Philips Lighting 913700500911 Core & Coil Magnetic HID Ballast, 150W HPS, 120V R-HPF

The Philips Lighting 913700500911 Core & Coil HID Ballast (model 71A8107B) operates 150W HPS lamps, ANSI S55, via an R-HPF circuit with integral ignitor. Rated 120V, 60 Hz and UL Recognized, it suits outdoor commercial and industrial fixtures.

Key Features

  • Lamp Compatibility: 150W HPS, ANSI S55.
  • Construction: Magnetic Core & Coil, R-HPF circuit.
  • Electrical Ratings: 120V, 60 Hz, 170 W input, 1.5 A current, 0.9 PF.
  • Ignitor & Fuse: 125°C integral ignitor; 15 A recommended fuse; remote wiring up to 2' max.

Certifications & Compliance

  • UL Recognized (Approval Marks: ULR)
  • UL Insulation Class H(180°C)
  • UL Temperature Code 1029A
  • Suitable for Outdoor Use

Technical Specifications

  • Ansi Code: S55
  • Approval Marks: ULR
  • Automatic Restart: No
  • Ballast Factor (Nom): 1
  • Capacitor Catalog Number: 7C550P12RA
  • Capacitor Diameter Oval Dimensions: 1.75 in
  • Capacitor Height: 3.75 in
  • Constant Wattage Deviation: Within Trapezoid
  • Ean Upc Product: 7.81087E+11
  • Hipot Test (1 Minute): 2000 V
  • Hipot Test (2 Seconds): 2500 V
  • Input Current (Nom): 1.5 A
  • Input Current (Open Circuit): 2.35 A
  • Input Current (Short Circuit): 1.65-2.75 A
  • Input Current (Starting): 2.25 A
  • Material Nr (12NC): 9.13701E+11
  • Max Ballast Lamp Distance Remote Wiring: 2'
  • Net Weight (Piece): 1.847 kg
  • Number Of Lamps: 1 piece/unit
  • Numerator Packs Per Outer Box: 1
  • Numerator Quantity Per Pack: 1
  • Open Circuit Voltage Test (Volts): 114-126 V
  • Order Code: 9.13701E+11
  • Order Product Name: CORE & COIL HID 71A8107001DB
  • Power Factor (Nom): 0.9
  • Remote Wiring Configuration Allowed: Yes
  • Secondary Short Circuit Current: 3.65-5.55 A
  • Suitable For Outdoor Use: Yes
  • Temperature Marking: A
  • Ul Insulation Class: H(180°C)
  • Ul Recognized: Yes
  • Wire Length By Color: 12"
  • Wire Striplength: 0.5 mm
  • Wire Type: Stranded
  • Product Core Size: 2 5/8 x 2 3/16

Typical Applications

  • HID Lighting Fixture Retrofits and Replacements
  • Outdoor Area and Site Lighting
  • Commercial and Industrial HPS Lighting Systems

Why Philips Lighting?

Philips Lighting builds this Core & Coil HID ballast with a magnetic R-HPF circuit and integral ignitor for dependable, stable operation. UL Recognized construction and outdoor-use suitability ensure reliable, code-compliant performance for professional HID lighting installations.

