Schlage Electronics CO-200 Standalone Electronic Mortise Lock, Privacy Function, Proximity and Keypad Reader

1-3/4 inches is exactly what the CO-200 is built for, and it is a single-thickness lock rather than an adjustable one. If your openings are thinner or thicker (older 1-3/8 inch interior doors, or 2 inch and up), this is the wrong part. For a wider range in an electronic cylindrical lock, the TownSteel XCE-2000 covers 1-3/4 to 2 inches and the SDC E75 covers 1-3/4 to 2-1/8 inches.

Handing is field reversible on the CO-200, so one lock covers a left or right hand opening without a return. Handing is still a selection when you order (right hand, left hand, right hand reverse, left hand reverse, or field reversible), so if you are stocking spares for a building with mixed swings, take the field reversible option and carry one part number instead of four.

Cylinder is a separate line item on most configurations. Four choices: B for less cylinder taking Schlage, Falcon or competitive OEM 7 pin SFIC; J for less cylinder Schlage 6 pin FSIC; L for less cylinder Schlage or Falcon 6 pin KIL; and P, which is the Schlage standard conventional cylinder supplied with the lock. If your facility already runs an SFIC core system, take B and drop your existing cores in. Only the P option arrives ready to key without buying a core separately.

No wiring, no panel, no network drop. The CO-200 is a standalone battery lock running on four AA cells, so the install is door prep and hardware only. Programming happens at the lock, either by keypad or by downloading from the Schlage Utility Software mobile app on a compatible Android device with a SUS-A cable, and it can also be managed from PC-based Schlage Express software. If you want live monitoring and remote lockdown from a head end, a standalone lock is the wrong architecture and you want a networked or wired solution instead.

That is the point of the reader. The CO-200 with the proximity and keypad reader takes the same credential already used at the building perimeter, plus 3 to 6 digit PINs, and card-plus-PIN dual authentication on doors that need it. Proximity and magnetic stripe cards are both supported across the series. It also shares an offline system with the AD-200, CO-220 and CT5000, so a mixed rollout stays on one credential set.

Grade 1, and the certifications listed are ANSI/BHMA A156.25 full outdoor (70 function), ANSI/BHMA Grade 1, UL 294, UL 10C, UL Canada, FCC Part 15, and ADA. As a mortise lock it meets or exceeds ANSI/BHMA A156.13, Series 1000, Grade 1. UL 10C is the positive pressure fire door test, so it is the listing a spec writer looks for on a fire rated opening. Heavy duty, commercial.

The CO-200 is a mortise lock, so it needs a mortise pocket in the door edge. Most of the alternatives are cylindrical, which is a bored prep: the TownSteel XCE-2000 and XCE-9000 keypad locksets, the TownSteel FCE-2000 and FCE-4000 RFID locksets, the Alarm Lock Trilogy T2 DL2700 and T3, and the BEST 9KZ EZ Series with key override are all cylindrical. If your doors are bored for a cylindrical lock, choose one of those rather than paying to mortise the doors. The other split is credentials: the CO-200 reads proximity cards and PIN, while the DL2700 and the TownSteel XCE units are keypad entry.

The Alarm Lock Trilogy T2 DL2700 is a Grade 1 standalone electronic cylindrical lock with a digital keypad and 100 user codes, and it is IC/SFIC compatible. The CO-200 is also Grade 1 and standalone, but it reads proximity credentials as well as keypad PINs and carries up to 2,000 users. Where the opening only needs PIN entry for a small group, the DL2700 covers it on keypad alone; where the same card used at the building perimeter must open the door, the proximity and keypad reader on the CO-200 is what does that.

No. The SDC Electra 7200 is a solenoid controlled cylindrical lock running on dual voltage 12/24VDC for doors 1-3/4 to 2 inches, so it is released by an access control system feeding it power at the door. The Schlage CO-200 is standalone and battery operated on four AA cells, making its own decision at the lock from a PIN or proximity credential. If there is no wire to the opening, the 7200 is not a substitute.

The Schlage CO-200 is ordered less cylinder in a 7 pin SFIC prep that accepts Schlage, Falcon and competitive OEM cores, and also in Schlage 6 pin FSIC, Schlage and Falcon 6 pin KIL, or with a Schlage standard conventional cylinder. The Alarm Lock Trilogy T2 DL2700 is IC/SFIC compatible as well, and the BEST 9KZ EZ Series electronic keypad cylindrical lock includes a key override function. Confirm which core family your master key system is built on before you pick the prep.

The Schlage CO-200 is built for a 1-3/4 inch door. For thinner leaves, the Alarm Lock Trilogy T2 DL2700 covers 1-5/8 to 1-7/8 inches as a Grade 1 standalone keypad lock, the Lockey E985 electronic keypad lever lock with key override covers 1-3/8 to 1-3/4 inches, and the Dorma C150 Grade 1 heavy-duty cylindrical lock in entry/office function spans 1-3/8 to 2-1/4 inches if the opening does not need electronics at all.

