3M 7010305769 3M, Heat Shrink ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$116.54
$66.54
3M 7010305769 3M, Heat Shrink Heavy-Wall Cable Sleeve ITCSN-1100, 9 in Length pieces, 3 pieces/pack, 12 packs/case

3M 7010305769 3M, Heat Shrink Heavy-Wall Cable Sleeve ITCSN-1100, 9 in Length pieces, 3 pieces/pack, 12 packs/case

(No reviews yet) Write a Review

Model: 7010305769
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$116.54
$66.54
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
3M, Heat Shrink Heavy-Wall Cable Sleeve ITCSN-1100, 9 in Length pieces, 3 pieces/pack, 12 packs/case

  • Features

    • IDEAL FOR A VARIETY OF APPLICATIONS: Used for insulating secondary splices; direct-buried, submersible, or dig in repairs; and physical protection of high voltage, air-insulated connectors or lugs
    • CERTIFICATIONS: UL Listed, CSA Certified, and RoHS 2011/65/EU Compliant
    • VOLTAGE: UL 486D, Voltage Rating 600 V; Applies to: ITCSN 0400, 0800, 1100, 1500, 2000; CSA Certified ITCSN 0400, 0800, 1100, 1500, 2000, 3000
    • WIDE OPERATING TEMPERATURE RANGE: Withstands temperatures between 67,230 °F (55,110 °C)
    • HIGHLY RESISTANT: Delivers mechanical and environmental protection against abrasion, corrosion, and chemicals
    • DURABLE CONSTRUCTION: Adhesive-lined, split resistant, fast shrinking, and made from cross-linked polyolefin; non-adhesive options are also available


7010305769 - spec sheet

Manufacturer Resources

Product Specs

Adhesive Lined:
Yes
Ais Url Article Information Sheet :
https://multimedia.3m.com/mws/mediawebserver?mwsId=SSSSSu9n_zu8l00xmY_GMxm94v70k17zHvu9lxtD7xtBevSS
Cable Size Range:
2-4/0 AWG
Country Of Origin:
United States
Dielectric Strength V Mil :
500 V/mil
Direct Bury:
Yes
Elongation Uom:
%
Etim Class 8 0:
EC000217
Expanded Inner Diameter:
1.1 in
Expanded Inner Diameter Metric :
27.9 mm
Flame Retardant:
No
Flammability Rating:
Non-Flame Retardant
Heat Shrink Type:
Adhesive-Lined Polyolefin Heat Shrink Tubing
Inner Diameter After Shrink Imperial :
0.37 in
Inner Diameter After Shrink Metric :
9.4 mm
Inner Diameter Before Shrink Imperial :
1.1 in
Inner Diameter Before Shrink Metric :
27.9 mm
Manufacturing Origin:
USA
Maximum Operating Temperature Celsius :
110
Maximum Operating Temperature Celsius Uom:
Degree
Maximum Operating Temperature Fahrenheit :
230.0 Degree
Maximum Voltage Rating:
1 kV
Minimum Expanded Tubing I D :
1.1 in
Minimum Shrink Temperature Celsius :
121
Minimum Shrink Temperature Fahrenheit :
250 °F
Non Corrosive:
Yes
Operating Temperature Celsius :
-55 to 100 Degrees Celsius
Operating Temperature Fahrenheit :
-67 °F to 230 °F
Operating Temperature Range Celsius :
-55 °C to -100 °C
Operating Temperature Range Fahrenheit :
-67 °F to 230 °F
Overall Length Imperial :
9.0 in
Overall Length Metric :
228.6 mm
Product Color:
Black
Product Material:
Polyolefin
Product Voltage:
1 kV
Rds Url Regulatory Data Sheet :
https://cdmsweb.3m.com/ingredientcommunication/file/Media/3oiRvIxw8vI=
Recovered Inner Diameter:
0.37 in
Recovered Inner Diameter Metric :
9.4 mm
Rohs Eu Comments:
RoHS 2011/65/EU compliant without exemption
Shelf Life:
3600
Shrink Ratio:
3:01
Solution For:
Access Network: FTTH/FTTB/CATV
Specifications Met:
UL 486D*
Splice Type:
Heat Shrink
Tensile Strength Imperial :
2400 Pound-Force Per Square Inch
Tubing Type:
Heavy Wall
Units Per Case:
3
Department:
Electrical

