Philips Lighting 913701115001 Core & Coil Magnetic HID Ballast, 400W Metal Halide, Multi-Tap

The Philips Lighting 913701115001 Core & Coil HID Ballast is a magnetic Super-CWA ballast engineered for 400W metal halide (ANSI M135-M155) lamps. It accepts multi-tap 120/208/240/277/480V input at 60 Hz with a 0.9 power factor, and is UL Recognized (ULR) and suitable for outdoor use in commercial and industrial fixtures.

Key Features

  • Lamp Compatibility: Powers 400W MH lamps, ANSI code M135-M155, Rated Lamp Power 400 W.
  • Multi-Tap Voltage: Accepts 120/208/240/277/480V input, 60 Hz, Power Factor 0.9.
  • Magnetic Super-CWA Circuit: Ballast Factor 1 with 10% constant-wattage deviation for stable lamp performance.
  • Matched Components: Includes 7C260P33R capacitor (330V, 26 MFD) and LI533-H4 ignitor, both rated 105°C.
  • Remote Wiring Capable: Supports remote wiring configuration up to a 2' max ballast-lamp distance, with 12" color-coded leads.
  • Outdoor Rated: Suitable for outdoor use in commercial and industrial HID lighting fixtures.

Certifications & Compliance

  • UL Recognized (Approval Marks: ULR)

Technical Specifications

  • Approval Marks: ULR
  • Automatic Restart: No
  • Ballast Factor Nom: 1
  • Constant Wattage Deviation: 10%
  • Input Current Nom: 3.8/2.3/1.9/1.65/0.95 A
  • Max Ballast Lamp Distance (Remote Wiring): 2'
  • Packs Per Outer Box: 1
  • Quantity Per Pack: 1
  • Order Product Name: CORE & COIL HID 71A6052001D
  • Power Factor Nom: 0.9
  • Remote Wiring Configuration Allowed: Yes
  • Suitable For Outdoor Use: Yes
  • UL Recognized: Yes
  • Wire Length By Color: 12"

Typical Applications

  • Commercial and Industrial HID Lighting Fixtures
  • Outdoor Area and Site Lighting
  • Metal Halide Ballast Replacement
  • Fixture Retrofits Requiring a Magnetic Super-CWA Circuit

Why Philips Lighting?

Philips Lighting core-and-coil ballasts use UL Recognized components and matched capacitor/ignitor sets for dependable, code-compliant HID lighting performance in commercial and industrial fixtures. The magnetic Super-CWA circuit design, ballast factor of 1, and multi-tap 120/208/240/277/480V input voltage flexibility make this ballast a dependable replacement option for 400W metal halide lighting systems, with remote wiring capability for fixture design flexibility.

Manufacturer Resources

Product Specs

Ansi Code:
M135-M155
Approval Marks:
ULR
Automatic Restart:
No
Ballast Factor Nom :
1
Ballast Type:
Magnetic HID
Base Model:
71A6052A
Capacitor Catalog Number:
7C260P33R
Capacitor Diameter Oval Dimensions:
1.75 in
Capacitor Height:
4.8 in
Capacitor Requirements:
330V
Capacitor Temperature Rating:
105°C
Capacitor Value:
26 MFD
Circuit Type:
SUPER-CWA
Constant Wattage Deviation:
10%
Ean Upc Product:
7.81087E+11
Hipot Test 1 Minute :
2000 V
Hipot Test 2 Seconds :
2500 V
Ignitor Catalog Number:
LI533-H4
Ignitor Temperature Rating:
105°C
Input Current Nom :
3.8/2.3/1.9/1.65/0.95 A A
Input Current Open Circuit :
2.7/1.6/1.3/0.8/0.65 A
Input Current Short Circuit :
2.2-3.4/1.35-2.1/1.1-1.7/0.75-1.3/0.55-0.85 A
Input Current Starting :
3/1.7/1.5/1.2/0.75 A
Input Frequency:
60 Hz
Input Power Nom :
454 W
Input Voltage:
120/208/240/277/480 V
Lamp Type:
400W MH
Material Nr 12nc :
9.13701E+11
Max Ballast Lamp Distance Remote Wiring:
2'
Net Weight Piece :
7.244 kg
Number Of Lamps:
1 piece/unit
Numerator Packs Per Outer Box:
1
Numerator Quantity Per Pack:
1
Open Circuit Voltage:
275 V
Open Circuit Voltage Test Volts :
250-305 V
Order Code:
9.13701E+11
Order Product Name:
CORE & COIL HID 71A6052001D
Power Factor Nom :
0.9
Rated Lamp Power:
400 W
Recommended Fuse Value:
10/7/5/5/3 A
Remote Wiring Configuration Allowed:
Yes
Secondary Short Circuit Current:
3.6-4.4 A
Suitable For Outdoor Use:
Yes
Temperature Marking:
B/D/D/B/D
Ul Insulation Class:
H(180°C)
Ul Recognized:
Yes
Ul Temperature Code:
1029D
Wire Length By Color:
12"
Wire Striplength:
0.5 mm
Wire Type:
Stranded
Product Core Size:
4 1/4 x 4 3/4 (2 coil)
Product Type:
HID Ballast
Department:
Electrical

