WAC Lighting L Track Flexible ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$37.95
WAC Lighting L Track Flexible Track Connector Track Component

WAC Lighting L Track Flexible Track Connector Track Component

(No reviews yet) Write a Review

Model: WAC-LFLX
From the L Track Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$37.95
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Modern Forms PD-W24216 Cambridge LED Outdoor Pendant

A classic sensibility with timeless style. This exterior LED pendant luminaire beckons like a glowing lantern to welcome guests to your fine home.
  • Extruded aluminum body with an etched acrylic diffuser framed in clear glass panels etched along the border, for clear and even illumination.
  • Cambridge is wet location listed - can be used indoor or outdoor. 10ft of wire included to extend pendant up to a total of 120in. Includes 1x6in and 3x12in extension rods. Additional rods can be purchased separately for longer lengths.
  • Universal Input Voltage Driver (120V-240V-277V) concealed in fixture.
  • Smooth and continuous dimming with an electronic low voltage (ELV) or TRIAC dimmer.
  • High Powered Replaceable LED Module CRI: 90, Rated Hours: 50,000, Color Temp: 3000K
  • Standards: ETL & cETL UL 1598 listed for Wet Locations. CEC Title 24 Compliant. Replacement Downrods: RPL-ROD-OUT06-BK, RPL-ROD-OUT12-BK

Manufacturer Resources

Product Specs

ADA Compliant:
No
Backplate Depth:
1.63"
Backplate Height:
0.75"
Backplate Width:
11"
Collection:
L Track
Complete System:
No
Energy Star:
No
Hardwired or Portable:
Hardwired
Location Rating:
Dry
Product Type:
Track Component
Safety Rating:
UL, cUL
Subcategory:
Track Connector
Base Material:
Aluminum
Location Indoor/ Outdoor:
Interior
Max Height:
0.75"
Reversible Mounting:
No
Title 24 Compliant:
No
Segment:
Lighting
SORTME:
1329
Product Voltage:
120
Product Length:
11"
Product Style:
Functional
Product Height:
0.75"
Product Category:
Track Lighting
Product Width:
1.63"

WAC Lighting WAC-LFLX – Frequently Asked Questions

1) Will the LFLX connector work with 277V track or only 120V?
120 volts. The LFLX is rated for 120V L Track, so it is not the part for a 277V run in a commercial space. If the drawing calls for 277V track, specify track and components rated for that voltage instead. It is a hardwired component, not something that plugs in.
2) Can I use this WAC track connector outdoors or in a covered patio or bathroom?
No. The LFLX carries a Dry location rating and is listed for interior use, so keep it out of damp and wet locations, including covered exterior soffits, open porches and shower areas. For anything exposed to moisture you need a fixture and system rated damp or wet.
3) How much ceiling space does the WAC L Track flexible connector take up?
The connector measures 11 inches long, 1.63 inches wide and 0.75 inches high, and the backplate matches those figures at 11 inches wide, 1.63 inches deep and 0.75 inches high. That 11 inch length is the span you need to allow between the two track sections it joins, so lay out the run with that gap accounted for. Its 0.75 inch height keeps it close to the ceiling plane, in line with the track profile.
4) What finishes does the WAC LFLX flexible track connector come in, and can I match it to my existing track?
Three finishes: Black (LFLX-BK), Brushed Nickel (LFLX-BN) and White (LFLX-WT). Order the one matching the L Track sections already installed so the joint does not stand out. Black and White are the common ceiling matches; Brushed Nickel suits retail and residential runs finished to match the heads.
5) Is the WAC LFLX track connector UL listed for a commercial job?
It carries UL and cUL safety listings, which covers both US and Canadian installs. It is not Energy Star rated and not CEC Title 24 compliant, and it is not ADA compliant, so if your project has a Title 24 or ADA requirement on the lighting package, that has to be met by the fixtures and controls rather than by this connector.
6) Can I mount the LFLX connector either way up on the track?
No, it is not a reversible mounting component. It installs in one orientation, so set the track polarity and the connector direction before you fix anything, particularly on a run that turns and comes back on itself.
7) What is the WAC flexible track connector made of, and will it hold up in a retail space?
Aluminum body, same material family as the track extrusion it joins, which keeps weight down on a ceiling-mounted run and resists corrosion in conditioned interior space. For a retail or gallery install on dry interior ceilings that is the appropriate build; it is not intended for exterior or damp environments.
