Thomas & Betts #2 AWG Copper Compression Lug with 3/8" Bolt - Standard Barrel Tin-Plated

Thomas & Betts #2 AWG Copper Compression Lug with 3/8" Bolt - Standard Barrel Tin-Plated

(No reviews yet) Write a Review

Model: 54143-TB
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$66.81
$7.47
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Thomas & Betts #2 AWG Copper Compression Lug with 3/8" Bolt - Standard Barrel Tin-Plated

Professional electrical connection hardware for reliable conductor termination

Thomas & Betts delivers professional-grade electrical connection solutions with this #2 AWG copper compression lug featuring a standard barrel design and tin-plated finish. This single-hole compression lug accommodates 3/8" bolt connections and provides reliable conductor termination for electrical installations. The copper construction with tin-plated finish ensures optimal conductivity and corrosion resistance for long-term performance.

Professional Features & Benefits

  • #2 AWG Wire Capacity: Accommodates #2 AWG conductors for versatile electrical connection applications
  • Copper Construction: Provides excellent electrical conductivity and mechanical strength for reliable connections
  • Tin-Plated Finish: Enhances corrosion resistance and maintains optimal electrical contact over time
  • Standard Barrel Design: Ensures consistent compression and proper conductor seating for secure terminations
  • 3/8" Bolt Compatibility: Single hole design accommodates standard 3/8" bolts for secure mounting
  • RoHS Compliance: Meets environmental standards for safe use in electrical installations
  • Peep Hole Feature: Allows visual verification of proper conductor insertion during installation

Technical Specifications

  • B Inches: 0.8
  • Barrel Length: Standard
  • Barrel Shape: Standard
  • Department: Electrical
  • Die Code: 33
  • Die Color: Brown
  • E Inches: 0.41
  • F Inches: 0.375
  • Hole Shape: Round
  • Inner Package: 25
  • Marking: Standard
  • Material: Copper
  • Number Of Studs: 1
  • Outer Package: 250
  • Package Height: 4
  • Package Length: 12.5
  • Package Width: 6.4
  • Peep Hole: Y
  • Product Finish: Tin-Plated
  • Product Group: Hardware
  • Product Subgroup: Bolts
  • Rohs Compliance: Yes
  • Stud Size: 8-Mar
  • T B Sold In Uom: Each
  • T B Weight Per Uom: 3.13 lbs. per 100
  • Tongue Angle: Straight
  • Tongue Width: Standard
  • Wire Size: #2 AWG

Professional Applications

  • Electrical panel connections and bus bar terminations
  • Motor control centers and switchgear installations
  • Industrial equipment grounding and bonding
  • Commercial electrical distribution systems
  • Transformer and generator connections
  • Electrical service entrance applications

Why Choose Thomas & Betts Quality?

Thomas & Betts compression lugs deliver reliable electrical connections with RoHS compliant construction and tin-plated finish for enhanced durability. The standard barrel design and peep hole feature ensure proper installation verification, while the copper material provides optimal conductivity for professional electrical applications.

Manufacturer Resources

Product Specs

B Inches:
0.8
Barrel Length:
Standard
Barrel Shape:
Standard
E Inches:
0.41
F Inches:
0.375
Hole Shape:
Round
Inner Package:
25
Marking:
Standard
Number Of Studs:
1
Outer Package:
250
Package Height:
4
Package Length:
12.5
Package Width:
6.4
Peep Hole:
Y
Product Group:
Wire Connectors & Terminals
Rohs Compliance:
Yes
Stud Size:
8-Mar
T B Sold In Uom:
Each
T B Weight Per Uom:
3.13 lbs. per 100
Tongue Angle:
Straight
Tongue Width:
Standard
Wire Size:
#2 AWG
Department:
Electrical
Product Subgroup:
Lugs & Terminals
Product Finish:
Tin-Plated
Product Material:
Copper
Product Die Color:
Brown
Product Die Code:
33
Product Type:
Compression Lug

Thomas & Betts 54143-TB – Frequently Asked Questions

1) Will the Thomas & Betts 54143-TB lug take #2 AWG copper wire only, or can I use it on a smaller conductor?
The 54143-TB is built for #2 AWG copper. It's a compression lug, so the barrel is sized to one conductor and crimped with the matching die; putting a smaller conductor in it won't give you a proper compression. For a smaller wire, order the lug made for that AWG size.
2) What die do I need to crimp the T&B 54143-TB compression lug?
Set your compression tool to die code 33, which T&B color-codes brown. Use that die index and you'll get the correct crimp on the standard barrel; a mismatched die is the usual cause of a loose or over-compressed termination.
3) How can I tell the conductor is fully seated before I crimp this lug?
There's a peep hole in the barrel. Push the stripped conductor in until you can see copper through the hole, then crimp. That visual check is why inspectors like these on service and switchgear work.
4) Is a tin-plated copper lug okay for outdoor or damp electrical enclosures?
The tin plating over copper is there for corrosion resistance and to keep the contact surface clean over time, which is what you want in damp or dusty environments and at aluminum bus interfaces. The base metal is copper, so use it on copper conductors.
5) How are these #2 AWG T&B lugs packaged if I'm buying for a full job?
Sold each, with 25 to an inner pack and 250 in the outer carton. Shipping weight runs 3.13 lbs per 100 pieces, useful if you're quoting freight on a full 250-count box.
6) Is this T&B compression lug RoHS compliant for a government or institutional spec?
Yes, the 54143-TB is RoHS compliant, and the barrel carries standard T&B marking for wire size and die code so an inspector can verify the crimp after the fact.