Philips Lighting 913701115001 – Frequently Asked Questions

1) Will the Philips 913701115001 ballast run my 400W metal halide lamp?
It's built for a single 400W metal halide lamp carrying ANSI code M135 through M155, with a rated lamp power of 400 W and a ballast factor of 1. One lamp per unit. If your lamp's ANSI designation falls outside the M135-M155 range, or it's a pulse start type outside that code set, this isn't the right core and coil.
2) Can this 400W HID ballast be wired for 480V, or do I need a different part number for each voltage?
One part covers all of it. The 913701115001 is multi-tap and accepts 120, 208, 240, 277 or 480V at 60 Hz, so you pick the tap lead at install instead of stocking five ballasts. Nominal input current runs 3.8 A at 120V, 2.3 A at 208V, 1.9 A at 240V, 1.65 A at 277V and 0.95 A at 480V.
3) What fuse size should I use on a 400W multi-tap metal halide ballast?
Recommended fuse values track the tap you land on: 10 A at 120V, 7 A at 208V, 5 A at 240V, 5 A at 277V and 3 A at 480V. Size the branch circuit around 454 W nominal input power, not the 400 W lamp rating, since the core and coil losses are real load.
4) Do I get the capacitor and ignitor with this core and coil ballast, or do I order them separately?
The kit is matched: capacitor 7C260P33R, rated 26 MFD at 330V, and ignitor LI533-H4. Both components are rated 105 degrees C. The capacitor measures 1.75 in oval diameter and 4.8 in tall, which is the number to check against the ballast tray space in an older fixture before you commit.
5) Can I mount the ballast away from the fixture and run leads to the lamp?
Remote wiring is allowed, but the ballast-to-lamp distance tops out at 2 feet. That covers a pole-head or a separate ballast compartment in the same housing, not a ground-level ballast box feeding a fixture up a pole. The factory leads are 12 inches, color coded, stranded wire.
6) Is this ballast OK for outdoor parking lot and site lighting fixtures?
Yes, it's rated suitable for outdoor use inside commercial and industrial HID fixtures, meaning the enclosed fixture provides the weather protection. The windings carry UL insulation class H (180 degrees C), and the capacitor and ignitor are both 105 degrees C parts, which is what you want in a sealed pole head that runs hot.
7) What does Super-CWA mean and why would I pick it over another HID circuit?
Super-CWA is a constant wattage autotransformer circuit: it holds lamp wattage steady when the line voltage sags, with only 10 percent constant wattage deviation, and it runs at 0.9 power factor. That's the circuit you want on utility feeds that dip, in warehouses and on outdoor sites. Reactor and lag circuits are cheaper but let lamp output follow line voltage.
8) Will the lamp come back on by itself after a power blip?
No. Automatic restart is not a feature of this ballast, so after an interruption the metal halide lamp has to cool before it will restrike, the normal several-minute HID restrike delay. If a facility needs instant light after an outage, plan on quartz restrike fixtures or emergency luminaires alongside it.
9) What open circuit voltage should I read when testing this 400W MH ballast before the lamp strikes?
Nominal open circuit voltage is 275 V, and the acceptable test window is 250 to 305 V. Open circuit input current runs 2.7/1.6/1.3/0.8/0.65 A across the 120 through 480V taps, and secondary short circuit current should fall between 3.6 and 4.4 A. Readings well outside those ranges point at a failed winding rather than a bad lamp.
10) How many ballasts come in a box when I order this Philips core and coil?
It ships one per pack, one pack per outer box, so each order line is a single ballast with its matched capacitor and ignitor. Order by the Philips catalog description CORE & COIL HID 71A6052001D, base model 71A6052A.
