RAB Vertical-Mount HID Replacement LED Lamp - 65W/80W, 8000-10000 Lumens, 5000K, E26 Base with Ballast Bypass

RAB Vertical-Mount HID Replacement LED Lamp - 65W/80W, 8000-10000 Lumens, 5000K, E26 Base with Ballast Bypass

(No reviews yet) Write a Review

Model: HID-65-V-E26-850-BYP-GL

In Stock (leaves warehouse same day if ordered before 3pm ET)

$49.44
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

RAB Vertical-Mount HID Replacement LED Lamp - 65W/80W, 8000-10000 Lumens, 5000K, E26 Base with Ballast Bypass

Professional LED retrofit solution for vertical-mount HID fixtures

The RAB Vertical-Mount HID Replacement LED Lamp delivers exceptional performance with 65W/80W power options producing 8000-10000 lumens of bright 5000K daylight illumination. Featuring an E26 base with ballast bypass design, this LED lamp provides reliable constant current operation at 125 lm/W efficacy for professional lighting applications requiring vertical mounting configurations.

Professional Features & Benefits

  • High Lumen Output: 8000-10000 lumens provide exceptional brightness for demanding commercial and industrial applications
  • Energy Efficient Operation: 125 lm/W efficacy delivers superior performance while reducing energy consumption compared to traditional HID lamps
  • Universal Voltage Compatibility: 120-277V input voltage accommodates diverse electrical systems and installation requirements
  • Extended Service Life: 25000 lamp hours minimize maintenance costs and replacement frequency in professional environments
  • Ballast Bypass Design: Eliminates ballast dependency for simplified installation and improved system reliability
  • Daylight Color Temperature: 5000K provides crisp, natural illumination ideal for task lighting and color-critical applications
  • Vertical Mount Optimization: Specifically designed for vertical-mount fixtures ensuring proper heat dissipation and performance

Technical Specifications

  • Driver Info: Constant Current
  • Efficacy: 125 lm/W
  • Flicker: Yes
  • Input Voltage: 120-277V
  • Lamp Hours: 25000
  • Lamp Info: LED
  • Product Finish: White

Professional Applications

  • Commercial Warehouse Lighting
  • Industrial Facility Illumination
  • Retail Store High-Bay Applications
  • Manufacturing Plant Task Lighting
  • Distribution Center Operations
  • Professional Workshop Environments
  • Maintenance and Service Areas

Why Choose RAB Quality?

RAB delivers professional-grade LED lighting solutions with proven reliability and durability. The 25000-hour service life and constant current driver technology ensure consistent performance in demanding commercial and industrial environments, backed by white finish construction for professional appearance and long-term value.

Manufacturer Resources

Product Specs

Driver Info:
Constant Current
Efficacy:
125 lm/W
Flicker:
Yes
Input Voltage:
120-277V
Lamp Hours:
25000
Product Finish:
White
Department:
Electrical
Product Group:
LED Bulbs
Light Technology:
LED

RAB HID-65-V-E26-850-BYP-GL – Frequently Asked Questions

1) Do I need to remove the ballast to install the RAB HID replacement LED lamp?
Yes. The RAB vertical-mount HID replacement lamp is a ballast bypass (line voltage) lamp, so the existing HID ballast has to be removed or bypassed and the E26 socket wired direct to line. Once it is wired direct it runs on anything from 120 to 277V, so the same lamp works on a 120V shop circuit or a 277V commercial lighting branch. If you are not prepared to open the fixture and rewire the socket, this is not the lamp for that job.
2) Can I mount this RAB LED HID replacement lamp base-up or horizontally in a shoebox fixture?
This one is built for vertical mounting, base up or base down, where the lamp runs in line with the socket. That orientation is what the thermal design counts on. For a horizontal burn position, such as a wall pack or a shoebox with a horizontal socket, look for the horizontal-mount version of the HID replacement lamp rather than forcing this one in.
3) What HID wattage does a 65W or 80W RAB LED replacement lamp actually replace?
Output is the number to match on, not watts. The 65W version puts out 8,000 lumens and the 80W version 10,000 lumens, both at 125 lm/W. Compare that against the lamp coming out: a lamp doing 8,000 to 10,000 lumens on the floor is the territory of a 250W metal halide, and because HID lamps lose a large share of their output over life, a fixture that started at 20,000 lumens is often down near this range by the time it gets relamped. Measure or check your maintained levels if the space is task critical.
4) Is this RAB LED lamp suitable for an office or anywhere people work at screens all day?
Worth knowing before you buy: this lamp flickers. RAB publishes flicker as present on it. That is a non-issue in a warehouse aisle, a loading dock, or a service corridor, which is where these HID retrofits normally go. It matters in an office, a classroom, a healthcare space, or anywhere cameras are running, since flicker shows up on video and bothers flicker-sensitive occupants. For those rooms choose a low-flicker driver product instead.
5) Which RAB part number do I order, the 65W or the 80W?
Two wattages ship on this lamp: HID-65-V-E26-850-BYP-GL at 65W and 8,000 lumens, and HID-80-V-E26-850-BYP-GL at 80W and 10,000 lumens. Everything else is common between them, same E26 base, same vertical mount, same 5000K, same 120-277V bypass wiring. Pick on the light level you need; the 80W is the one for high-bay and warehouse aisles, the 65W for lower mounting heights and service areas.
6) Will 5000K match the other lamps in my warehouse?
5000K is daylight white, the cool crisp end of the range that most warehouse and industrial LED retrofits use. It will read close to a 4000K neutral lamp beside it but noticeably cooler and bluer next to a 3000K warm lamp. If you are relamping a building a few fixtures at a time, standardize the whole space on 5000K rather than mixing, because the color difference is obvious in an open bay long before anyone notices a lumen difference.
7) Can I put this RAB HID replacement LED on a dimmer or an occupancy sensor?
It runs on a constant current driver with no dimming control listed, so treat it as a full-output lamp: wire it to a switched or contactor-controlled circuit, not a dimmer. Line voltage occupancy or photocell switching that simply cuts power is fine. If a job spec calls for dimming or daylight harvesting on those fixtures, a dedicated dimmable LED fixture is the right answer instead of an HID retrofit lamp.
8) How much energy does an LED HID replacement lamp actually save over metal halide?
At 125 lm/W, the 80W lamp does 10,000 lumens on 80 watts. A metal halide system producing comparable light draws several times that once ballast losses are counted, and HID ballasts alone typically add roughly 10 to 15 percent on top of lamp watts, which the bypass wiring eliminates entirely. On top of the draw, the 25,000 hour rated life means far fewer lift trips than an HID relamp cycle, which is usually the bigger number for a facility running high-bay fixtures.
9) How long will these last if the lights run 24/7?
Rated life is 25,000 hours. Running continuously that is a little under three years; on a two-shift schedule of about 16 hours a day it is roughly four and a quarter years, and on a single 8 hour shift about eight and a half. That is the planning number for a maintenance budget on a warehouse or distribution center.
10) Can I use this LED lamp in an enclosed or wet location fixture outdoors?
Treat it as an indoor commercial and industrial lamp: warehouses, plants, distribution centers, shops, and service areas are what it is built around, in a vertical socket orientation. The fixture itself is what carries any wet or damp location rating, so for an outdoor or washdown position the fixture rating and the lamp's vertical orientation both have to check out before it goes in.
