Spears PVC DWV 90° Low Heel Inlet Elbow, Hub x Hub x Hub

Spears PVC DWV 90° Low Heel Inlet Elbow, Hub x Hub x Hub

(No reviews yet) Write a Review

Model: P304-015

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4.65
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Spears PVC DWV 90° Low Heel Inlet Elbow, Hub x Hub x Hub

The Spears PVC DWV 90° Low Heel Inlet Elbow is a 1/4 bend fitting purpose-built for drain-waste-vent (DWV) plumbing systems, combining a 90° directional turn with a low heel inlet branch connection in a 3" x 3" x 2" configuration. Molded from durable PVC and finished with Hub x Hub x Hub (HxHxH) solvent-weld connections at all three ports, this fitting allows installers to redirect waste flow while tying in a secondary branch line without sacrificing drainage performance. Each carton ships with 25 pieces, making it a practical choice for stocking trucks and job sites on residential and commercial plumbing projects.

Key Features

  • Trade Size: 3" x 3" x 2" configuration for reducing DWV branch connections.
  • Durable Construction: PVC material provides corrosion resistance and long service life in drain-waste-vent applications.
  • 90° Low Heel Inlet Design: 1/4 bend geometry with a low heel inlet enables a secondary branch tie-in while maintaining proper waste flow direction.
  • Hub x Hub x Hub (HxHxH) Connections: Solvent-weld hub ports at all three openings for a secure, leak-resistant joint.
  • Job-Site Packaging: Supplied 25 each per carton for efficient stocking and installation planning.
  • Lightweight PVC Body: Easy to handle and cut on-site compared to metallic drainage fittings.

Technical Specifications

  • Product Type: Elbow
  • Department: Plumbing
  • Product Group: PVC & CPVC Fittings
  • Material: PVC
  • Connection: Hub x Hub x Hub (HxHxH)
  • Configuration: 3" x 3" x 2" 90° Low Heel Inlet 1/4 Bend
  • Packaging: 25 each per carton

Typical Applications

  • Drain-Waste-Vent (DWV) Piping Systems
  • Residential and Commercial Plumbing Installations
  • Branch Line Connections Requiring a Directional Change
  • New Construction Plumbing Rough-In
  • Plumbing Renovation and Repair Projects

Why Spears?

Spears PVC DWV fittings are engineered for dependable, code-compliant performance in demanding drain-waste-vent applications. The corrosion-resistant PVC body and precise Hub x Hub x Hub solvent-weld connections help ensure a tight, long-lasting joint at every port, while the 90° low heel inlet design gives installers flexibility to combine a directional turn with a branch connection in a single fitting. Choose Spears for reliable PVC DWV fittings built for professional plumbing installations.

Product Specs

Product Type:
Elbow
Department:
Plumbing
Product Group:
PVC & CPVC Fittings
Product Material:
PVC
Connection Type:
Hub
Configuration:
90° Low Heel Inlet
Product Size:
3" x 3" x 2"
Product Subgroup:
Pipe Fittings

Spears P304-015 – Frequently Asked Questions

1) What is a low heel inlet elbow used for in a DWV system?
A low heel inlet elbow is a 1/4 bend that turns waste flow 90 degrees and carries a separate branch port cast into the heel of the bend, so you pick up a secondary line (a lavatory or a vent tie-in, for example) without adding a second fitting and a length of pipe between them. The Spears PVC DWV version does this in a 3 x 3 x 2 inch configuration: the two 3 inch ports carry the run, the 2 inch heel inlet takes the branch. If you do not need the branch, a plain 1/4 bend is the fitting to order instead. If the branch needs to enter on the back of the bend rather than the heel, that is a high heel inlet, which is a different part.
2) Does the Spears low heel inlet elbow use solvent weld or gasketed connections?
All three ports are hubs for solvent welding, so it goes together with PVC primer and cement, not gaskets and not threads. That means the fitting accepts plain-end PVC DWV pipe cut square and deburred: 3 inch pipe into the two 3 inch hubs, 2 inch pipe into the heel inlet. There is no threaded port anywhere on it, so if the branch you are tying in ends in a male thread you need a separate adapter.
3) Which sizes of the Spears DWV low heel inlet elbow can I order?
Two: the 3 x 3 inch, part number P303-338, and a 1-1/2 inch, part number P304-015. The 3 x 3 is the one with the 2 inch heel inlet branch. Order by that part number if you are matching an existing submittal or replacing a fitting already in the wall.
4) How many Spears PVC DWV low heel inlet elbows come in a carton?
Twenty five per carton. That is the packaging quantity on the 3 x 3 x 2 low heel inlet elbow, which matters if you are stocking a service truck or buying rough-in quantities for a multi-unit job rather than picking up one fitting for a repair.
5) Will PVC drain fittings hold up in a commercial building or should I use cast iron?
PVC is the standard choice for DWV where the code and the spec allow it: it does not corrode the way metallic drainage does, it cuts and joins on site with a saw and solvent cement, and it weighs a fraction of cast iron, which is why a property manager or plumbing contractor can get a branch changed out in an occupied building without rigging. Where cast iron still wins is sound attenuation in stacks running behind occupied walls and any application where the spec or the local code calls for non-combustible drainage, so check the drawing before you substitute.