Up to 2,000 users and an audit trail of up to 2,000 events, which is what separates the CO-200 from the keypad-only CO-100 below it. That capacity suits a whole floor or a mid-size facility, not just a single room. If you only need a hundred codes on a door, an Alarm Lock Trilogy T2 DL2700 holds 100 user codes and is a simpler box to program.

Seven finishes, 605 bright brass, 606 satin brass, 612 satin bronze, 619 satin nickel, 625 bright chrome, 626 satin chrome and 643E aged bronze, so it matches the usual commercial finish schedules. Lever styles are Athens, Latitude, Longitude, Rhodes, Sparta and Tubular, which are the same Schlage lever families used on mechanical locksets, so an electronic opening does not have to look different from the mechanical ones beside it.

A standalone lock earns its place where you want credential control and an audit trail on a handful of doors without paying for a panel, wiring and a head end. The CO-200 gives you 2,000 users, 2,000 audit events, holidays and time zones for scheduled auto lock and unlock, all managed at the door or from Schlage Express. What it will not do is report in real time or accept a remote unlock from a security desk. If that is a requirement, buy a networked system. If you are only trying to get keys out of circulation on offices and storage rooms, standalone is the right call.

It ships with a 1-1/8 x 2-1/4 inch square corner deadlatch. The deadlatch feature is what stops a latch being carded or shimmed on a door that stands closed against a stop, which matters on an office or storeroom opening in a commercial building. Square corner faceplate is the standard hollow metal door prep, so it drops into a factory prepped steel door without filing the edge.

Yes, and that is the usual reason people buy the series. Classroom/storeroom, office and privacy functions are all available across the CO Series, so restrooms, offices and storage can run the same lock body, the same credential and the same programming workflow with only the function changing. Privacy function locks can also be ordered with the occupancy indication option, which is what a restroom or exam room needs.

The TownSteel XCE-9000 is a Grade 1 heavy duty electronic classroom intruder cylindrical lockset with a keypad, covering 1-3/4 to 2 inch doors, and the FCE-4000 is an RFID electronic intruder classroom cylindrical lockset, Grade 1 heavy duty at 1-3/4 inches. Both are built around the intruder classroom function. The Schlage CO-200 is offered in classroom/storeroom, office, and privacy functions and takes proximity and keypad credentials.

The Cal-Royal CAL20 is a Grade 1 extra heavy duty privacy lockset covering doors 1-3/8 to 2 inches, with no electronics to program or power. The Alarm Lock Trilogy 4100 sits in between as a Grade 1 electronic cylindrical lock with a privacy function and keypad on 1-5/8 to 1-7/8 inch doors. The CO-200 is battery operated on four AA cells and carries an audit trail of up to 2,000 events, which is what you keep by staying electronic and give up by going mechanical.

The Alarm Lock T3 DL3075 is a Grade 1 electronic cylindrical lock with audit trail and keypad access, in the DL3200 Series. The Schlage CO-200 holds up to 2,000 users with an audit trail of up to 2,000 events and adds proximity credentials alongside the keypad, plus support for holidays and time zones to auto lock and unlock during specified periods. Both give you a record of who opened the door; the CO-200 does it with the same credential carried at the building perimeter.

The CENTRIOS CEB100 is a Grade 1 smart Bluetooth cylindrical lock in a privacy function, managed from a phone over Bluetooth. The Schlage CO-200 is a Grade 1 standalone mortise lock read by proximity card or a 3 to 6 digit PIN, programmed at the lock through the SUS mobile app on a compatible Android device or with PC-based Schlage Express software, and it offers an occupancy indication option on privacy function locks. If the facility issues cards rather than phone apps, the CEB100 does not carry that credential.

The SDC E75 Series is a battery-powered electronic cylindrical lockset with keypad access control for doors 1-3/4 to 2-1/8 inches. The Schlage CO-200 is battery powered on four AA cells with up to 2 years of battery life and a status indicator, is field reversible for handing, and is a Grade 1 heavy duty mortise lock at 1-3/4 inches. The E75 is the cylindrical-prep option; the CO-200 also adds proximity credential reading to the keypad.

Up to two years on the four AA cells, with a status indicator at the lock so a maintenance tech can catch a low battery on a walk instead of getting a call about a door. For a property manager budgeting service visits, that puts battery swaps on a routine annual or biennial round rather than a reactive one.

Only where no record of entry is needed. The Lockey 2830 is a mechanical pushbutton keyless knob lock with an auto-locking passage function for doors 1-1/8 to 2 inches, and the Lockey 1600 is a heavy duty mechanical keyless knob lock with adjustable backset over the same 1-1/8 to 2 inch range. Neither reads a credential. The Schlage CO-200 stores up to 2,000 users with an audit trail of up to 2,000 events, which is the reason to specify it over a mechanical pushbutton lock.

The Marks USA 195RAB is a Grade 1 Survivor Series entry clutched lever lockset supplied less core, and the Dorma C853 is a Grade 1 entry keyed single cylinder lever lockset for 1-3/8 to 2-1/4 inch doors. Both hold the Grade 1 rating that the Schlage CO-200 carries. Where the CO-200 is specified for a 2-3/4 inch backset and ordered less cylinder so your own core drops in, the 195RAB is likewise less core for a keyed system.
