Schneider Electric 8536 Type S Magnetic Motor Starter NEMA Sizes 0-3 3-Phase 120V Coil Non-Reversing Across-the-Line Control System

Schneider Electric 8536 Type S Magnetic Motor Starter NEMA Sizes 0-3 3-Phase 120V Coil Non-Reversing Across-the-Line Control System

Professional Motor Control for Industrial Applications

The Schneider Electric 8536 Type S Magnetic Motor Starter delivers reliable 3-phase motor control with 120V coil operation and non-reversing across-the-line functionality. This professional-grade motor starter features screw clamp terminals for secure electrical connections and separate control circuit design for enhanced operational flexibility. Built to NEMA standards for sizes 0-3, this open device configuration provides versatile motor control solutions for industrial and commercial applications.

Professional Features & Benefits

• 3-Phase Motor Control: Provides reliable three-phase power management for industrial motor applications with consistent performance and operational stability.
• 120V Coil Operation: Standard voltage coil design ensures compatibility with common control circuits and simplifies integration into existing electrical systems.
• Non-Reversing Design: Dedicated across-the-line configuration delivers straightforward motor starting and stopping control for single-direction applications.
• Screw Clamp Terminals: Secure electrical connections ensure reliable power transfer and simplified installation with standard wiring practices.
• Separate Control Circuit: Independent control wiring allows for flexible control integration and enhanced safety isolation between power and control functions.
• NEMA Sizes 0-3 Compatibility: Versatile sizing options accommodate various motor ratings and application requirements across multiple industrial contexts.
• TAA Compliance: Meets Trade Agreements Act requirements for government and institutional procurement applications.

Technical Specifications

• Compliance: TAA
• Control Circuit: separate control circuit
• Control Type: no control units
• Country Of Origin: Mexico
• Electrical Connection: screw clamp terminals
• Environmental Disclosure: ENVPEP2506062EN
• Eoli Availability Display: No need of specific recycling operations
• Function Option: Standard
• Function Option Id: STANDARD
• Legacy Weee Scope: In
• Local Signalling: without pilot light
• Manufacturer: Schneider Electric
• Mercury Free: Yes
• Motor Starter Type: non reversing
• Nema Degree Of Protection: not rated (open device)
• Packaging Made With Recycled Cardboard: Yes
• Packaging Without Single Use Plastic: Yes
• Phase: 3 phase
• Poles Description: 3P
• Product Availability: Stock - Normally stocked in distribution facility
• Product Contributes To Saved And Avoided Emissions: No
• Product Or Component Type: motor starter
• Range Of Product: S
• Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id: CONTAINS_SVHC
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• Recycled Metal Content At Cr Level: 0%
• Relationshiptype: Compatible relationship
• Return Indicator: Y
• Returnability: Yes
• Rohs Eur Conformity Date: 2541
• Rohs Eur In Scope: Yes
• Rohs Exemption Information: Yes
• Scope Perimeter: Outside of Europe
• Sustainable Packaging: Yes
• Take Back: No
• Tier: 1
• Tier Id: 1
• Toxic Heavy Metal Free: Yes
• With Recycled Cardboard: Yes
• Without Single Use Plastic: Yes
• Department: Electrical
