Pemko 2903 Series Heavy Duty Fire-Rated Perimeter Gasketing 36"; x 84"; with Eco-V Insert

Pemko 2903 Series Heavy Duty Fire-Rated Perimeter Gasketing 36" x 84" with Eco-V Insert

(No reviews yet) Write a Review

Model: 2903AV 84
$76.88
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$76.88
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 2903 Series Heavy Duty Fire-Rated Perimeter Gasketing 36"; x 84"; with Eco-V Insert

Professional Fire-Rated Door Sealing Solution

The Pemko 2903 Series Heavy Duty Perimeter Gasketing provides professional-grade door sealing with UL 10C fire rating certification. This 36"; x 84"; aluminum gasket features an Eco-V insert and 1/4"; height profile with 1-1/2"; overall profile height. Applied to the jamb, it functions as standard jamb section for parallel arm closer applications or as a stop when specified, with GREENGUARD Gold certification for indoor air quality compliance.

Professional Features & Benefits

  • Precise Dimensions: 36"; x 84"; length with 1/4"; height and 1-1/2"; profile height for accurate door frame sealing applications.
  • Fire-Rated Performance: UL 10C certified for positive pressure fire tests ensuring code compliance in fire-rated door assemblies.
  • Heavy-Duty Construction: Mill finish aluminum base material provides exceptional durability and corrosion resistance for commercial applications.
  • Eco-V Insert Technology: Advanced Eco-V gasketing material delivers superior sealing performance while maintaining GREENGUARD Gold certification.
  • Versatile Installation: Functions as standard jamb section for parallel arm closer or as stop when specified, with screw-applied mounting.
  • Complete Hardware Package: Supplied with PHSMS #6 x 5/8"; sheet metal screws for mounting, undrilled for custom applications.
  • Environmental Certification: GREENGUARD Gold Certified for low chemical emissions and indoor air quality compliance.
  • Flexible Length Options: Available in lengths from 2' minimum to 185"; maximum for various door frame configurations.

Technical Specifications

  • ANSI/BHMA: Fire Rated UL10C- Positive Pressure; Underwriters Laboratory 4L10; Greenguard Gold Certified
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Dimension: W: 1/4", H: 1-1/2";
  • Product Function: Gasketing
  • Product Group: Door Trim and Accessories
  • Product Length: 36"; x 84";
  • Product Subgroup: Astragals, Gaskets and Weatherstripping
  • Product Substrate: Aluminum
  • Product Type: Gaskets
  • Series: 2903 Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Fire-Rated Door Assemblies
  • Commercial Office Buildings
  • Healthcare Facility Fire Doors
  • Educational Institution Safety Systems
  • Industrial Facility Fire Barriers
  • Multi-Tenant Residential Fire Doors
  • Government and Municipal Buildings

Why Choose Pemko Quality?

Pemko 2903 Series gasketing delivers professional-grade fire protection with UL 10C positive pressure certification and GREENGUARD Gold environmental compliance. The heavy-duty aluminum construction with Eco-V insert technology ensures reliable sealing performance in demanding commercial fire door applications. Engineered for code compliance and long-term durability where fire safety and indoor air quality are essential.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Astragals, Gaskets and Weatherstripping
Product Type:
Gaskets
Subcategory:
Gaskets & Weatherstripping
ANSI/BHMA:
Fire Rated UL10C- Positive Pressure; Underwriters Laboratory 4L10; Greenguard Gold Certified
Product Substrate:
Aluminum
Commercial/Residential:
Commercial
Series:
2903 Series
Product Length:
36" x 84"
Product Function:
Gasketing
Product Dimension:
W: 1/4", H: 1-1/2"
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko 2903AV 84 – Frequently Asked Questions

1) Can I use Pemko 2903 perimeter gasketing on a fire-rated door assembly?
Yes. The Pemko 2903 Series perimeter gasketing is fire rated UL 10C for positive pressure, carries Underwriters Laboratory 4L10, and is Greenguard Gold Certified. That makes it usable on fire-rated door assemblies where a positive pressure listed perimeter seal is called for, and the Greenguard Gold listing is the one facility people ask about on healthcare and school work.
2) How much frame does one Pemko 2903 gasket kit cover on a single door opening?
The 36 x 84 inch configuration covers a standard single opening: 36 inches across the head and 84 inches down each jamb. Order the 84 inch length on its own if you only need jamb legs, for example when you are replacing one damaged side rather than gasketing the whole frame.
3) How much room does the 2903 gasket take up on the frame stop?
The extrusion measures 1/4 inch by 1-1/2 inch. Applied to the jamb it works as the standard jamb section for a parallel arm closer application, or as the stop itself when it is specified that way, so on a flat frame face you are adding the full 1-1/2 inch profile height rather than fitting into an existing kerf.
4) Is Pemko 2903 gasketing screw-on or adhesive, and does it come with fasteners?
Screw applied, and it ships with PHSMS #6 x 5/8 inch sheet metal screws. The extrusion comes undrilled, so you lay it out and drill for your own hole spacing on site. Bring a drill and countersink; there is no peel-and-stick option here.
5) Will Pemko 2903 gasketing interfere with a parallel arm door closer?
No, it is made for that condition. Applied to the jamb the 2903 serves as the standard jamb section for parallel arm closer applications, so the closer shoe mounts to the frame face without the gasket fighting the arm. That is the usual failure point when someone substitutes a stop-mounted seal on a parallel arm opening.
6) What is the Eco-V insert in Pemko 2903 gasketing and is it the sealing element?
The aluminum extrusion is just the carrier. The Eco-V insert is the compressible gasketing material that does the actual sealing against the door face, and it is the part of the assembly tied to the Greenguard Gold certification for low chemical emissions. Both offered configurations of the 2903 use the Eco-V insert.
7) Is Pemko 2903 gasketing rated for exterior weatherstripping or is it an interior smoke and fire seal?
This is a commercial-duty perimeter seal built around a UL 10C positive pressure fire listing, applied to the jamb of a fire-rated assembly. Treat it as the perimeter gasket for rated interior openings, corridors, stairs and cross-corridor doors. It is a commercial product, not a residential entry weatherstrip.
8) What finish does Pemko 2903 perimeter gasketing come in?
Mill finish aluminum only. That is the raw, unpainted silver aluminum, which is what most commercial hollow metal and aluminum frame work takes. If the openings in your building are dark bronze or painted frames and the frame face matters visually, the mill finish will read as a bright line around the opening.
