Schlage NDEB Locks - Grade 1 ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,740.00
$1,275.22
Schlage Electronics Schlage Electronics NDEBSI - Grade 1 ENGAGE Series Wireless Cylindrical Lock, 2.4 GHz Bluetooth Low Energy Reader, Mobile Enabled Multi-Function with HID Credentials SCH-NDEBSI-KEYED

Schlage NDEB Locks - Grade 1 ENGAGE Series Wireless Cylindrical Lock, 2.4 GHz Bluetooth Low Energy Reader, Mobile Enabled Multi-Function with HID Credentials

(No reviews yet) Write a Review

Model: NDEBSIP RHO 626AM
$1,740.00
$1,275.22
Selected Finish is
Selected Lever Style is
Selected Cylinder is
Selected Keying is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,740.00
$1,275.22
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

SCHLAGE NDE ELECTRONICS NDE MOBILE ENABLED WIRELESS CYLINDRICAL LOCK

The Schlage® NDE mobile enabled wireless cylindrical lock is designed to affordably extend electronic access control deeper into the building beyond traditional perimeter and high security openings. It can function in offline or No-Tour mode or as a networked lock with either periodic check-ins or real-time management.

The open architecture design allows the NDE to be managed by Allegion software or to be integrated into popular physical access control systems through our PACS Alliance program. This enables customers to choose the system that best fits their requirements and gives them the ability to move to a fully networked solution at any time.

The NDE is compatible with a wide range of mobile, smart and proximity credential technologies and can operate in storeroom, office, privacy, or apartment functions using its interior push button with indication.

NDE works within existing network architecture and can exist in the same EAC system as other wireless locks including Schlage Control™, AD-400 and LE.



ND Series Mechanical Lock

Users: Up to 5,000 1
Audits: Up to 2,000 2
Credential verification time: Smart and proximity: ≤ 1 second;Mobile: mobile device dependent
Visual communications: LED (red, amber, green)
Audible communications: Audible indicator (field configurable)
Communication standards:

  • 2.4 GHz Wi-Fi® (IEEE 802.11b/g/n)
  • WPA2, WPA, WEP, 802.1x
  • Bluetooth® low energy (version 4.2)
  • Transport Layer Security (TLS) version 1.2
  • Advanced Encryption Standard (AES), 256-bit

Gateway communication range: Up to 30' in typical building environments. A detailed site survey is recommended using the ENGAGE Test Kit (TKE). Reference ENGAGE™ Gateway
Data Sheet for additional detail.
Wake-Up on Radio: Responds to command from host in less than 5 seconds when linked to ENGAGE; Gateway (requires PACS provider system)
Data rate: NDE80 = 24mbps, NDEB = 54mbps
Connectivity options:

  • Mobile device (send updates at the lock)
  • Wi-Fi access point (automatic daily updates7)
  • No-Tour8
  • ENGAGE Gateway (real-time communication)- RS-485 to ACP or IP to host

Battery life: Uses 4 AA batteries;Up to 2 years
Operating temperature Exterior: -31° to 151°F (-35° to 66°C); Interior: 32° to 120°F (0° to 49°C) (battery)
Operating humidity: 0 - 100% non-condensing
Certifications: ANSI/BHMA A156.25-2013 (Indoor/Outdoor), ANSI/BHMA A156.2-2011, Series
4000, Grade 1, UL 294, UL 10C, CSA C22.2 No. 205-M1983, FCC Part 15, IC
RSS-210, ADA, ICC ANSI A117.1

