Philips Lighting RSM175STPI Magnetic Fluorescent Ballast for F96T12 Slimline, 120V, 75W

Philips Lighting RSM175STPI Magnetic Fluorescent Ballast for F96T12 Slimline, 120V, 75W

(No reviews yet) Write a Review

Model: RSM175STPI

In Stock (leaves warehouse same day if ordered before 3pm ET)

$200.00
$150.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting RSM175STPI Magnetic Fluorescent Ballast for F96T12 Slimline, 120V, 75W

The Philips Lighting RSM175STPI is a standard magnetic fluorescent ballast engineered to operate (1) F96T12 Slimline lamp rated at 75W. Manufactured under the Philips Advance brandlabel, this 120V input ballast uses an instant start method with a series lamp connection, delivering a 0.95 ballast factor and 0.96 power factor for dependable, consistent performance. Housed in a metal R6 housing measuring 9.5" x 3.11" x 1.78", it is UL Listed, CSA certified, RoHS compliant, and suitable for outdoor use.

Key Features

  • Lamp Compatibility: Designed for (1) F96T12 Slimline lamp rated at 75W, connected in series.
  • Magnetic Construction: Standard magnetic fluorescent ballast housed in a metal R6 enclosure measuring 9.5" x 3.11" x 1.78".
  • Instant Start: Instant start method delivers quick, reliable lamp starting without a separate starter.
  • Electrical Rating: 120V input voltage, 0.82A input current, 94W input power, and 60Hz line frequency.
  • Performance: 0.95 ballast factor, 1.01 ballast efficacy factor, 0.96 power factor, 1.7 lamp current crest factor, 25% max THD, and Sound Rating A for quiet operation.
  • Remote Wiring: Allowed wiring configuration for remote mounting, up to 30' max distance between ballast and lamp.
  • Automatic Restart: Automatic restart feature paired with 18AWG solid wire leads for straightforward installation.

Certifications & Compliance

  • UL Listed
  • CSA Certificate
  • RoHS Compliant
  • Suitable for Outdoor Use

Technical Specifications

  • Ballast Type: Magnetic Fluorescent
  • Base Model: RSM175STP
  • Number Of Lamps: 1 piece
  • Rated Lamp Watts: 75W
  • Starting Method: Instant Start
  • Lamp Connection: Series
  • Input Voltage: 120 V
  • Input Current (Operating): 0.82 A
  • Input Power Gear: 94 W
  • Line Frequency: 60 Hz
  • Housing Material: Metal
  • Housing Type: R6
  • Housing Dimensions: 9.5" x 3.11" x 1.78"
  • Wire Gauge: 18AWG
  • Wire Type: Solid
  • Max Distance, Ballast to Lamp (Remote): 30'

Typical Applications

  • Commercial and Industrial Fluorescent Lighting Fixtures
  • F96T12 Slimline Lamp Fixture Retrofits and Replacements
  • Remote Ballast Mounting Configurations
  • Outdoor Fluorescent Lighting Installations
  • New Construction and Renovation Projects

Why Philips Lighting?

Manufactured under the Philips Advance brandlabel, the RSM175STPI reflects Philips Lighting's commitment to reliable, code-compliant ballast performance. Its metal R6 housing construction, UL Listed and CSA certified ratings, and RoHS compliance make it a dependable choice for professional fluorescent lighting installations. With automatic restart and remote wiring capability up to 30', this magnetic ballast delivers consistent operation for indoor and outdoor F96T12 Slimline lamp fixtures.

