ABH 0147-1.5 Offset Pivot Set ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$851.00
$836.26
ABH ABH 0147-1.5 Pivot Set, 1-1/2" Offset ABH-0147-1.5

ABH 0147-1.5 Offset Pivot Set 1-1/2" with Heavy Duty Bearings Fire Rated

(No reviews yet) Write a Review

Model: 0147-1.5-RH-US26
$851.00
$836.26
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$851.00
$836.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH Offset Pivot Set 1-1/2" with Heavy Duty Bearings Fire Rated

Professional Fire-Rated Pivot Hardware Solution

The ABH Offset Pivot Set delivers professional-grade door support with 1-1/2" offset design for commercial applications. This heavy-duty pivot set features stainless steel base material construction and supports doors up to 350 pounds with maximum door width of 48". UL listed for use on 3-hour fire rated doors, this pivot set accommodates doors ranging from 60" to 90" tall with one intermediate pivot (019 model recommended, ordered separately).

Professional Features & Benefits

  • Heavy-Duty Load Capacity: Supports doors up to 350 pounds with maximum 48" door width for demanding commercial applications.
  • Fire Rating Compliance: UL listed for use on 3-hour fire rated doors ensuring code compliance and safety requirements.
  • Precision Offset Design: 1-1/2" offset configuration provides proper door clearance and smooth operation for offset hung applications.
  • Stainless Steel Construction: Stainless steel base material provides exceptional durability and corrosion resistance for long-term performance.
  • Heavy Duty Bearings: Professional-grade bearing system ensures smooth operation and extended service life under heavy use.
  • Flexible Door Height Compatibility: Accommodates doors from 60" to 90" tall with intermediate pivot support, with additional pivots for every 30" of additional height.
  • Handed Configuration: Available in left-hand or right-hand configurations to match specific door swing requirements.

Technical Specifications

  • Application: Standard Door
  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Weight: Up to 350 lbs
  • Duty Level: Heavy Duty
  • Electronic: No
  • Fire Rated Time: 3 hours
  • Fire Rating: Yes
  • Hang Type: Offset Hung
  • Keyed: N/A
  • Keyed Function: N/A
  • Mounting Method: Offset
  • Pivot Type: Top & Bottom
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Stainless Steel
  • Product Type: Pivot Sets - Offset
  • Subcategory: Door Pivots

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Fire-Rated Door Assemblies
  • Heavy-Duty Commercial Entrances

Why Choose ABH Quality?

ABH Offset Pivot Sets deliver professional-grade reliability with stainless steel construction and heavy-duty bearings rated for doors up to 350 pounds. UL listed for 3-hour fire rated applications with BAA qualification for government projects. Engineered for demanding commercial applications where dependable performance and code compliance are essential.

Product Specs

Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Pivot Sets - Offset
Subcategory:
Door Pivots
Commercial/Residential:
Commercial
Hang Type:
Offset Hung
Keyed:
N/A
Keyed Function:
N/A
BAA Qualified:
Yes
Duty Level:
Heavy Duty
Fire Rated Time:
3 hours
Electronic:
No
Door Weight:
Up to 350 lbs
Pivot Type:
Top & Bottom
Mounting Method:
Offset
Application:
Standard Door
Product Attribute:
Pivots
Fire Rating:
Yes
Product Category:
Door Hinges and Pivots
Product Substrate:
Stainless Steel
Department:
Door Hardware