Manufacturer Resources

Product Specs

Series:
ENGAGE Series
Grade:
Grade 1
Duty Level:
Heavy Duty
Handle Type:
Lever
Keyed Function:
Single Cylinder
Keys Included:
2
Features:
Electronics Bring More Visibility and Control to the Opening; Ability to Read Bluetooth and NFC Mobile Credentials, Along with Smart and Proximity; Updates can be Made Immediately
Standard Strike:
47267101: ANSI w/DPS, 1-1/4" x 4-7/8", 1-3/16" Lip
Subcategory:
Electronic Cylindrical Locks
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Cylindrical Locks
Keyed:
Yes
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
ANSI/BHMA:
ANSI/BHMA Certified A156.25-2013, A156.2-2011, Series 4000, UL 294, UL 10C
Electronic:
Yes
Wireless Communication:
Yes
Connection Type:
Wireless
Product Attribute:
Electronic Locks
Door Hand Direction:
Non-Handed
Door Thickness Range:
1-5/8" to 2"
Product Category:
Electronic Locks
Product Substrate:
Zinc and Steel
Department:
Door Hardware

Schlage Electronics NDEBSIP RHO 626AM – Frequently Asked Questions

1) Do I have to specify handing when ordering a Schlage NDE cylindrical lock?
No handing to specify. The NDE is non-handed, which is what makes it practical to stock one lock for a whole floor of openings regardless of swing. What you do have to specify is finish, lever style, and cylinder prep.
2) What cylinder options does the Schlage NDE wireless lock come in, and which do I pick for an SFIC keyway?
Four cylinder preps: B for 6-pin small format IC prep less core, J for full size IC less core, L for less conventional cylinder, and P with a conventional cylinder supplied. If your facility is on small format interchangeable core, order B and drop your own cores in. If you keep full size IC, order J. Order P only if you want Schlage's conventional cylinder in the box. It is a single cylinder keyed lock, and two keys come with it.
3) Does the Schlage NDE lock need a special strike or will it work with the ANSI prep already in my frame?
The NDE ships with a 47267101 ANSI strike with door position sensor, 1-1/4 by 4-7/8 inches with a 1-3/16 inch lip. That is the standard ANSI 4-7/8 frame prep, so on an existing commercial hollow metal frame already cut for ANSI you are dropping into the same cutout. The door position sensor is built into that strike, which is how the lock reports door open or closed back to the access control system, so do not substitute a plain strike if you want that reporting.
4) Is the Schlage NDE wireless lock rated for a fire door?
The NDE carries UL 10C along with UL 294 for access control, and it is ANSI/BHMA certified to A156.25-2013 and A156.2-2011 Series 4000, Grade 1. The description also lists ADA and ICC ANSI A117.1. For a fire rated opening, UL 10C is the positive pressure fire test listing you need on the hardware, and the lock has to be installed on a labeled door and frame assembly to keep the rating.
5) Do I need a gateway or network to run Schlage NDE locks, or can they work standalone?
Both. The NDE runs offline or in No-Tour mode with no infrastructure, updates over a mobile device at the door, checks in daily over a 2.4 GHz Wi-Fi access point, or communicates in real time through an ENGAGE Gateway (RS-485 to an access control panel or IP to host). Gateway range is up to about 30 feet in typical building environments, and Allegion recommends a site survey with the ENGAGE Test Kit (TKE) before you commit to gateway placement. Wake-up on radio responds to a host command in under 5 seconds when linked to a gateway. That lets you start offline and move to fully networked later without changing locks.
6) What lock functions can a Schlage NDE be set to, and can I change it after install?
The NDE operates in storeroom, office, privacy, or apartment function using the interior push button with indication. That is a configuration, not a different part number, so one lock covers an office door today and a privacy application later. The audible indicator is field configurable, and the LED signals in red, amber and green.
7) What powers the Schlage NDE lock and do I need to run wire to the door?
