.5 INCH CONN,LT FLEX METAL,DC,INSUL
Manufacturer Resources
Product Specs
- Product Group:
- Conduit & Fittings
- Selling Unit Of Measure:
- each
- Connection Type:
- Threaded
- Product Material:
- Zinc Die Cast
- Department:
- Electrical
- Country Of Origin:
- India (IN)
- Standards:
- UL e23018
- Product Type2:
- Connectors-Straight
- Product Type:
- Liquid tight connectors
Steel City LT 800 – Frequently Asked Questions
1) What sizes does the Steel City LT straight liquidtight connector come in?
Five ordering choices: LT 800 covers 3/8 inch (1/2 inch trade), LT 801 is 1/2 inch, LT 802 is 3/4 inch, LT 803 is 1 inch, and LT804 is the 1 inch straight. Each is sold individually, not by the bag or carton, so you can order exact counts per box or panel.
2) Will this connector work with liquidtight flexible metal conduit, or is it for the nonmetallic type?
It is built for liquidtight flexible metal conduit (LFMC). The Steel City LT straight connector is a die cast zinc body with the sealing gland and insulated throat used on flex metal whips. If you are running liquidtight nonmetallic flex, that takes a fitting listed for LFNC instead.
3) Is the throat insulated so I can pull THHN without nicking the insulation?
Yes, the LT straight connector has an insulated throat, which is what protects conductor insulation as wire is pulled through the fitting. That is the version electrical inspectors expect on whips feeding motors and rooftop units.
4) How does this connector attach to a box or enclosure?
It is a threaded fitting, so the male hub goes through the knockout and is secured with a locknut on the inside. Trade size matches the conduit size you order, 3/8 through 1 inch.
5) Why does the 3/8 inch connector list 1/2 inch beside it?
LT 800 is the 3/8 inch conduit size with a 1/2 inch trade thread, so it lands in a standard 1/2 inch knockout while accepting 3/8 inch liquidtight flex. That is the common combination on small motor and fixture whips.
6) Is a zinc die cast liquidtight connector suitable for outdoor or wash-down use?
The body is zinc die cast, the standard material for liquidtight fittings used in damp and wet locations where the gland seals the conduit jacket. For highly corrosive or chemical wash-down areas, buyers typically step up to a nonmetallic or stainless alternative rather than die cast.
How fast can I get the Steel City LT 800 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Steel City LT 800 come with a warranty?
Absolutely. The Steel City LT 800 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Steel City LT 800?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
