Metallics JFMP47 10-32 x 3/8 in. Flat Head Phillips Machine Screws - Steel Zinc - 100qty

Metallics JFMP47 10-32 x 3/8 in. Flat Head Phillips Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JFMP47
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.20
$0.20
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10-32 x 3/8 in. Flat Head Phillips Machine Screws - Steel Zinc - 100qty

  • Features

    • Zinc yellow screws are popular in electronics applications.
    • Steel Zinc Material
    • Flat head with Phillips Drive
    • 10-32 Diameter, 3/8" Length

  • Additional Notes

    • Other sizes and quantities available by request | Hardness and tensile strength standards are offered as guides only for stainless machine screws. There is currently no national standard for these performance requirements for stainless machine screws.

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-1998
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.098 - 0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.333 - 0.362 in.
Fastener Length:
8-Mar
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Gaging Diameter:
0.313
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Mach_Screw.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.124
Phillips Recess Diameter:
0.198
Phillips Recess Width:
0.032
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.4 lbs
Product Width:
3 in
Protrusion Gaging Diameter:
0.025 - 0.042 Above
Sub Division:
Electrical-E H2
Tensile Strength:
1200 lb minimum
Thread Per Inch:
32
Thread Standard:
ANSI/ASME B1.1
Thread Type:
UNF
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
FM and FMP
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JFMP47 – Frequently Asked Questions

1) Will a 10-32 x 3/8 in. machine screw thread into a standard electrical box or device ring?
The Metallics JFMP47 is a 10-32 UNF machine screw at 32 threads per inch, cut to the ANSI/ASME B1.1 thread standard. 10-32 is the thread used on standard electrical outlet boxes, device mounting ears, plaster rings and cover plates, so it mates with those tapped holes. At 3/8 in. long it is the short length used for mounting devices and covers, not for deep standoffs or spacers.
2) Will a flat head Phillips machine screw sit flush in a countersunk hole?
Yes, that is what the flat head is for. The JFMP47 head measures 0.333 to 0.362 in. across with a head height of 0.098 to 0.116 in., built to ASME B18.6.3-1998, so it seats flush in an 82 degree countersink of matching diameter. If the hole is not countersunk, the head will stand proud and you want a pan or round head instead.
3) Do these screws meet Buy American or ARRA requirements for a government job?
No. The JFMP47 is not Buy American compliant and is not ARRA compliant, and country of origin is listed as multiple. If your contract carries a domestic sourcing clause, these will not qualify.
4) What size Phillips bit drives these 10-32 screws?
A #2 Phillips. The recess on the JFMP47 is 0.198 in. in diameter and 0.124 in. deep, which is the standard #2 Phillips geometry. Running a #1 will cam out and chew the recess; a #3 will not seat.
5) How do these zinc plated steel machine screws hold up outdoors or in damp locations?
These are low carbon steel (AISI 1006 to 1022) with a zinc plated finish. Zinc plating is a mild corrosion barrier meant for dry interior service, so it suits panel work, device mounting and indoor MRO. For wet locations, exterior work or washdown areas, specify a stainless machine screw of the same 10-32 x 3/8 size instead.
6) How strong is a 10-32 steel machine screw like this, and can I use it structurally?
The JFMP47 is rated to 1,200 lb minimum tensile with a hardness of Rockwell B70 to B100. That is ordinary low carbon commercial fastener strength, good for mounting devices, covers, panels and brackets. It is not a graded structural bolt, so do not substitute it where a drawing calls for a Grade 5 or Grade 8 fastener.
7) How are these Metallics machine screws packaged and what is the smallest quantity I can buy?
They ship in a jar of 100, which is also the order minimum, at roughly 0.4 lbs per jar. That is the stocking quantity for a van or a shop drawer rather than a single-piece pick.
8) What trades use 10-32 flat head machine screws like the JFMP47 most?
Metallics lists field application as the electrical, plumbing, heating and air conditioning industries. In practice that means device and cover mounting, control panel assembly, equipment enclosures and sheet metal brackets where a tapped 10-32 hole already exists. The zinc yellow finish is also common in electronics work.
