Schneider Mini Circuit Breaker, QO, 25A, 2 Pole, 120/240VAC, 10kA, Bolt On

Schneider Electric QO 25A 2-Pole GFCI Circuit Breaker 120/240VAC 10kA Bolt-On

(No reviews yet) Write a Review

Model: QOB230GFI

In Stock (leaves warehouse same day if ordered before 3pm ET)

$552.39
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric QO 25A 2-Pole GFCI Circuit Breaker 120/240VAC 10kA Bolt-On

Professional Ground Fault Circuit Interrupter Protection

The Schneider Electric QO 25A 2-Pole GFCI Circuit Breaker delivers reliable ground fault protection for 120/240VAC applications with 10kA interrupting capacity. This bolt-on miniature circuit breaker features pressure plate electrical connections and occupies 2 spaces in QO load centers, providing professional-grade earth leakage protection for commercial installations.

Professional Features & Benefits

  • 25A Current Rating: Handles substantial electrical loads while providing precise overcurrent protection for branch circuits.
  • GFCI Protection: Built-in ground fault circuit interrupter technology protects against electrical shock hazards and ground faults.
  • 10kA Interrupting Capacity: Safely interrupts fault currents up to 10,000 amperes for reliable system protection.
  • Bolt-On Mounting: Secure mechanical connection ensures reliable contact and prevents accidental disconnection during service.
  • Pressure Plate Connections: Professional-grade electrical connections provide consistent contact pressure and long-term reliability.
  • 2-Pole Configuration: Protects both hot conductors in 240V applications while maintaining proper neutral handling.
  • QO Series Compatibility: Designed specifically for Schneider Electric QO load centers and panelboards.

Technical Specifications

  • Ambient Air Temperature For Operation: 40 °C
  • Average Life Duration: 15 year(s)
  • China Rohs In Scope: No
  • Circuit Breaker Application: not rated
  • Circularity Profile: ENVEOLI2212005
  • Compliance: TAA
  • Country Of Origin: Mexico
  • Device Type: LV equipment - Low voltage circuit breaker
  • Electrical Connection: pressure plate
  • End Of Life Doc Ref: ENVEOLI2212005
  • Energy Efficiency Optimized: FALSE
  • Environmental Disclosure: ENVPEP2212005
  • Eoli Availability Display: Yes
  • Eu Rohs Directive: Compliant with Exemptions
  • Field Service Division: PPIBS
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Green Premium Status For Reporting: Green Premium product
  • H And D Domain: Safety
  • H And D Enrichment Assignment: yes
  • H And D Enrichment Class 3: Earth leakage protection devices
  • H And D Enrichment Class 4: GFCI
  • H And D Enrichment Function: GFCI
  • H And D Subrange: COM
  • Legacy Weee Scope: In
  • Market Segmentation: Commercial
  • Market Segmentation Id: COMMERCIAL
  • Mercury Free: Yes
  • Mounting Mode: bolt-on
  • Number Of Spaces Required: 2
  • Packaging Made With Recycled Cardboard: No
  • Packaging Without Single Use Plastic: Yes
  • Poles Description: 2P
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Depth: 2.91 in
  • Product Height: 4.13 in
  • Product Or Component Type: miniature circuit-breaker
  • Product Width: 1.5 in
  • Range Of Product: QO
  • Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: CONTAINS_SVHC
  • Reach Regulation: Reference contains Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 2532
  • Rohs Eur Full Compliance Status: Compliant with Exemptions
  • Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant with Exemptions
  • Rohs Exemption Information: Yes
  • Serviceability: No
  • Sustainable Packaging: No
  • Take Back: No
  • Tier: 1
  • Tier Id: 1
  • Total Lifecycle Carbon Footprint: 41 kg CO2 eq.
  • Traceability: No
  • Use Carbon Footprint: 37.375
  • With Recycled Cardboard: No
  • Without Single Use Plastic: Yes
  • Department: Electrical

Professional Applications

  • Commercial Electrical Panels
  • Industrial Control Centers
  • Multi-Unit Residential Properties
  • Professional Office Buildings
  • Retail and Service Establishments
  • Healthcare and Educational Facilities
  • Ground Fault Protection Applications

Why Choose Schneider Electric Quality?

Schneider Electric QO series circuit breakers deliver proven reliability with 15-year average life duration and TAA compliance. The mercury-free design and Green Premium product status demonstrate environmental responsibility, while the bolt-on mounting and pressure plate connections ensure professional installation standards for long-term performance.

