Pemko 297AV Fire-Rated Perimeter Door Gasketing 36"; x 84"; with Eco-V Insert

Professional Fire-Rated Door Sealing Solution

The Pemko 297AV Standard Perimeter Gasketing provides comprehensive door sealing with 36"; x 84"; coverage in durable mill finish aluminum construction. This heavy-duty gasketing features a gray Eco-V insert that remains flexible at high and low temperatures while resisting deterioration from oily substances. UL 10C fire-rated and GREENGUARD Gold certified for superior air infiltration control and environmental safety in commercial applications.

Professional Features & Benefits

  • Complete Door Coverage: 36"; x 84"; dimensions provide full perimeter sealing for standard commercial door applications with 1/4"; width and 1-1/16"; height profile.
  • Fire-Rated Performance: UL 10C positive pressure fire test certified and UL 1784 air leakage tested for code-compliant fire door assemblies.
  • Heavy-Duty Construction: Mill finish aluminum substrate with 3/8"; projection provides exceptional durability for high-traffic commercial environments.
  • Temperature-Flexible Sealing: Gray Eco-V insert remains flexible at high and low temperatures while resisting deterioration from oily substances for consistent sealing performance.
  • Environmental Certification: GREENGUARD Gold certified for low chemical emissions, supporting healthy indoor air quality in occupied spaces.
  • Comprehensive Testing: ANSI/BHMA A156.22 compliant with ASTM E-283-04 and ASTM E 90-2009 testing for verified air infiltration performance.
  • Professional Installation: Slightly compressible design allows proper fit and seal adjustment during installation for optimal performance.

Technical Specifications

  • ANSI/BHMA: Air Infiltration Tested; Fire Rated- UL10C- Positive Pressure; Underwriters Laboratory 4L10; GREENGUARD Gold Certified
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Duty Level: Heavy Duty
  • Insert Type: Eco-V Insert
  • Product Category: Door Trim and Accessories
  • Product Dimension: W: 1/4", H: 1-1/16";
  • Product Group: Door Trim and Accessories
  • Product Length: 36"; x 84";
  • Product Projection: 3/8";
  • Product Subgroup: Astragals, Gaskets and Weatherstripping
  • Product Substrate: Aluminum
  • Product Type: Gaskets
  • Series: 296 Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Fire-Rated Door Assemblies
  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Industrial and Warehouse Facilities
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties

Why Choose Pemko Quality?

Pemko 297AV gasketing delivers professional-grade sealing performance with heavy-duty aluminum construction and comprehensive fire safety certifications including UL 10C positive pressure testing. GREENGUARD Gold certification ensures low emissions for healthy indoor environments while ANSI/BHMA A156.22 compliance provides verified air infiltration control. Engineered for demanding commercial applications where reliable fire door sealing and environmental safety are essential.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Astragals, Gaskets and Weatherstripping
Product Type:
Gaskets
Subcategory:
Gaskets & Weatherstripping
ANSI/BHMA:
Air Infiltration Tested; Fire Rated- UL10C- Positive Pressure; Underwriters Laboratory 4L10; GREENGUARD Gold Certified
Product Substrate:
Aluminum
Commercial/Residential:
Commercial
Series:
296 Series
Product Projection:
3/8"
Duty Level:
Heavy Duty
Insert Type:
Eco-V Insert
Product Length:
36" x 84"
Product Dimension:
W: 1/4", H: 1-1/16"
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko 297AV-36X84 – Frequently Asked Questions

1) Will the Pemko 297AV gasketing cover a standard 3'0" x 7'0" commercial door opening?
Yes. The 297AV set is supplied for a 36 x 84 inch opening, which is the head and two jambs of a standard 3'0" x 7'0" single door. It seals the perimeter only, so the bottom of the door still needs a separate door bottom or sweep and, on an exterior opening, a threshold.
2) Is the Pemko 297AV approved for use on a fire-rated door assembly?
It is. The 297AV carries a UL 10C positive pressure fire test rating along with Underwriters Laboratory 4L10, and it's air infiltration tested to ANSI/BHMA A156.22. That combination is what an inspector looks for on a labeled fire door opening in an office, school, or hospital corridor.
3) How much does the 297AV gasketing stick out from the frame, and will it interfere with the door swing?
Projection is 3/8 inch off the mounting surface, on a housing that measures 1/4 inch wide by 1-1/16 inch high. Mounted on the stop, that 3/8 inch is what the door face compresses against. The insert is slightly compressible, so you get some adjustment during install to dial in the seal without binding the door.
4) What is the Eco-V insert on the Pemko 297AV and how does it hold up in an unconditioned building?
Eco-V is the gray flexible seal carried in the aluminum retainer. It stays flexible at both high and low temperatures and resists breaking down from oily substances, which is why it gets specified on loading dock doors, mechanical rooms, and industrial openings where a standard vinyl bulb hardens and stops sealing.
5) Will this gasketing meet a low-emission or green building requirement for a school or hospital?
The 297AV is GREENGUARD Gold certified for low chemical emissions, which is the certification typically cited for classrooms, patient rooms, and other occupied interior spaces. It's the reason this one gets picked over an untested gasket on healthcare and education work.
6) Can one 297AV set be used to gasket a pair of doors?
No. The 36 x 84 inch set is sized for the head and jambs of one single door leaf. A pair needs coverage for a wider head plus both jambs, and the meeting stile between the two leaves requires an astragal rather than perimeter gasketing.
7) Does the 297AV help with smoke and air leakage, or just sound and drafts?
Air leakage is the tested performance. The 297AV is UL 1784 air leakage tested and verified under ASTM E-283-04 for air infiltration, with ASTM E 90-2009 sound transmission testing as well. That is the data a code official wants when the opening is part of a smoke barrier or an energy compliance package.
8) What finish does the Pemko 297AV come in?
Mill finish aluminum, and that's the only finish offered on the 297AV. The aluminum retainer is the substrate itself, so if the specification calls for a dark bronze or clear anodized perimeter seal to match existing frames, you'd need a different retainer finish in the Pemko line rather than this one.
9) Is the 297AV heavy enough for high traffic doors, or is it a light residential gasket?
It's rated heavy duty and specified for commercial use, not residential. The aluminum retainer plus the fire rating is what puts it on stairwell doors, corridor doors, and warehouse openings that cycle all day. For a house door, this is more gasket than the job needs.
