Pemko 296CR Series Standard Perimeter Door Gasketing 36"; x 80"; with Black Sponge EPDM Insert

Pemko 296CR Series Standard Perimeter Door Gasketing 36" x 80" with Black Sponge EPDM Insert

(No reviews yet) Write a Review

Model: 296CR-36X80
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$454.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 296CR Series Standard Perimeter Door Gasketing 36"; x 80"; with Black Sponge EPDM Insert

Professional Door Sealing Solution for Commercial Applications

The Pemko 296CR Series Standard Perimeter Gasketing provides reliable air infiltration control and environmental sealing for commercial door assemblies. This 36"; x 80"; gasket features mill finish aluminum construction with a black sponge EPDM insert, offering 3/4"; width and 3/8"; projection for effective perimeter sealing. GREENGUARD Gold Certified for indoor air quality and tested to multiple UL and ASTM standards for fire and air leakage performance.

Professional Features & Benefits

  • Standard Door Dimensions: 36"; x 80"; sizing fits standard commercial door openings with 3/4"; width and 3/8"; projection for comprehensive perimeter coverage.
  • Heavy-Duty Construction: Mill finish aluminum substrate provides durability for commercial applications with reliable long-term performance.
  • Temperature Flexibility: Sponge EPDM insert remains flexible at both high and low temperatures for consistent sealing performance across varying environmental conditions.
  • Chemical Resistance: Resists deterioration from oily substances while maintaining slightly compressible characteristics for effective door-to-frame contact.
  • Multiple Certifications: UL 1784 air leakage tested, UL 10C fire tested, and ANSI/BHMA A156.22 compliant for comprehensive door assembly performance standards.
  • Indoor Air Quality: GREENGUARD Gold Certified for low chemical emissions, supporting healthy indoor environments in commercial buildings.
  • Jamb Application: Designed for jamb mounting to provide effective perimeter sealing around door assemblies in commercial installations.

Technical Specifications

  • ANSI/BHMA: Air Infiltration Tested; Underwriters Laboratory 4L10; Greenguard Gold Certified
  • Application: Applied to Jamb
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Duty Level: Heavy Duty
  • Product Category: Door Trim and Accessories
  • Product Dimension: W: 3/4", H: 36"; x 80";
  • Product Group: Door Trim and Accessories
  • Product Projection: 3/8";
  • Product Subgroup: Astragals, Gaskets and Weatherstripping
  • Product Substrate: Aluminum
  • Product Type: Gaskets
  • Series: 296 Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Pemko Quality?

Pemko 296 Series gasketing delivers professional-grade sealing performance with mill finish aluminum construction and temperature-flexible EPDM insert materials. GREENGUARD Gold Certification and comprehensive UL testing including UL 1784 air leakage and UL 10C fire standards demonstrate proven reliability for demanding commercial door applications. Engineered for heavy-duty commercial use where consistent environmental sealing and code compliance are essential.

Product Specs

Application:
Applied to Jamb
Product Group:
Door Trim and Accessories
Product Subgroup:
Astragals, Gaskets and Weatherstripping
Product Type:
Gaskets
Subcategory:
Gaskets & Weatherstripping
ANSI/BHMA:
Air Infiltration Tested; Underwriters Laboratory 4L10; Greenguard Gold Certified
Commercial/Residential:
Commercial
Series:
296 Series
Duty Level:
Heavy Duty
Product Dimension:
W: 3/4", H: 36" x 80"
Product Projection:
3/8"
Product Substrate:
Aluminum
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko 296CR-36X80 – Frequently Asked Questions

1) Will a Pemko 296CR gasket set cover a standard 3/0 x 6/8 commercial door opening?
Yes. The 296CR perimeter gasketing is supplied for a 36 x 80 inch opening, which is the standard 3/0 x 6/8 door size, so the set covers both jambs and the head of that frame. It mounts to the jamb, not to the door face.
2) How much clearance does the Pemko 296CR gasket need between door and frame?
The extrusion is 3/4 inch wide with a 3/8 inch projection off the stop, so the EPDM bulb reaches 3/8 inch into the gap to meet the door face. If your door-to-stop clearance is much larger than that, the seal will not make consistent contact and you want a deeper-projection gasket instead.
3) Can the Pemko 296CR gasketing be used on a fire rated door assembly?
It is UL 10C fire tested and UL 1784 air leakage tested, and it complies with ANSI/BHMA A156.22 for door gasketing. That is the combination a rated opening with a smoke and draft requirement is usually specified against.
4) Does perimeter gasketing seal the bottom of the door too?
No. The 296CR set seals the two jambs and the head only, since it is applied to the jamb. The gap under the door needs a separate door bottom or sweep, and a threshold if it is an exterior opening.
5) What finish does the Pemko 296CR aluminum gasketing come in?
Clear anodized aluminum, with a black sponge EPDM insert. The carrier is an aluminum extrusion, so it holds its shape on a long jamb run rather than deforming like a vinyl-only seal.
6) Will a sponge EPDM door seal hold up in an unconditioned or exterior opening?
Sponge EPDM stays flexible at both high and low temperatures and resists deterioration from oily substances, which is why it is used on openings that swing between hot and cold. The insert is slightly compressible so it keeps contact with the door face as the frame moves.
7) Is the Pemko 296CR gasketing acceptable for a LEED or indoor air quality spec?
It is GREENGUARD Gold Certified for low chemical emissions, which is the certification most schools and healthcare projects ask for on interior sealing products.
8) Is this Pemko gasketing rated for high traffic commercial doors or is it a light residential seal?
Heavy duty, commercial rated. It is the perimeter seal used on office, school, healthcare, retail, warehouse and municipal openings rather than a residential foam or vinyl weatherstrip.