Manufacturer Resources

Product Specs

Ambient Air Temperature For Operation:
40 °C
Average Life Duration:
15 year(s)
China Rohs In Scope:
No
Circuit Breaker Application:
not rated
Circularity Profile:
ENVEOLI2212005
Compliance:
TAA
Country Of Origin:
Mexico
Device Type:
LV equipment - Low voltage circuit breaker
Electrical Connection:
pressure plate
End Of Life Doc Ref:
ENVEOLI2212005
Energy Efficiency Optimized:
FALSE
Environmental Disclosure:
ENVPEP2212005
Eoli Availability Display:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Field Service Division:
PPIBS
Function Option:
Standard
Green Premium Status For Reporting:
Green Premium product
H And D Domain:
Safety
H And D Enrichment Assignment:
yes
H And D Enrichment Class 3:
Earth leakage protection devices
H And D Enrichment Class 4:
GFCI
H And D Enrichment Function:
GFCI
Legacy Weee Scope:
In
Market Segmentation:
Commercial
Mercury Free:
Yes
Mounting Mode:
bolt-on
Number Of Spaces Required:
2
Packaging Made With Recycled Cardboard:
No
Packaging Without Single Use Plastic:
Yes
Poles Description:
2P
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Depth:
2.91 in
Product Height:
4.13 in
Product Or Component Type:
miniature circuit-breaker
Product Width:
1.5 in
Range Of Product:
QO
Reach Full Compliance Status:
Reference contains Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
2532
Rohs Exemption Information:
Yes
Serviceability:
No
Sustainable Packaging:
No
Take Back:
No
Tier:
1
Total Lifecycle Carbon Footprint:
41 kg CO2 eq.
Traceability:
No
Use Carbon Footprint:
37.375
With Recycled Cardboard:
No
Without Single Use Plastic:
Yes
Department:
Electrical
Product Type:
Miniature Circuit-Breaker
Product Group:
Circuit Breakers

Schneider QOB230GFI – Frequently Asked Questions

1) Will a Schneider QO bolt-on GFCI breaker fit my plug-on QO load center?
No. The QO GFCI breaker here is a bolt-on device, meaning it fastens mechanically to the bus rather than clipping on. Bolt-on breakers go in QO panelboards prepped for bolt-on mounting (the QOB style), not in plug-on QO load centers. If your panel takes plug-on breakers, you need the plug-on QO GFCI version instead.
2) How much panel space does a 2-pole QO GFCI breaker take up?
Two spaces. The 2-pole QO GFCI occupies 2 poles in the panel, and the breaker body measures 4.13 in high, 2.91 in deep and 1.5 in wide. Count two open adjacent spaces on the same phase pair before you plan the install.
3) Is 10kA interrupting capacity enough for my commercial panel?
The QO 2-pole GFCI interrupts fault currents up to 10,000 amperes. That covers most branch-circuit positions in commercial and multi-family panels, but if your available fault current at the panel exceeds 10kA (common close to a large service transformer), you need a higher AIC device. Check the short-circuit current study or the panel label before you commit.
4) Does this QO GFCI breaker protect people or just equipment?
It is a GFCI, classified as an earth leakage protection device, so it trips on ground fault current to guard against shock hazard, and it also provides normal overcurrent protection for the branch circuit. It is not an AFCI, so it does not detect arcing faults. If your circuit needs arc-fault protection, you need a different breaker.
5) What amperages does the Schneider QOB 2-pole GFCI breaker come in?
Two ratings are offered: 20 A as QOB220GFI and 30 A as QOB230GFI. Both are 2-pole bolt-on GFCI devices rated 120/240VAC with 10kA interrupting capacity. Size the breaker to the branch circuit conductor, not to the load's nameplate alone.
6) What kind of wire terminations does this breaker use, and does it need a neutral?
Terminations are pressure plate connections on the line/load side. As a 2-pole GFCI it lands both hot conductors and also requires the circuit neutral to be landed on the breaker, with the breaker's own pigtail going to the panel neutral bar. That neutral routing is what makes GFCI sensing work, and getting it wrong is the usual cause of nuisance tripping on install.
7) Can I use this breaker in a hot mechanical room or outdoor panel?
Operating ambient is rated to 40 degrees C. Above that, thermal-magnetic breakers begin to trip at less than their marked rating, so a panel in an unventilated attic, boiler room or sun-exposed enclosure can cause nuisance trips. Keep the enclosure ambient within the 40 C figure or derate the circuit.
8) Does the Schneider QOB GFCI breaker meet TAA requirements for a government job?
Yes, it is listed as TAA compliant, with country of origin Mexico, which is a TAA designated country. That makes it usable on federal and other TAA-restricted procurement. It also carries Schneider's Green Premium status and is mercury free, which helps on sustainability-scored bids.
9) Can a tripped QO GFCI breaker be repaired or rebuilt?
No. The QO GFCI is a non-serviceable sealed device, so a breaker that fails its test button or will not reset gets replaced, not opened. For MRO planning, Schneider lists an average life duration of 15 years, so on long-lived panels budget replacement rather than repair.
10) Do I need environmental documentation for this breaker on a LEED or ESG reporting job?
Schneider publishes an environmental profile (ENVPEP2212005) and an end-of-life instruction reference (ENVEOLI2212005) for this QO GFCI, and states a total lifecycle carbon footprint of 41 kg CO2 eq. RoHS status is compliant with exemptions, and the REACH declaration notes the reference contains Substances of Very High Concern above the threshold, which some specs require you to disclose. Packaging is free of single-use plastic.
How fast can I get the Schneider QOB230GFI delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Schneider QOB230GFI come with a warranty?
Absolutely. The Schneider QOB230GFI is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Schneider QOB230GFI?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