Manufacturer Resources

Product Specs

Allowed Wiring Config Remote :
Yes
Allowed Wiring Config Tandem :
No
Allowed Wiring Config Through :
No
Approbation Marks:
UL, CSA, RoHS
Automatic Restart:
Yes
Ballast Efficacy Factor:
1.01 -
Ballast Factor:
0.95 -
Ballast Type:
Magnetic Fluorescent
Bar Code On Case:
3.07811E+13
Bar Code On Pack:
7.81087E+11
Base Model:
RSM175STP
Brandlabel:
PHILIPS ADVANCE
Catalog:
RSM175STPI
Cec Listing:
No
Circle E Logo:
No
Csa Certificate:
Yes
Csa E:
No
Cul Certificate:
No
Doe:
No
Emc Immunity:
FCC Non-Consumer
Eop Net Weight Pp:
2.355 kg
Eop Pck Cfg:
6
Family Name:
Standard
Fide Certificate:
No
Full Product Name:
MAG BALLAST (1) F96T12 SLIMLINE 120V
Gtin:
7.81087E+11
Height C1:
1.78 in
Housing Dimensions:
9.5" x 3.11" x 1.78"
Housing Material:
Metal
Housing Type:
R6
Idwindex:
7583643
Idwitemctrl:
7.81087E+11
Igcc:
3700
Ignition Time:
0.1 s
Input Current Operating :
0.82 A
Input Power Gear:
94 W
Input Voltage:
120 V
Lamp Connection:
Series
Lamp Current Crest Factor:
1.7 -
Lamp Type:
F96T12
Length A1:
9.5 in
Length A2:
8.91 in
Line Frequency:
60 Hz
Logistics Code S :
9.1371E+11
Max Dist Ball To Lamp Remote :
30'
Max Thd:
25%
Nom Certificate:
No
Number Of Lamps:
1 piece
Pieces Per Sku:
1
Power Factor:
0.96
Product Number:
RSM175STPI
Rated Lamp Watts:
75W
Rohs Compliant:
Yes
Saso Certificate:
No
Sequenceid:
478
Short Product Name:
MAG BALLAST (1) F96T12 SLIMLINE 120V
Skus Case:
6
Sound Rating:
A
Starting Method:
Instant Start
Suitable For Outdoor Use :
Yes
Ul Listed:
Yes
Ul Recognized:
No
Unspsc:
39101901
Width B1:
3.11 in
Wire Gauge:
18AWG
Wire Length By Color:
See data sheet
Wire Striplength:
0.50/0.375 mm
Wire Type:
Solid
Product Type:
Fluorescent Ballast
Department:
Electrical

Philips Lighting RSM175STPI – Frequently Asked Questions

1) How many F96T12 Slimline lamps will the Philips Advance RSM175STPI ballast run?
One. The RSM175STPI is a single-lamp magnetic ballast for one F96T12 Slimline lamp rated 75W, wired in series. If your fixture holds two 8-foot slimline lamps, one of these will not carry both, so you would need a two-lamp ballast instead.
2) Will the RSM175STPI ballast work on 277V?
No. This ballast is 120V only, drawing 0.82A at 60Hz with 94W input power. On a 277V circuit you need a 277V version of the ballast, not this one.
3) Can this magnetic ballast be used in an outdoor or unheated fluorescent fixture?
Yes, the RSM175STPI is rated suitable for outdoor use and is UL Listed and CSA certified. It is an instant start ballast, so the lamp fires without a separate starter.
4) Will this ballast fit the channel of my existing 8-foot slimline fixture?
The metal R6 case measures 9.5 x 3.11 x 1.78 inches. R6 is the standard rectangular magnetic ballast case used in most 8-foot strip fixtures, so measure your channel opening and mounting stud spacing against those numbers before you pull the old one.
5) Can I mount the ballast away from the fixture, like in a sign cabinet or a remote enclosure?
Yes. Remote wiring is an allowed configuration, with a maximum of 30 feet between ballast and lamp. Tandem and through wiring are not permitted with this unit, so run it as a single dedicated ballast to its one lamp.
6) Will this ballast hum in a quiet office or classroom?
It carries a Sound Rating A, the quietest class for magnetic ballasts, which is what you want in offices, classrooms and patient areas. Magnetic gear is never silent the way electronic is, but A rated units are acceptable in occupied low-noise spaces.
7) What wire leads come on the RSM175STPI and how do I prep them?
The ballast comes with 18AWG solid leads. Strip length is 0.50/0.375 mm. It also has automatic restart, so the lamp re-strikes after a power interruption without cycling the switch.
8) Is the RSM175STPI RoHS compliant for a government or institutional spec?
Yes, it is RoHS compliant and carries UL and CSA marks. EMC immunity is classed FCC Non-Consumer, which suits commercial and industrial installations rather than residential equipment specs.
9) What is the correct part number to order for a Philips Advance F96T12 slimline 120V magnetic ballast?
Order catalog number RSM175STPI, built on base model RSM175STP under the Philips Advance brandlabel. Each SKU is one ballast, and the factory case pack is six.
