Spec Sheet
Product Specs
- Hub Size:
- 1-1/2 Inch
- Inner Quantity:
- 1
- Outer Dimensions Inches:
- 17.25x10x6.37
- Outer Quantity:
- 10
- Product Group:
- Conduit & Raceway
- Standards:
- CSA
- Unspsc:
- 39131708 Electrical conduit fitting body
- Weight Uom:
- 109 lbs. per 100
- Department:
- Electrical
- Product Subgroup:
- Conduit Bodies & Covers
- Product Type:
- Type T Conduit Body
- Product Details:
- Rigid Conduit
- Product Material:
- Cast Aluminum
Thomas & Betts CITA-1 1/2 – Frequently Asked Questions
1) Is a Type T conduit body the right choice, or should I use an LB or C body?
The CITA-1 1/2 is a Type T body, which gives you a three-opening tee: conduit in line plus one branch at 90 degrees. Use it where a run has to split or where you need a pull point with a branch feed. If you only need to turn the run into a wall or around a corner, an LB or LL/LR is the right body; if you just want a straight pull point, a Type C is the simpler fitting.
2) What is the CITA-1 1/2 conduit body made of, and can I use it outdoors?
Cast aluminum. That makes it suitable for exposed and damp outdoor rigid conduit runs where you want a non-ferrous body that will not rust, and it is the usual pairing with aluminum rigid conduit. Avoid direct contact with dissimilar metals in corrosive or marine environments, and for a cementitious or high-chloride location specify a PVC-coated or iron body instead.
3) Does the CITA-1 1/2 conduit body come with a cover and gasket?
The CITA-1 1/2 is the conduit body itself, a cast aluminum Type T. Covers and gaskets for conduit bodies are ordered separately in most Thomas & Betts lines, so if the opening needs to be closed off, add a cover sized to a 1-1/2 inch Form body plus the gasket if the location is damp or wet.
4) Is the Thomas & Betts CITA-1 1/2 certified for Canadian work?
CSA is the standard listed for the CITA-1 1/2, so it is recognized for Canadian installations. That is the only certification carried on the record for this body.
5) What exact part number should I put on the purchase order for this 1-1/2 inch aluminum tee body?
Order it as Thomas & Betts CITA-1 1/2. That is the manufacturer part number for the 1-1/2 inch cast aluminum Type T conduit body, UPC 062253881165. Distributors cross-referencing it will find it under UNSPSC 39131708, electrical conduit fitting body.