Manufacturer Resources

Product Specs

Ansi Code:
S55
Approval Marks:
ULR
Automatic Restart:
No
Ballast Factor Nom :
1
Ballast Type:
Magnetic HID
Base Model:
71A8107B
Capacitor Catalog Number:
7C550P12RA
Capacitor Diameter Oval Dimensions:
1.75 in
Capacitor Height:
3.75 in
Capacitor Requirements:
120V
Capacitor Temperature Rating:
105°C
Capacitor Value:
55 MFD
Circuit Type:
R-HPF
Constant Wattage Deviation:
Within Trapezoid
Ean Upc Product:
7.81087E+11
Hipot Test 1 Minute :
2000 V
Hipot Test 2 Seconds :
2500 V
Ignitor Catalog Number:
INTEGRAL
Ignitor Temperature Rating:
125°C
Input Current Nom :
1.5 A A
Input Current Open Circuit :
2.35 A
Input Current Short Circuit :
1.65-2.75 A
Input Current Starting :
2.25 A
Input Frequency:
60 Hz
Input Power Nom :
170 W
Input Voltage:
120 V
Lamp Type:
150W HPS
Material Nr 12nc :
9.13701E+11
Max Ballast Lamp Distance Remote Wiring:
2'
Net Weight Piece :
1.847 kg
Number Of Lamps:
1 piece/unit
Numerator Packs Per Outer Box:
1
Numerator Quantity Per Pack:
1
Open Circuit Voltage:
120 V
Open Circuit Voltage Test Volts :
114-126 V
Order Code:
9.13701E+11
Order Product Name:
CORE & COIL HID 71A8107001DB
Power Factor Nom :
0.9
Rated Lamp Power:
150 W
Recommended Fuse Value:
15 A
Remote Wiring Configuration Allowed:
Yes
Secondary Short Circuit Current:
3.65-5.55 A
Suitable For Outdoor Use:
Yes
Temperature Marking:
A
Ul Insulation Class:
H(180°C)
Ul Recognized:
Yes
Ul Temperature Code:
1029A
Wire Length By Color:
12"
Wire Striplength:
0.5 mm
Wire Type:
Stranded
Product Core Size:
2 5/8 x 2 3/16
Product Type:
HID Ballast
Department:
Electrical

Philips Lighting 913700500911 – Frequently Asked Questions

1) Will the Philips 913700500911 ballast run a 150W high pressure sodium lamp on 120V?
Yes, that is exactly what it's built for. The Philips 71A8107B core and coil HID ballast operates one 150W HPS lamp with ANSI code S55, on a 120V, 60 Hz supply. Nominal input power is 170 W at 1.5 A with a 0.9 power factor. If your lamp carries a different ANSI designation, it is not a match for this ballast.
2) Do I need a separate ignitor and capacitor with this Philips HPS ballast kit?
The ignitor is integral to the ballast, rated 125 degrees C, so there is no separate ignitor to wire in. The capacitor is a separate component: 55 MFD rated for 120V, catalog number 7C550P12RA, 1.75 in oval diameter and 3.75 in high, rated to 105 degrees C. Plan fixture space for that can and confirm you have the matching capacitor before you close up the pole head.
3) Can I use this 150W HPS ballast on 277V or 208V?
No. It is a single-voltage 120V ballast, tested for open circuit voltage in the 114 to 126 V band. On a 277V or 208V feed you need the matching voltage version of the ballast instead, not this one.
4) Is this Philips core and coil ballast OK for an outdoor parking lot or wall pack fixture?
Yes. The 71A8107B is marked suitable for outdoor use and is UL Recognized as a component, with UL insulation class H (180 degrees C), temperature code 1029A and temperature marking A. It is a component ballast, so it goes inside a listed fixture or enclosure rather than being exposed on its own.
5) What does R-HPF mean on a 150W HPS ballast and how does it affect my branch circuit?
R-HPF is a regulated high power factor circuit: power factor is 0.9 nominal and the lamp is regulated against line swings, with constant wattage deviation held within the trapezoid. On 120V it draws 1.5 A nominally, 2.25 A starting, and 2.35 A open circuit, so size the circuit for the starting draw. Philips lists a 15 A recommended fuse for this ballast.
6) Will this ballast restrike the HPS lamp automatically after a power blip?
No. Automatic restart is not a feature of the 71A8107B, so after an outage or momentary drop the HPS lamp has to cool before it will reignite, which is normal HID behavior. If your site needs instant light after a blip, pair the fixture with a quartz restrike or separate emergency lighting.
7) Will this core and coil ballast physically fit the tray in my existing HPS fixture?
Core size on the 71A8107B is 2 5/8 x 2 3/16, and the unit weighs 1.847 kg. Compare those against the core stack of the ballast you are pulling out, and leave room for the separate 55 MFD capacitor, which is 1.75 in across and 3.75 in tall.
8) What wire leads come on the Philips 913700500911 ballast for hookup?
Leads are stranded wire, 12 inches long by color, with a 0.5 mm strip length. Twelve inches is short, so mount the ballast close to your wiring compartment or plan splices inside the fixture.
9) How many ballasts come in a box when I order the Philips 71A8107B?
It ships one per pack, one pack per outer box, and each ballast drives a single lamp. For a multi-fixture relamp job, order one unit per fixture.
