Metallics JSPMP30SS 10-32 x 3/8 in. Pan Head Phillips Machine Screws - 18-8 Stainless - 100qty

Metallics JSPMP30SS 10-32 x 3/8 in. Pan Head Phillips Machine Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JSPMP30SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.36
$0.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10-32 x 3/8 in. Pan Head Phillips Machine Screws - 18-8 Stainless - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

  • Features

    • 10-32 Diameter, 3/8" Length
    • 18-8 Stainless Material
    • Pan head with Phillips Drive

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
8-Mar
Hardness:
Rockwell BBS-B9S
Language Code:
EN
Material Standard:
SAE
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Head_Screw_St_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.53 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Sub Division:
Electrical-E H2
Tensile Strength:
80000 psi minimum
Thread Per Inch:
32
Thread Type:
UNF
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
SPMP
Product Details:
Machine Screw
Product Material:
18-8 Stainless

Metallics JSPMP30SS – Frequently Asked Questions

1) How much clearance does the pan head take up, and will it sit flat under a cover plate?
Pan head, with a head width of 0.357 to 0.373 in. and head height of 0.122 to 0.133 in. That means roughly an eighth of an inch standing proud of the surface, which clears under most device plates but will not sit flush. If you need flush, use a flat head screw with a countersunk hole instead.
2) Do these Metallics machine screws meet Buy American and ARRA requirements for a public project?
Both the Buy American and ARRA compliance flags on the JSPMP30SS are marked compliant, which is what a government, school or municipal submittal package usually asks for on fasteners. Country of origin is listed as multiple.
3) What driver do I need for the Metallics JSPMP30SS machine screws?
A #2 Phillips bit. The recess is a Phillips with a 0.192 in. recess diameter and a gaging depth of 0.089 to 0.113 in., so a #2 tip seats fully. A #1 will cam out and chew the recess, especially in stainless.
4) Are these stainless screws suitable for outdoor or damp-location electrical work?
They are 18-8 stainless, the austenitic grade normally specified where plated steel would rust, so they hold up in wet, damp and coastal exterior work far better than zinc-plated machine screws. Note that 18-8 is non-magnetic and softer than hardened steel, so do not overdrive it.
5) What dimensional standard do these pan head Phillips screws conform to?
ASME B18.6.3-2010 governs the head and recess dimensions, with the material called out to SAE. That is the standard a spec writer looks for on a machine screw submittal, and it is why the head width and recess dimensions are given as tolerance ranges rather than single numbers.
6) How strong is an 18-8 stainless machine screw compared with a hardened steel one?
Tensile strength is given as 80,000 psi minimum with hardness in the Rockwell B range. Metallics states that tensile values for stainless screws are approximations because there is no single performance standard for stainless machine screws. For a structural or high-torque connection, a hardened steel fastener is the better call; for corrosion resistance on device and box mounting, stainless is why you are buying it.
7) How are these 10-32 stainless screws packaged and what is the minimum order?
They ship in a jar, with a minimum of 100 count. Packed weight is 0.53 lbs. Handy for a van or shop drawer rather than a loose bag.
