Aiphone KB-DAR - Tilt Video Door Station

(No reviews yet) Write a Review

Model: KB-DAR

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,356.00
$943.78
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The KB-DAR is a video door station for use with the KB-3MRD Video System. Up to 3 KB-DAR's can be connected to master station.

The KB-DAR-M allows any standard motion detector or activation device with a normally open contact to be interfaced with the KB-3MRD Video System. When the motion detector is tripped, the camera will turn on and a chime will be heard at the inside monitor station(s), indicating that there is some activity near the door station location.

FEATURES

  • Tilt controlled camera
  • Mounts directly to wall or 1-gang box
  • Locator LED backlit on CALL button
  • LED illumination automatically turns on in low light conditions
  • KB-DAR-M: Motion detector interface
SPECS
  • Communication: Hands-free
  • Camera
    • Type: 1/4" CCD
    • View Area: 3'8"~7'1" vertical x 2' horizontal at 20"
  • Temp. Rating: 14°~140°F (-10°~60°C)
  • Material: Fire resistant ABS plastic
  • Mounting: Surface mount directly to wall
  • Wire Type: Door Station to Master Station: 2-cond., low cap, non-shielded - use Aiphone #871802
  • Distance: Door Station to Master Station: 330'(22AWG) 650'(18AWG)

Product Specs

Product Type:
Door Station
Series:
KB Series
Product Group:
Electronic Access Controls
Product Subgroup:
Intercoms
Subcategory:
Video Intercoms
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone KB-DAR – Frequently Asked Questions

1) What master station does the Aiphone KB-DAR video door station work with?
The KB-DAR is built for the Aiphone KB-3MRD video system and only works as part of that system. It is not a standalone intercom, so you need the KB-3MRD master station on the inside to answer calls and view the camera.
2) Can I put more than one door station on a KB-3MRD system?
Yes, up to three KB-DAR door stations can be connected to one KB-3MRD master station. That covers a front entrance, a side or service door, and a gate or rear door off a single inside monitor.
3) What is the difference between the KB-DAR and the KB-DAR-M?
Two versions are offered: the standard KB-DAR, and the KB-DAR-M, which adds remote activation contacts. The -M lets any standard motion detector or activation device with a normally open contact trigger the station, so when the detector trips the camera turns on and a chime sounds at the inside monitor. If you want motion-triggered viewing at the door, order the M version; if you only need call-button operation, the standard unit is the one.
4) How far can the KB-DAR door station be run from the master station, and what wire do I use?
Run it with 2-conductor, low capacitance, non-shielded cable (Aiphone #871802). Distance from door station to master is 330 feet on 22AWG and 650 feet on 18AWG, so step up to 18AWG for the longer pulls across a building or out to a gate.
5) Can the Aiphone KB-DAR mount to an existing 1-gang box?
Yes. The KB-DAR mounts directly to a wall surface or to a 1-gang box, so an existing single-gang backbox at the entry works as the mounting point. No flush back box or special ring is required.
6) Will this Aiphone door station hold up outdoors in cold or hot weather?
The housing is fire resistant ABS plastic and the station is rated from 14 to 140 degrees F (-10 to 60 C). That covers most sheltered exterior entries, but in a climate that drops below 14 F pick a location under cover or out of direct exposure.
7) Can you adjust the camera angle on the KB-DAR, and what does it actually see?
The camera tilts, so you can aim it after mounting to suit the door height and approach. Coverage is 3 feet 8 inches to 7 feet 1 inch vertical by 2 feet horizontal at a 20 inch distance, using a 1/4 inch CCD. That vertical range is what lets one mounting height frame both a tall adult and a child or a package on the step.
8) Does the KB-DAR work at night or in a dark entryway?
Yes. LED illumination switches on automatically in low light, and the CALL button is backlit with a locator LED so a visitor can find it in the dark. No separate entry light is needed for the camera to pick up a face at the door.
9) Does a visitor have to hold a button to talk on the Aiphone KB-DAR?
No. Communication is hands-free at the door station, so the visitor presses CALL once and then speaks normally. That matters for accessibility at a main entrance where someone may have their hands full or cannot hold a talk button.
10) Is the Aiphone KB Series door station suitable for a commercial building?
The KB-DAR is classified as commercial video intercom equipment, and the three-door-station capacity plus 650 foot wire runs on 18AWG suit a small office, clinic, or multi-tenant entry as readily as a residence.