Four AA batteries, up to two years of life, and no wire to the opening. That is the whole point of it: you get electronic access control on interior doors without cutting the frame for power transfer or pulling cable, which is why it goes on classroom, storeroom and tenant doors that were never worth hardwiring. If you want a wired, panel-powered cylindrical lock instead, the SDC Electra 7200 Series is a solenoid controlled cylindrical lock running 12 or 24 VDC.
8) How is the Schlage NDE different from a keypad lock like the Alarm Lock Trilogy or TownSteel XCE?
The NDE is a credential reader lock, Bluetooth and NFC mobile plus smart and proximity cards, and it can report to a host system in real time. Keypad locks are code entry. The Alarm Lock Trilogy T2 DL2700 is a Grade 1 standalone electronic cylindrical lock with a digital keypad, 100 user codes and IC/SFIC compatibility. The TownSteel XCE-2000 is a Grade 1 heavy duty electronic cylindrical keypad lockset in classroom function. Choose keypad if you want no credentials to issue and no software; choose the NDE if you are managing many users, want audit trail and mobile credentials, or intend to bring the openings into a networked access control system later.
9) I have a door thicker than 1-7/8 inches. Which electronic cylindrical lock will fit?
The Schlage NDE covers 1-5/8 to 2 inches, so it takes that door. If you are comparing, the Alarm Lock Trilogy DL2700 and DL4100 both stop at 1-7/8 inches, the TownSteel XCE-2000 and XCE-9000 run 1-3/4 to 2 inches, and the SDC E75 goes 1-3/4 to 2-1/8 inches. On a thick door, thickness is the first thing to check, ahead of function or credential type.
10) Will Schlage NDE locks work alongside the AD-400 and Schlage Control locks we already have?
Yes. The NDE works within existing network architecture and can live in the same electronic access control system as other Allegion wireless locks including Schlage Control, AD-400 and LE. The open architecture also lets it be managed by Allegion software or integrated into third-party access control systems through the Allegion PACS Alliance program, so you are not forced to change head-end software to add openings.
11) I need a classroom intruder function lock. Is the Schlage NDE the right choice?
Not for that. The NDE configures to storeroom, office, privacy or apartment function, so a dedicated classroom intruder lockset is a different product. For that requirement, the TownSteel XCE-9000 is a Grade 1 electronic classroom intruder cylindrical lockset with keypad for 1-3/4 to 2 inch doors, and the FCE-4000 Series is an RFID electronic intruder classroom cylindrical lockset for 1-3/4 inch doors. Use the NDE where you want credential-based access control and audit on general openings, and an intruder function lock where lockdown from inside the room is the requirement.
12) What is the closest equivalent to the Schlage NDEB wireless cylindrical lock if the site standardizes on TownSteel?
The TownSteel XCE-2000 Series is the nearest peer: a Grade 1 heavy duty electronic cylindrical lockset with a keypad, classroom function, fitting doors 1-3/4 inch to 2 inch. The NDEB is also Grade 1 heavy duty and fits a 1-5/8 inch to 2 inch door, but reads credentials rather than codes - Bluetooth and NFC mobile credentials along with smart and proximity. The practical split is credential technology: XCE-2000 openings are entered by keypad code, NDEB openings by a phone or card. Both are cylindrical bored locksets, so the door prep is the same class of prep.
13) What is a simpler electronic cylindrical lock than the Schlage NDEB when there is no access control system to connect to?
The Alarm Lock Trilogy T2 DL2700 is a standalone electronic cylindrical lock, Grade 1, with a digital keypad and 100 user codes, IC/SFIC compatible, for doors 1-5/8 inch to 1-7/8 inch. It is programmed at the door and needs no host system or gateway. The NDEB is also Grade 1 and is a wireless lock built to be managed by software or integrated into an access control system, reading mobile, smart and proximity credentials. For a handful of doors with a short user list, the DL2700 is the self-contained route; the NDEB is the one to pick when the openings will be managed centrally.
