WAC Lighting Charge 8010 LED Adjustable Track Head, 5-CCT Selectable, 9W
The WAC Lighting Charge 8010 is a compact LED track head engineered for superior light output in a small, unobtrusive housing. Built with solid die-cast aluminum construction and a frosted TIR lens, this 9W fixture delivers 865 delivered lumens at 90+ CRI with 5-CCT selectable color temperature (2700K-3000K-3500K-4000K-5000K), making it ideal for residential spaces and lower-mounted commercial applications. A 45 degree flood beam optic and full 350 degree horizontal / 90 degree vertical aiming range let you place light exactly where it is needed. ETL and cETL listed for dry locations, the Charge 8010 is available in H, J, and L style track compatibility to match your existing system.
Key Features
- Durable Construction: Solid die-cast aluminum housing with a frosted TIR lens for even, bright illumination with reduced glare.
- Adjustable Aiming: 350 degree horizontal and 90 degree vertical aiming lets you direct light precisely where needed.
- 45° Flood Beam Optics: Beam spread suitable for both accent lighting and general ambient illumination.
- Track Compatibility: Available in H-style (3-wire) and J or L style (2-wire) track systems; order the style that matches your existing track.
- High-Powered LED Engine: 9W, 865 delivered lumens, 90+ CRI, and 50,000 rated hours (LM-70) for long, high-quality service life.
- 5-CCT Selectable Color Temperature: Choose from 2700K, 3000K, 3500K, 4000K, or 5000K to match the space.
- Smooth Dimming: Compatible with ELV or TRIAC (standard LED/CFL) dimmers, dimming down to 10%.
- Dry Location Rated: Suitable for dry-location residential and lower-mounted commercial installations.
Certifications & Compliance
- ETL & cETL Listed (UL #1598) for Dry Locations
- Energy Star 2.0 Certified
- Title 24 JA8-2016 Compliant
- Title 20 Compliant
- ADA Compliant
Technical Specifications
- ADA Compliant: Yes
- Bulb Base: LED Module - Driver
- Bulb Shape: LED Module
- Bulbs Included: Yes
- Dimmable: ELV;TRIAC
- Energy Star: Yes
- Hardwired or Portable: Plugin
- Number of Bulbs: 1
- Safety Rating: ETL, cETL
- Shade/Glass Description: Clear Glass Lens
- Warranty: 5 Years Functional, 2 Years Finish
- Subcategory: Integrated LED Track Head
- Avg Rated Hours: 50000
- Beam Spread: 45
- Voltage: 120
- Country of Origin: Thailand
- Location Rating: Dry
- Color Temperature: 2700-3000-3500-4000-5000
- Style: Modern;Transitional
- Mounting: Ceiling/Wall;Any
Typical Applications
- Residential Accent and Ambient Lighting
- Lower-Mounted Commercial Track Lighting
- Retail Display and Gallery Lighting
- Track Systems Using H, J, or L Style Compatibility
- Dimmable LED Lighting with ELV or TRIAC Controls
Why WAC Lighting?
WAC Lighting builds the Charge 8010 with solid die-cast aluminum construction and a frosted TIR lens for reliable, glare-controlled performance in dry-location settings. Backed by ETL and cETL listing, Energy Star 2.0 certification, and a 5-year functional / 2-year finish warranty, this track head is engineered for code-compliant, long-term performance in professional lighting installations.
Manufacturer Resources
Specification Sheet
Product Specs
- ADA Compliant:
- Yes
- Bulb Base:
- LED Module - Driver
- Bulb Shape:
- LED Module
- Bulbs Included:
- Yes
- Collection:
- Charge
- Dimmable:
- ELV;TRIAC
- Energy Star:
- Yes
- Hardwired or Portable:
- Plugin
- Number of Bulbs:
- 1
- Safety Rating:
- ETL, cETL
- Shade/Glass Description:
- Clear Glass Lens
- Subcategory:
- Integrated LED Track Head
- Avg Rated Hours:
- 50000
- Beam Spread Angle:
- 45
- Product Voltage:
- 120
- Product Material:
- Aluminum
- Location Rating:
- Dry
- Light Temperature:
- 2700-3000-3500-4000-5000
- Product Style:
- Modern;Transitional
- Mounting Method:
- Ceiling/Wall;Any
- Department:
- Electrical
- Product Group:
- Lighting
- Product Subgroup:
- Light Fixtures
- Product Type:
- Track Lighting
WAC Lighting H-8010-CS-BK – Frequently Asked Questions
1) Which track type do I order for the WAC Charge 8010 head, H, J, or L?
Order the letter that matches the track already on the ceiling. The Charge 8010 is built as three separate heads: H-8010-CS for H-style 3-wire track, J-8010-CS for J-style 2-wire, and L-8010-CS for L-style 2-wire. The adapters are not interchangeable, so an H head will not seat in a J or L track. If you are unsure, pull an existing head and compare the contact arrangement in the adapter before ordering.
2) Can I set the color temperature on the Charge 8010 track head on site?
Yes. It is a 5-CCT selectable head, switchable between 2700K, 3000K, 3500K, 4000K, and 5000K, so one part number covers warm residential through neutral commercial. For a property manager standardizing across units, that means stocking a single head and matching whatever is already installed in each space rather than carrying five SKUs.
3) What dimmer works with the WAC Charge 8010 LED track head?
Use an ELV or TRIAC dimmer, which is the standard LED/CFL type. The head runs on 120V and dims smoothly down to 10 percent. It will not work on a 0-10V or DALI control, and a legacy magnetic low-voltage dimmer is the wrong class for it.
4) Can the WAC Charge 8010 go in a bathroom, over a shower, or on a covered porch?
No. It carries a Dry location rating only, ETL and cETL listed under UL 1598. Keep it out of shower zones, canopies, and anywhere exposed to moisture or condensation; those openings need a damp or wet rated fixture.
5) Is a 9W track head bright enough for retail display lighting?
At 865 delivered lumens with a 45 degree flood optic, the Charge 8010 suits residential accent work and lower-mounted commercial runs, retail display, and gallery lighting. On high ceilings the 45 degree spread washes out and loses punch on merchandise, so for tall retail you want a higher-output head with a narrower spot optic instead.
6) What finishes does the WAC Charge 8010 come in, and can I match existing bronze track?
Four finishes: Black, White, Brushed Nickel, and Dark Bronze. Brushed Nickel and Dark Bronze are offered on the H-style head; the J and L style heads come in Black and White. So matching dark bronze track means going with the H-style version.
7) Will the Charge 8010 render paint and merchandise colors accurately?
Yes, it is a 90+ CRI engine, which is the threshold gallery and retail specs usually call for on accent lighting. Combined with the selectable 2700K through 5000K range, you can tune both the color accuracy and the warmth to the finishes in the room.
