Schaub CS422 Concealed Surface Mounted 12" Center to Center Fonce Acrylic Appliance Pull

The Schaub CS422 is an appliance pull on 12 inch center-to-center spacing, which is sized for refrigerator and freezer panels rather than a base cabinet door. For short spacing, the Omnia 1968/102 modern cabinet pull is forged solid brass on 4 inch center-to-center spacing, and the Trimco 553 series drawer pull is 3 inch center-to-center. The Trimco 562 series covers 3-1/2 inch, 4 inch, and 96mm center-to-center options if you need to match a few different drawer widths in one order.

The Schaub CS422 uses an acrylic bar on solid brass concealed surface mounted posts. If you want metal throughout, the Orca Hardware CK-12001 is a steel T-pull bar with a 2 inch bar width in satin nickel, and the Deltana SBP35 is a heavy-duty solid brass modern square bar pull at 3-1/2 inch. Note that both are shorter than the CS422's 12 inch center-to-center and 15 inch overall length, so they will not fill an appliance panel the same way.

Projection is 2 inches, measured from the mounting surface to the back of the grip. The bases are 1-1/8 inches. Two inches of clearance is worth checking against anything alongside, a wall return, an adjacent appliance handle, or a door swinging into a corner, before you commit to it on a panel-ready fridge or dishwasher.

Both. The CS422 is from Schaub's Fonce collection and pairs acrylic with solid brass hardware, the brass making up the posts and mounting bases. That is why the two-tone finishes exist, the metal components carry the plated finish while the acrylic grip stays constant.

Five choices: Matte Black, Polished Nickel, Satin Brass, and two mixed-metal combinations, Matte Black with Polished Nickel and Matte Black with Satin Brass. The two-tone options let you match a black appliance panel while picking up the nickel or brass used on the rest of the kitchen's cabinet hardware.

No exposed screw heads on the face. The CS422 mounts through the panel from behind with 1/4-20 x 1 inch machine screws threading into the posts, so the front shows only the acrylic bar and its brass bases. You need access to the back of the door or panel to install it.

The CS422 is a contemporary Fonce-collection pull, so the cabinet pulls and knobs should follow the same clean-line vocabulary and the same metal. Emtek sells the Schaub collection under its SELECT 8405 cabinet pulls and its Bar cabinet pull, both of which keep the contemporary bar profile in smaller sizes for doors and drawers. On the modern solid brass side, the Omnia 1968, 1969, 1970, and 1971 series are all modern cabinet pulls if you want a single metal running through the room.

The CS422 is specified for 1/4-20 x 1 inch screws. On a thick applied panel or a door with a substrate plus face material, a 1 inch screw may not reach the post with enough thread engagement, and you would need a longer 1/4-20 machine screw. Measure the panel thickness at the hole locations before install.

It is a two-post bar pull: an acrylic grip carried on two brass bases with a 2 inch projection, mounted at 12 inch centers. That is a different animal from a single-post T-pull like the Orca Hardware CK-12001 with its 2 inch bar width, which anchors at one point. If your panel is only drilled for one hole, the CS422 is not a drop-in.

No. The Schaub CS422 is a Fonce collection acrylic appliance pull in solid brass with a 2 inch projection and a 1-1/8 inch base. The Emtek Bar Cabinet Pull is from the Bar series in Emtek's Schaub collection and is catalogued as a cabinet knob/pull, so it is a straight bar profile rather than the acrylic-bar-on-brass-posts look of the Fonce. They share the Schaub design lineage but are different products with different profiles.

The Schaub CS422 is a contemporary Fonce collection pull in solid brass. To carry the same designer's line to smaller openings, Emtek offers the Schaub collection under its own part numbers: the Emtek 8405 Select cabinet pulls in the Emtek SELECT series, plus the Alexander, Art Deco, and Bar series cabinet pulls, all catalogued as cabinet knob/pull. Confirm center-to-center for each drawer front before ordering, since those series span a range of sizes.

The Schaub CS422 has a 2 inch projection off the face of the panel. For less standoff, the Omnia 1970 modern cabinet pull is forged solid brass with a 1-1/4 inch projection, and the Omnia 1969 and Omnia 1971 are both forged solid brass at 1-3/16 inch projection. All three are cabinet pulls rather than appliance pulls, so check the center-to-center against your panel.

Yes. Schaub publishes a Proposition 65 warning for this pull, linked from its product stewardship page. Specifiers working California multi-family or hospitality projects should route that through their usual disclosure process.

They serve different openings. The Schaub CS422 is a 12 inch center-to-center appliance pull, 15 inch overall, mounted on two posts with 1/4-20 x 1 screws. A knob is single-point: the Orca Hardware CK-15030 Bachelor Collection round pull knob and CK-16030 round ring pull knob are both 1-1/4 inch diameter, and the CK-17025 Blackcomb Collection square knob is 25mm. Those suit small doors and drawers, not an appliance panel that needs a two-post grip along its length.