3M 7010305769 – Frequently Asked Questions

1) What cable size will the 3M ITCSN-1100 heat shrink sleeve fit?
The ITCSN-1100 covers 2 AWG through 4/0 AWG cable. It goes on at a 1.1 inch expanded inner diameter and recovers down to 0.37 inch, a 3:1 shrink ratio, so it grips a wide range of conductor and splice diameters within that band. If your splice bulge is larger than 1.1 inches going on, it won't slide over, so measure the widest point of the connector, not the cable.
2) Can 3M ITCSN-1100 sleeves be direct buried or used in a wet vault?
Yes. The ITCSN-1100 is rated for direct burial and the adhesive lining is what makes that work, it flows on heating and seals the ends against moisture. 3M lists it for direct-buried, submersible, and dig-in repair work, plus physical protection of high voltage air-insulated connectors or lugs. The material is non-corrosive to the conductor.
3) What voltage is the ITCSN-1100 cable sleeve rated for?
1 kV. The UL 486D listing on the ITCSN family carries a 600 V rating, and the sleeve itself is specified at 1 kV maximum with a dielectric strength of 500 V/mil. That puts it in secondary splice and service territory, not primary distribution insulation.
4) Is this 3M heat shrink sleeve flame retardant?
No. The ITCSN-1100 is a non-flame-retardant cross-linked polyolefin. If your spec or inspector calls for a flame retardant sleeve inside a building or in a plenum, this isn't the one. It's built for mechanical and environmental protection, abrasion, corrosion, and chemicals, in buried and outdoor work.
5) What temperature range can these buried splice sleeves take once installed?
Installed operating range is -67 F to 230 F (-55 C to 110 C at the top end), which covers outdoor conduit, buried duct, and unconditioned equipment rooms. Tensile strength is 2400 psi, so the wall holds up to backfill and pulling stress.
6) Is 9 inches of sleeve enough to cover my splice?
Each piece is 9 inches long (228.6 mm), so you need your connector plus enough overlap onto the jacket at both ends for the adhesive to seal. Rule of thumb on a buried secondary splice is at least an inch of clean, abraded jacket under each end. A compression connector on 4/0 typically leaves you plenty inside 9 inches; a long inline butt splice may not, and you'd step up to a longer ITCSN piece.
7) Does the 3M ITCSN-1100 meet UL and RoHS requirements for a spec job?
It's UL Listed under UL 486D, CSA Certified, and RoHS 2011/65/EU compliant without exemption. The CSA and UL coverage spans the ITCSN 0400, 0800, 1100, 1500 and 2000 sizes, so you can standardize across sizes on the same submittal. Made in the USA.
8) What is the difference between heavy-wall adhesive-lined sleeve and regular thin-wall heat shrink?
Heavy wall with an adhesive lining is the choice when the splice is going in the ground, in water, or anywhere it takes mechanical abuse. The thick polyolefin wall resists abrasion and split-out, and the adhesive seals the ends so water can't track down the conductor. Thin-wall tubing is for indoor strain relief and color coding and won't seal a buried joint. The ITCSN-1100 is the heavy-wall adhesive-lined type in black. 3M also offers non-adhesive versions of this sleeve where you don't need the moisture seal.
9) How many pieces come in a case of 3M 7010305769?
Part 7010305769 is packed 3 pieces per pack, 12 packs per case, so 36 sleeves in a full case. Useful if you're stocking a utility truck or an MRO crib rather than buying per splice.