14) The door is 2-1/4 inches thick - what Grade 1 cylindrical lever lock fits when the Schlage NDEB does not?
The NDEB fits doors 1-5/8 inch to 2 inch. For a thicker leaf, the Dorma C853 entry keyed single cylinder lever lockset is Grade 1 and covers 1-3/8 inch to 2-1/4 inch, and the Dorma C150 heavy-duty cylindrical lock in entry/office function covers the same 1-3/8 inch to 2-1/4 inch range at Grade 1. Both are mechanical key-operated locksets rather than credential readers, so an opening moved to a C853 or C150 is keyed rather than managed electronically.
15) Is the TownSteel FCE-4000 a substitute for the Schlage NDEB on a classroom opening?
They are not the same tool. The FCE-4000 is a Grade 1 heavy duty RFID electronic intruder classroom cylindrical lockset for 1-3/4 inch doors - the intruder function lets the room be secured from inside. The NDEB is Grade 1 heavy duty as well and operates in storeroom, office, privacy, or apartment functions using its interior push button with indication; classroom intruder function is not among them. If the specification calls for lockdown from the inside of the classroom, the FCE-4000 or the XCE-9000 classroom intruder lockset answers it; the NDEB answers the openings managed by mobile and card credentials.
16) What replaces the Schlage NDEB on an opening that has to be electrically released from a card reader or door controller?
The SDC Electra 7200 Series is a solenoid controlled cylindrical lock running on dual voltage 12/24VDC for doors 1-3/4 inch to 2 inch - it is wired to a controller and released by it. The NDEB is a wireless lock powered by 4 AA batteries with the reader in the lock itself, communicating over 2.4 GHz Wi-Fi and Bluetooth low energy. Where the access decision is made by a panel and the opening is already wired, the 7200 takes the signal; where running wire to the leaf is the obstacle, the NDEB puts the reader and the decision at the door.
17) Can I get multiple Schlage NDE locks keyed alike across a building?
Yes, keyed alike is an ordering choice on the NDE alongside keyed different, and there is a free-text field for special cylinder or keying requirements if you are matching an existing master system. A third option lets you order it less cylinder entirely so your locksmith supplies cores from your own keyway. Two keys come with a keyed lock.
18) Can the Schlage NDE be used on an exterior door, or is it interior only?
It is certified to ANSI/BHMA A156.25-2013 Indoor/Outdoor, and the exterior operating range runs -31 to 151 F (-35 to 66 C). The interior side, where the batteries live, is rated 32 to 120 F (0 to 49 C), and humidity 0 to 100 percent non-condensing. In practice that means the lock body handles weather but the battery compartment wants a conditioned interior side, which is the normal case on a perimeter or vestibule door.
19) How many users and audit records does a Schlage NDE lock hold?
Up to 5,000 users and up to 2,000 audit events on the lock itself. For a tenant suite, a stockroom, or a shared amenity room that is normally more than enough; if you are running a large campus population through one opening, you would pull audits regularly or run it networked through an ENGAGE Gateway so events move off the lock in real time.
20) What lever styles and finishes does the Schlage NDE come in for matching existing hardware?
Nine lever styles cover it: Athens, Boardwalk, Broadway, Latitude, Longitude, Omega, Rhodes, Sparta and Tubular. Finishes run 605 bright brass, 606 satin brass, 612 satin bronze, 613 oil rubbed bronze, 619 satin nickel, 622 matte black, 625 bright chrome, 626 satin chrome, 626AM satin chrome antimicrobial, and 643E aged bronze. If you are adding electronic openings to a building already on Schlage ND mechanical locks, pick the lever and BHMA finish number that match what is on the other doors and the two will read as one set. The 626AM antimicrobial finish is worth knowing about for healthcare corridors.
21) Is the Schlage NDE tough enough for a high traffic commercial opening?
