Steel City 1 Inch Insulated Ground Bushing for Rigid/IMC Conduit - Zinc Die Cast
Professional grounding solution for rigid and IMC conduit installations
Steel City delivers reliable electrical grounding with this 1 inch insulated ground bushing, engineered for rigid and IMC conduit applications. Constructed from durable zinc die cast material, this professional-grade bushing provides secure grounding connections while maintaining electrical isolation where required in commercial and industrial installations.
Professional Features & Benefits
- 1 Inch Size: Accommodates standard 1 inch rigid and IMC conduit for versatile installation compatibility
- Zinc Die Cast Construction: Provides exceptional durability and corrosion resistance for long-term performance
- Insulated Design: Maintains electrical isolation while enabling proper grounding connections
- Rigid/IMC Compatibility: Engineered specifically for rigid and intermediate metallic conduit systems
- Professional Grade: Meets demanding commercial and industrial electrical installation requirements
- Steel City Quality: Trusted brand reliability for critical electrical infrastructure applications
Technical Specifications
- Departmetn: Electrical
- Material: Zinc Die Cast
- Number Of Batteries: 0
- Product Group: Conduit & Fittings
- Product Size: 1 Inch
- Product Subgroup: Bushings
- Product Type: Insulated Ground Bushing
- Product Type2: Insulated Ground Bushing
Professional Applications
- Commercial Building Electrical Systems
- Industrial Facility Conduit Installations
- Institutional Electrical Infrastructure
- Multi-Unit Residential Properties
- Professional Office Buildings
- Retail and Service Establishments
- Educational and Healthcare Facilities
Why Choose Steel City Quality?
Steel City insulated ground bushings deliver the professional reliability and durability required for critical electrical installations. The zinc die cast construction ensures long-lasting performance while the insulated design provides the electrical isolation necessary for safe and compliant grounding connections in demanding commercial and industrial environments.
Manufacturer Resources
Product Specs
- Product Group:
- Grounding & Bonding
- Product Type:
- Grounding Bushing
- Product Material:
- Zinc Die Cast
- Number Of Batteries:
- 0
- Department:
- Electrical
- Product Type2:
- Insulated Ground Bushing
- Product Subgroup:
- Grounding & Bonding
Steel City BG801L – Frequently Asked Questions
1) What trade sizes do Steel City BG801L insulated grounding bushings come in?
The Steel City insulated grounding bushing line runs from 1/2 inch through 3-1/2 inch trade size: 1/2 in (BG801L), 3/4 in (BG802L), 1 in (BG803L), 1-1/4 in (BG804L), 1-1/2 in (BG805L), 2 in (BG806L), 2-1/2 in (BG807L), 3 in (BG808L) and 3-1/2 in (BG809L). Order by the conduit trade size, not the outside diameter of the pipe.
2) Will a Steel City grounding bushing thread onto EMT?
No. These bushings are threaded for rigid and intermediate metallic conduit (IMC), which carry male NPT threads on the end. EMT is not threaded, so a run of EMT entering a box or enclosure needs an EMT connector with a grounding lug instead, or a threaded fitting ahead of the bushing.
3) What does the insulated throat on a grounding bushing actually do?
It protects the conductors. The plastic insulating liner sits in the throat where the wire turns out of the conduit, so the pulled conductors bear on plastic rather than a metal thread edge. The bushing body itself still bonds the conduit and carries a lug for the equipment grounding conductor, so you get the bond and the wire protection in one fitting instead of a separate bushing and insulator.
4) Does the grounding bushing come with the bonding jumper wire?
No wire is included. The bushing supplies the lug; you provide the bonding jumper and size it to the circuit per code for the equipment grounding conductor. Plan on a lug screw termination at the bushing and a landing point on the enclosure ground bus or a bonding screw.
5) I'm replacing a grounding bushing on 2 inch rigid conduit. Which part number do I order?
For 2 inch rigid or IMC, order BG806L. Match the trade size stamped on the conduit or read it off the existing fitting; if the run is 2-1/2 inch it's BG807L, and 1-1/2 inch is BG805L.
6) Is a zinc die cast grounding bushing suitable for a damp industrial environment?
Zinc die cast is the body material on these bushings, and it holds up well indoors and in the damp, corrosion-prone conditions found in plant rooms and industrial facilities. For an aggressive chemical wash-down or a marine setting, spec a fitting rated for that exposure. Typical use here is commercial building and industrial conduit work, institutional infrastructure, and multi-family properties.
