Appleton U-Line Contender GFS1 GFCI Cover, 20A

Appleton U-Line Contender GFS1 GFCI Cover, 20A

(No reviews yet) Write a Review

Model: GFS1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4,001.81
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Appleton U-Line Contender 20A 3-Pole Factory-Sealed Plugs & Receptacles

Appleton U-Line Contender Factory Sealed 20 Amp Plugs and Receptacles deliver a dead-front design engineered for electrical equipment in hazardous locations. Rated 125 Vac or 250 Vac at 20A with 3-pole, 2-wire configuration, each receptacle is not energized until the plug is fully inserted and the switch is engaged. A neoprene gasket in the throat of the receptacle seals against the plug or the spring-loaded cover to keep out water, dust, and corrosive compounds, while U-Line receptacles are specifically designed so they cannot be energized by an ordinary plug.

Key Features

  • Dead Front Design: The receptacle stays de-energized until the plug is fully inserted and the switch is engaged, reducing arc-flash exposure.
  • Sealing Protection: Neoprene gasket in the receptacle throat seals against the plug or spring-loaded cover to block water, dust, and corrosive compounds.
  • Broad Compatibility: ECP plug fits any standard non-explosionproof receptacle (NEMA 5-20R or 6-20R) as well as U-Line explosionproof receptacles, and is intermatable with competitor plugs of like configurations.
  • Electrical Rating: 125 Vac or 250 Vac, 20A, 3-pole, 2-wire for reliable hazardous-area power connections.
  • Insulator Block Material: Glass-filled reinforced polyester provides superior dielectric and mechanical strength with the lowest arc tracking.
  • Durable Construction: Mounting boxes are malleable iron with a triple-coat finish (zinc electroplate, chromate, epoxy powder coat); standard receptacle covers and optional aluminum mounting boxes are copper-free aluminum with epoxy powder coat.
  • GFCI Option: Ground fault circuit interrupting cover and receptacle combinations are available.
  • Mounting Flexibility: Mounting box entries support dead-end or feed-thru configurations, with plug cable diameter of .538–.639.

Certifications & Compliance

  • Covers are UL Listed when used with Contender™ Series mounting boxes, and UL Classified when used with Crouse-Hinds™ EDS™ series mounting boxes
  • Class I, Groups C, D; Class I, Division 2, Group B; Class I, Zone 1, Group IIB; Class I, Zone 2, Group IIB + H2
  • Class II, Groups F, G; Class III
  • NEMA 3RX, 7CD, 9FG

Technical Specifications

  • Number of Poles: 3
  • Amperage: 20
  • Number of Wires: 2

Typical Applications

  • Hazardous Location Electrical Installations
  • Oil & Gas Processing Facilities
  • Chemical and Petrochemical Plants
  • Industrial Power Distribution and Portable Equipment Connections
  • Outdoor and Wet-Location Equipment Hookups

Why Appleton?

Appleton engineers the U-Line Contender line with malleable iron and copper-free aluminum housings, epoxy powder coat finishes, and glass-filled reinforced polyester insulator blocks to withstand demanding hazardous-area environments. With UL Listed and UL Classified cover options, documented Class I/II/III hazardous area ratings, and a dead-front, factory-sealed design, these plugs and receptacles deliver code-compliant, reliable power connections for professional electrical installations.

What this is: GFS1 is a Contender-series factory-sealed GFCI cover (5 mA trip, 125 VAC, 20A, copper-free cast aluminum) that installs into a standard Contender mounting box — it is a cover/accessory, not a complete plug-and-receptacle set. If you need a complete ready-to-install set, see the ECSK-2023 or EFSR-2023M listings.

