel copper compression connector engineered for 3/0 AWG copper conductors. It features a 3/8" stud hole with 1" stud hole spacing, a beveled barrel entry, and an inspection window for verified wire seating. Built from tin-plated copper and rated to a maximum of 35kV, this lug is CSA certified and UL Listed for demanding industrial and commercial power connections.

Key Features

  • Wire Size & Stud Hole: Sized for 3/0 AWG copper conductors with a 3/8" stud hole and 1" stud hole spacing for secure two-hole mounting.
  • Durable Construction: Copper base material with a tin-plated finish for reliable conductivity and corrosion resistance.
  • Two-Hole Standard Barrel Design: Beveled barrel entry simplifies conductor insertion, while the inspection window lets installers visually confirm full wire seating before crimping.
  • Barrel Dimensions: 1.14" barrel length (29 mm) sized for a 1-3/16" wire strip length, ensuring a proper compression connection.
  • Voltage Rating: Rated to a maximum of 35kV, suitable for medium-voltage power distribution applications.
  • Temperature Rating: CSA and UL temperature rating of 90°C for reliable performance under electrical load.
  • Finish: Tin-plated copper construction for enhanced corrosion resistance in demanding environments.

Certifications & Compliance

  • CSA Certified to C22.2 No. 65-13
  • UL Listed to 486A-486B, File #E52164
  • NEBS Level 3 Compliant

Technical Specifications

  • CSA Temperature Rating (°C): 90
  • Inspection Window: Yes
  • Lead Content Indicator: N
  • Mercury Content Indicator: N
  • Stud Hole Spacing (In.): 1
  • Stud Hole Size (mm): 9.5
  • Tongue Thickness (mm): 3.4
  • Product Segment: IEI
  • T & B Die Index Number: 50
  • UOM EA PK: PK
  • Barrel Length (mm): 29
  • Std Package Width In: 3.4
  • Any Reason Not to Sell: N
  • REACH Status: N
  • California Pro65 Cancer: No
  • Std Package Length In: 4.7
  • Maximum Voltage (kV): 35
  • Overall Length (mm): 84.6
  • UL Temperature Rating (°C): 90
  • Country of Origin: Mexico
  • Std Ctn Qty: 0
  • Stud Hole Size (In.): 3/8
  • Product Type: Compression Lug
  • Std Package Width MM: 86.36
  • Pallet Quantity: 0
  • Std Package Height In: 3.4

Typical Applications

  • Industrial and Commercial Power Distribution
  • Medium-Voltage Cable Terminations
  • Panelboard and Switchgear Connections
  • Grounding and Bonding of Copper Conductors
  • Utility and Data Center Power Installations

Why Panduit?

Panduit's Pan-Lug™ compression connectors are manufactured from copper for maximum conductivity and finished with tin plating that protects against corrosion in demanding environments. With CSA certification, UL Listing, and NEBS Level 3 compliance, the LCD3/0-38D-X delivers the code-compliant, dependable performance electrical professionals require for critical power connections.

Manufacturer Resources

Product Specs

Barrel Length (In.):
1.14
Standard Package Volume Ft3:
0.0312
Standard Package Weight Pounds:
1.3000
Std. Pkg. UOM:
Piece
Tongue Thickness (In.):
0.13
CSA Temperature Rating (°C):
90
Barrel Entry:
Beveled
Inspection Window:
Yes
Standard Carton Volume Ft3:
0.0000
Color Code:
Orange
Lead Content Indicator:
N
Mercury Content Indicator:
N
Std Package Length MM:
119.38
Sub Brand:
Pan-Lug™
Stud Hole Spacing (In.):
1
Wire Strip Length (In.):
1-3/16
Stud Hole Size (mm):
9.5
Tongue Thickness (mm):
3.4
Product Segment:
IEI
Standard Carton Weight Pounds:
0.0000
Min Order Qty:
1.0000
GTIN Package:
00074983383290
T & B Die Index Number:
50
UOM EA PK:
PK
Barrel Length (mm):
29
Pallet Volume:
0.000000
Std Package Width In:
3.4
Any Reason Not to Sell:
N
Barrel Type:
Standard
Stud Hole Spacing (mm):
25.4
Tongue Width (In.):
0.96
Copper Conductor Size:
3/0 AWG
Tongue Angle:
Straight
REACH Status:
N
Base Material:
Copper
California Pro65 Cancer:
No
Std Package Length In:
4.7
Maximum Voltage (kV):
35
Finish/Coating:
Tin-Plated
Overall Length (mm):
84.6
UL Temperature Rating (°C):
90
Country of Origin:
Mexico
Std Ctn Qty:
0
Stud Hole Size (In.):
3/8
Product Type:
Compression Lug
Std Package Width MM:
86.36
Pallet Quantity:
0
Std Package Height In:
3.4
Department:
Electrical
Product Group:
Wiring Devices
Pack Size:
100