It is Grade 1 heavy duty, built for commercial use, with a zinc and steel construction, and certified to ANSI/BHMA A156.2-2011 Series 4000 for the mechanical cylindrical lock side. Grade 1 is the highest of the three ANSI/BHMA operational grades, which is the level you want on a main corridor, stairwell or tenant entry rather than a light-use interior door.
22) Is there a cheaper way to control a single door than a Schlage NDE, if I do not need audit or networking?
For one door with a handful of people and no reporting requirement, a mechanical pushbutton lock avoids batteries, credentials and software altogether. The Lockey 1600 is a heavy duty mechanical keyless knob lock with an adjustable backset, covering 1-1/8 to 2 inch doors, and the Lockey 2830 is a mechanical pushbutton keyless knob lock with an auto-locking passage function over the same thickness range. What you give up is per-user credentials, audit trail, and the ability to revoke access without changing the code for everyone. That trade is why the NDE, with up to 5,000 users and 2,000 audits, belongs on doors with turnover.
23) What is the alternative to the Schlage NDEB when only mechanical key access is needed on the interior doors of the same building?
The Marks USA 195RAB is a Grade 1 Survivor Series entry clutched lever lockset supplied less core, and the Marks USA 195N is a Grade 1 passage lever lockset with an American lever, ADA compliant, for openings that need no lock at all. The NDEB is Grade 1 and non-handed, and its keyed variants take a conventional cylinder, 6-pin SFIC prep less core, or FSIC less core. Where a job runs NDEB locks on the controlled doors, the 195RAB keeps the same Grade 1 level on the key-only doors and accepts a core, and the 195N covers the openings that only need latching.
24) Which electronic cylindrical lock takes a small format interchangeable core the way the Schlage NDEB does?
The NDEB is offered in a 6-pin SFIC prep less core and an FSIC less core, as well as a conventional cylinder. Among electronic peers, the Alarm Lock Trilogy T2 DL2700 is IC/SFIC compatible at Grade 1, and the BEST 9KZ EZ Series electronic keypad cylindrical lock includes a key override function. A site already keyed on an SFIC core system can carry that core into either the NDEB or the DL2700 rather than introducing a second key system.
25) For a privacy opening, what is used instead of the Schlage NDEB?
The NDEB can run in a privacy function using its interior push button with indication, but on a restroom or single-occupancy door with no need for credentials, the Cal-Royal CAL20 is a Grade 1 extra heavy duty privacy lockset covering 1-3/8 inch to 2 inch doors, and the Alarm Lock Trilogy 4100 is a Grade 1 electronic privacy lock with a keypad for 1-5/8 inch to 1-7/8 inch doors. The CAL20 is purely mechanical; the 4100 keeps a keypad on a privacy opening.
26) Is the CENTRIOS CEB100 Bluetooth lock the same kind of product as the Schlage NDEB?
Both read Bluetooth, but they are aimed at different openings. The CENTRIOS CEB100 is a Grade 1 smart Bluetooth cylindrical lock in privacy function. The NDEB is Grade 1 heavy duty, reads Bluetooth and NFC mobile credentials along with smart and proximity cards, and is built to run offline, in No-Tour mode, or as a networked lock with periodic check-ins or real-time management through Allegion software or a PACS Alliance system. A CEB100 opening is unlocked from a phone; an NDEB opening is administered as part of an access control population.
27) What electronic cylindrical lock covers a 2-1/8 inch door when the Schlage NDEB tops out at 2 inches?
The SDC E75 Series is a battery-powered electronic cylindrical lockset with keypad access control rated for doors 1-3/4 inch to 2-1/8 inch. The NDEB fits 1-5/8 inch to 2 inch. Both run on battery power at the door, so neither requires wire to the leaf; the E75 is entered by keypad code while the NDEB reads mobile, smart and proximity credentials.
28) How does the Accentra nexTouch NTB613 differ from the Schlage NDEB for a small multi-tenant building?