Product Specs

Product Type:
Weatherproof Receptacle Cover
Voltage Rating:
125/250 VAC
Amperage Rating:
20A
Configuration:
3-Pole
Standards:
NEMA 3RX, 7CD, 9FG
Listing:
UL Listed
Product Finish:
Epoxy Powder Coat
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Weatherproof Covers

Appleton GFS1 – Frequently Asked Questions

1) Is the Appleton GFS1 a complete GFCI receptacle assembly or just the cover?
GFS1 is a cover only. It's a Contender-series factory-sealed GFCI cover, copper-free cast aluminum, 5 mA trip, 125 VAC, 20A, that installs into a standard Contender mounting box. You do not get a plug-and-receptacle set with it. If you need a complete ready-to-install set, look at the ECSK-2023 or EFSR-2023M.
2) Which mounting boxes can I use with the Appleton GFS1 GFCI cover?
It mounts on Contender Series boxes and on Crouse-Hinds EDS series boxes. The distinction matters for your inspector: the cover is UL Listed when used with Contender Series mounting boxes, and UL Classified when used with Crouse-Hinds EDS series boxes. If your spec calls for UL Listed, stay with the Contender box.
3) What hazardous location classes is the Appleton Contender GFCI cover rated for?
The rating covers Class I, Groups C and D; Class I, Division 2, Group B; Class I, Zone 1, Group IIB; Class I, Zone 2, Group IIB + H2; Class II, Groups F and G; and Class III. Enclosure ratings are NEMA 3RX, 7CD and 9FG, so it is suited to wet and corrosive outdoor areas as well as classified interiors. Note there is no Group A or Group B Division 1 listing, so acetylene or hydrogen Division 1 areas are out.
4) Can I use the GFS1 GFCI cover on a 250 volt circuit?
No. The GFS1 GFCI cover itself is a 125 VAC, 20A device with a 5 mA trip. The U-Line Contender family as a whole is rated 125 or 250 Vac at 20A, 3-pole, 2-wire, but the GFCI cover is the 125 VAC part of that range. For a 250 volt hookup you need a non-GFCI cover and receptacle combination from the same series.
5) Will an ordinary NEMA 5-20 plug energize a U-Line Contender receptacle?
No, and that is deliberate. U-Line receptacles are built so they cannot be energized by an ordinary plug. The design is dead front: the receptacle stays de-energized until the plug is fully inserted and the switch is engaged, which cuts arc-flash exposure. The traffic goes the other way though, an ECP plug will fit a standard non-explosionproof NEMA 5-20R or 6-20R receptacle as well as U-Line explosionproof receptacles.
6) How does the Contender cover keep water and dust out of the receptacle?
There's a neoprene gasket in the throat of the receptacle. It seals either against the inserted plug or against the spring-loaded cover when nothing is plugged in, blocking water, dust and corrosive compounds. That is what backs the NEMA 3RX rating for wet and corrosive outdoor locations.
7) What is the Appleton Contender cover made of, and will it hold up in a chemical plant?
Standard receptacle covers, including the GFS1, are copper-free cast aluminum with an epoxy powder coat finish. Mounting boxes are malleable iron with a triple-coat finish of zinc electroplate, chromate and epoxy powder coat. Insulator blocks are glass-filled reinforced polyester for dielectric and mechanical strength with low arc tracking. Copper-free aluminum is the material specified for refinery and petrochemical service.
8) What cable diameter does the Contender plug accept?
Plug cable diameter range is .538 to .639 inches. Check your cord jacket OD against that before ordering, an oversized SOOW jacket will not seat in the grip.
9) Can I order the GFS1 for a feed-thru run, or is it dead-end only?
Both work. Contender mounting box entries support dead-end or feed-thru configurations, so you can loop power through a string of receptacle stations rather than home-running each one. The box determines that, not the GFS1 cover, so specify the entry arrangement when you order the box.
10) What exact part number do I order for the Appleton Contender 20A GFCI cover?
Order catalog number GFS1 from Appleton. It is the Contender factory-sealed GFCI cover, 20A, 125 VAC, 5 mA trip. Pair it with a Contender mounting box and receptacle to make a working station.
