95605 Viega MegaPress tee Smart Connect technology 304 stainless steel, 4'' x 4'' x 2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Country Of Origin:
- Made In Germany
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 4'' x 4'' x 2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 10.709"
- Product Height:
- 5.193"
- Product Weight:
- 5.99 lbs
- Product Width:
- 5.114"
Viega 95605 – Frequently Asked Questions
1) What size branch does the Viega MegaPress 95605 tee reduce to?
The MegaPress 95605 is a 4 inch x 4 inch x 2 inch tee, so the run stays full 4 inch and the branch drops to 2 inch. Use it where you need to pull a 2 inch takeoff off a 4 inch main without adding a separate reducing bushing.
2) Is the Viega 95605 tee press-fit or does it need welding or threading?
It is a press fitting. All three ends are press connections (P1 x P2 x P3), so it goes together cold with a press tool and jaw, no welding, no threading, and no open flame on the job.
3) What material is the Viega MegaPress 95605 tee, and will it work on a carbon steel system?
The 95605 is made of 304 stainless steel. Stainless MegaPress fittings are the ones to use on stainless piping systems; if your main is carbon steel, you want the carbon steel MegaPress line rather than this one, since mixing a stainless fitting onto carbon steel pipe is a corrosion question you do not want in a building.
4) How much room do I need to fit a 4 x 4 x 2 MegaPress tee between hangers?
Plan the space around the fitting body: it measures 10.709 inches long, 5.114 inches wide and 5.193 inches high. You also need clearance beyond that for the press jaw or ring to come around each collar, so do not size the opening tight to the fitting itself.
5) What is Viega Smart Connect on the 95605 tee and why does it matter on a large job?
Smart Connect is the feature that lets an unpressed connection leak during pressure testing so you can find it before the system goes into service. On a run with dozens of 4 inch joints, that is what keeps a missed press from turning into a callback in a finished ceiling.
6) Is the 4 inch MegaPress tee heavy enough to need support during install?
At 5.99 lbs for the fitting alone, a 4 x 4 x 2 stainless tee is a two-hand lift once it is loaded with pipe. Rig your hangers so the tee is supported before you press, rather than letting the joint carry the weight while you set the jaw.
7) What part number and manufacturer do I order this 4 x 4 x 2 stainless press tee under?
Order it as Viega MegaPress part number 95605. It is manufactured in Germany. Give distribution the 95605 number plus the 4 x 4 x 2 size and stainless material and you will get the right fitting.