The Accentra nexTouch NTB613 is a Grade 1 cylindrical keypad lock with pushbutton entry - each user is given a code entered at the lock. The NDEB is Grade 1 and can run in apartment function using its interior push button with indication, and it reads mobile, smart and proximity credentials, holding up to 5,000 users with up to 2,000 audits. For a building where tenants turn over and codes would need reissuing, the NDEB's credential model and audit record is the difference; for a building with a short, stable tenant list, the NTB613 keeps the entry method to a keypad.
29) What looks like a substitute for the Schlage NDEB but will not secure the opening?
Dummy and passage trim will not. The Dorma C501 is a Grade 2 single dummy trim keyless lever lockset for 1-3/8 inch to 1-3/4 inch doors, the Dorma CL701 is a Grade 2 single dummy non-keyed cylinder lever lockset, and the Orca OCL2170 is a Grade 2 half dummy lever - none of them latch or lock. The Orca OCL210 is a Grade 2 medium duty passage lockset, which latches but never locks. The NDEB is Grade 1 heavy duty, keyed with a single cylinder and 2 keys included, and reads credentials at the door. Dummy and passage trim belong on the inactive leaf or a closet, not on a controlled opening.
30) Is a Lockey keyless pushbutton lock an alternative to the Schlage NDEB on a service or gate opening?
The Lockey 1600 is a heavy duty mechanical keyless knob lock with an adjustable backset covering 1-1/8 inch to 2 inch doors, and the Lockey 2830 is a mechanical pushbutton keyless knob lock with auto-locking passage function over the same 1-1/8 inch to 2 inch range. Both are mechanical - no batteries, no credentials, no record of who came through. The NDEB is a lever lockset, non-handed, running on 4 AA batteries with up to 2,000 audits and credential reading. On a remote opening with no power service and no need for an audit record, the Lockey units are the mechanical route; where the opening has to be traceable and managed, they are not a swap for the NDEB.
31) Is the Stanley QCL150 an equivalent to the Schlage NDEB for a Grade 1 entry opening?
It is not the same grade. The Stanley QCL150 is a Grade 2 entry lever with a Sierra bent lever and rose, supplied less cylinder, with a square 2-3/4 inch backset latch and a 4-7/8 inch x 1-1/4 inch ASA strike. The NDEB is Grade 1, ANSI/BHMA A156.2 Series 4000, heavy duty, and ships with an ANSI strike with DPS, 1-1/4 inch x 4-7/8 inch with a 1-3/16 inch lip. The strike footprint is the same 4-7/8 inch x 1-1/4 inch ANSI opening, so the frame prep carries over, but the QCL150 is a mechanical Grade 2 entry lever and the NDEB is a Grade 1 credential-reading lockset with a door position switch in the strike.
32) Does the NDEB communicate faster than the NDE80, and does that matter?
Data rate is 54 mbps on the NDEB versus 24 mbps on the NDE80. Both use 2.4 GHz Wi-Fi (IEEE 802.11b/g/n). The higher rate on the NDEB matters mainly on sites pushing frequent updates or larger credential databases across many locks; for a handful of openings on daily check-in it is not the deciding factor. Credential read speed is the same one second or less for smart and proximity either way.
33) Which lock should be specified instead of the Schlage NDEB on a healthcare or food service door where surface hygiene is the driver?
The NDEB itself covers this: it is offered in 626AM satin chrome antimicrobial alongside standard finishes such as 626 satin chrome and 622 matte black, on a zinc and steel body. Among the peers, the TownSteel FCE-2000 is a Grade 1 heavy duty standalone motorized cylindrical lockset with RFID for 1-3/4 inch doors if a standalone credential lock is wanted on the same wing. For the hygiene-driven openings specifically, the antimicrobial finish is on the NDEB rather than something to be sourced from a different lockset.
34) Can a Marks USA 175RF storeroom lever stand in for the Schlage NDEB on a storeroom door?
The Marks USA 175RF SFIC is a Grade 2 storeroom clutched lever lockset, small format IC less core, 2-3/4 inch backset, with an ANSI strike. The NDEB operates in storeroom function and is Grade 1 heavy duty. On a storeroom that only needs to stay locked and be opened by key, the 175RF does that job at Grade 2 and accepts an existing small format core. On a storeroom that has to be opened by credential or have its access changed without rekeying, the 175RF does not substitute.
