Metallics JFWP67SS 10 x 1-3/4 ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$385.71
Metallics JFWP67SS 10 x 1-3/4 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

Metallics JFWP67SS 10 x 1-3/4 in. Flat Head Phillips Wood Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JFWP67SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$385.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1-3/4 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

  • Features

    • Stainless wood screws are usually supplied without additional finish
    • Screws of nominal lengths too short to accomodate the minimum thread length shall have threads extending as close to the underside of the head as practicable.
    • Flat Head with Phillips Drive
    • 18-8 Stainless Material
    • 10 Diameter, 1-3/4" Length

  • Additional Notes

    • Other sizes and quantities available by request | Length of Thread: Length = 1 inch then 2/3 thread

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.1
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#3
Fastener Head Height:
0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.34 - 0.385 in.
Fastener Length:
1/3/04
Field Application:
Electrical, Plumbing, Heating, Air Conditioning Industries
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Wood_Screw_Steel_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.123 - 0.146
Phillips Recess Diameter:
0.245 - 0.258
Phillips Recess Width:
0.034
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
1.12 lbs
Product Width:
3 in
Screw Point Type:
Tapered Point
Sub Division:
Electrical-E H2
Thread Per Inch:
13
Thread Standard:
ASME B18.6.1-1997
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Wood Screw
Type2:
Wood Screw
Series:
JFWP
Product Details:
Wood Screw
Product Material:
18-8 Stainless

Metallics JFWP67SS – Frequently Asked Questions

1) How many screws come in a jar of Metallics JFWP67SS wood screws?
The JFWP67SS ships as a jar of 100 screws, and the jar is the minimum order quantity. If you need a different count or a different size in the same flat head Phillips stainless line, it's available by request.
2) Will 18-8 stainless wood screws hold up outdoors or in a damp location?
18-8 stainless is the corrosion-resistant choice for wet and exterior work, which is why these are supplied bare with no additional plating or finish. If you're fastening into treated lumber or working near the coast, stainless is what you want rather than a plain or zinc-plated steel wood screw.
3) What size Phillips driver bit do I need for a #10 Metallics flat head wood screw?
Use a #3 Phillips bit. The recess on these #10 screws runs 0.245 to 0.258 inch in diameter and 0.123 to 0.146 inch deep, so a #2 bit will sit shallow and cam out under torque.
4) Can I use the Metallics JFWP67SS on a federally funded job with Buy American requirements?
No. These screws are not Buy American compliant and not ARRA compliant, with country of origin listed as multiple. For a project with domestic sourcing requirements you'll need a domestically manufactured fastener instead.
5) Do these flat head screws sit flush in a countersunk hole?
Yes. The flat head measures 0.34 to 0.385 inch across with a 0.116 inch head height, so in a standard 82 degree countersink the head finishes flush with the surface. For strap, plate, or box mounting with a countersunk hole, that is the geometry you want.
6) Do I need to pre-drill for a #10 x 1-3/4 inch stainless wood screw?
Pre-drilling is a good idea. These are tapered point, 13 threads per inch wood screws, so the tapered body wants a pilot hole in hardwood or near an edge to avoid splitting. Stainless is softer than hardened steel and will twist off before it drives through dense material dry.
7) Are Metallics JFWP wood screws made to a dimensional standard I can spec?
They are built to ASME B18.6.1, with threads to ASME B18.6.1-1997. If a submittal or drawing calls for a B18.6.1 flat head Phillips wood screw, the JFWP67SS meets that callout.
8) How much does a jar of 100 Metallics JFWP67SS screws weigh?
A jar runs 1.12 lbs. Handy if you're pricing out freight or building a kit list for a truck stock order.