ABH 0147-1.5-RH-US26 – Frequently Asked Questions

1) Will the ABH 0147-1.5 pivot set hold a 300 lb solid core door?
Yes. The 0147-1.5 offset pivot set is rated for doors up to 350 lbs, with a maximum door width of 48 inches. It's a heavy duty set with stainless steel base material and heavy duty bearings, built for commercial traffic. Two things to check before you order: the door has to be under 48 inches wide regardless of how light it is, and if the door is taller than 60 inches you need intermediate pivots as well (see the height question).
2) My door is 90 inches tall. Do I need more than the top and bottom pivot?
Yes. The 0147-1.5 set covers the top and bottom only. For doors from 60 to 90 inches tall ABH calls for one intermediate pivot, with an additional pivot for every 30 inches of height beyond that. The 019 intermediate pivot is the recommended one and it is ordered separately, so a 90 inch door is the pivot set plus one 019.
3) Do I have to order the ABH 0147-1.5 pivots handed?
Yes, handing matters. The 0147-1.5 is sold left hand or right hand, and an offset pivot cannot be flipped in the field the way a butt hinge can. Determine the swing from the side the door opens toward you and order to match. If you're replacing an existing offset pivot, the handing of what's coming out is your answer.
4) Can I buy just the bottom pivot if only one is worn out?
Yes. Three ways to order: the complete 0147-1.5 set, which includes the 0180-1.5 top pivot and the 0147-1.5B bottom pivot; the 0147-1.5B bottom pivot on its own; or the 0180-1.5 top pivot on its own. The bottom pivot carries the door weight and is usually what wears first, so a bottom-only replacement is common. Match the handing and the 1-1/2 inch offset of what you're pulling out.
5) What other offset hung pivot set can go on a 3-hour fire rated door instead of the ABH 0147-1.5?
The BEST A3 System offset hung pivot set is the peer to look at when the opening is a rated one. The ABH 0147-1.5 is fire rated with a 3 hour rated time, and the BEST A3 is likewise a fire rated offset hung pivot set, so both belong in the conversation for a rated door. Where they part company is the geometry you have to match: the ABH 0147-1.5 is built to a 1-1/2 inch offset, so if the frame and door were prepped for a 1-1/2 inch offset, the ABH set is the one that drops into that prep. Confirm the offset dimension the opening was detailed for before you swap either way.
6) Is the ABH 0147-1.5 pivot set acceptable on a federally funded job?
The 0147-1.5 offset pivot set is BAA qualified, which is what a government or municipal spec is usually asking for on Buy American Act work. Base material is stainless steel. That combination is why it turns up on government, healthcare, and education projects where the domestic-content line on the submittal has to be answered.
7) Should I use offset pivots or butt hinges on a heavy commercial door?
Offset pivots like the ABH 0147-1.5 carry the door's weight on a bearing at the floor rather than spreading it down the edge of the door, which is why they're specified for heavy doors, up to 350 lbs here, and for high traffic openings where hinges would sag or the frame would fatigue. They also let the door swing clear of the frame face, which butt hinges don't. The trade-off is prep: pivots need a floor and header prep laid out to a template and the door has to be prepped for the offset before it's hung, so they're a design decision, not a field swap. Hinges stay the simpler choice on a standard weight door in an existing hinge-prepped frame.
8) What else does ZenSupply carry in offset hung pivot sets besides ABH?
Two other offset pivot sets: the BEST A3 System offset hung pivot set, which is also fire rated, and the Calibre Door Closers PV1000, a 3/4 inch offset flush pivot set. The Calibre is the one to look at if your opening is detailed for a 3/4 inch offset rather than 1-1/2 inch, since offset is not interchangeable. If the requirement is a 3-hour fire rating with a stated 350 lb door weight, the ABH 0147-1.5 is the set that carries those numbers.
9) What finishes can I get ABH offset pivots in to match the rest of my door hardware?
Fourteen finishes across the 0147-1.5 range: satin stainless steel, bright stainless steel, satin chrome, satin brass, bright brass, painted brass, satin bronze, bright bronze, painted satin bronze, oil rubbed bronze, painted dark bronze, painted aluminum, and black or white suede powder coat. Satin stainless and painted aluminum are the usual pairings on aluminum and hollow metal commercial openings; the bronzes and oil rubbed bronze are there when the pivots have to disappear against a dark storefront or a bronze pull.
10) Are ABH offset pivots electrified for access control?
No. The 0147-1.5 is a mechanical pivot set with no electrical transfer through it. If the door needs power for an electric strike, an electrified lock, or a card reader, that has to come from a separate power transfer device or an electrified hinge in the hinge stile. The pivots themselves just hang and swing the door.
