Appleton U-Line Factory-Sealed 20 Amp Plug and Receptacle

Appleton U-Line Factory-Sealed 20 Amp Plug and Receptacle

(No reviews yet) Write a Review

Model: EFSR-2023M

In Stock (leaves warehouse same day if ordered before 3pm ET)

$936.54
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Appleton U-Line Factory-Sealed 20 Amp Plug and Receptacle

The Appleton U-Line Factory-Sealed 20 Amp Plug and Receptacle is engineered for stationary or portable electrically operated devices in hazardous locations. The ECP Interchanger plug features built-in switch contacts that activate when twisted into the receptacle, fitting standard NEMA 5-20R and 6-20R receptacles while preventing standard plugs from mating with the receptacle. Rated 125 Vac or 250 Vac, 20A, 3-pole, 2-wire, this U-Line series is classified for Class I, Division 1 and 2 Groups B, C, D; Class II, Division 1 and 2 Groups F, G; Class III; and NEMA 3, 3R environments.

Key Features

  • Amperage Rating: 20A construction supports stationary and portable hazardous-location equipment.
  • Voltage Rating: 125 Vac or 250 Vac with 1 or 2 horsepower ratings for motor-driven loads.
  • Superior Insulators: Glass-filled reinforced polyester insulator block delivers superior dielectric and mechanical strength with lowest arc tracking.
  • Recessed Contacts: Energized receptacle contacts are deeply recessed to reduce the danger of accidental touching.
  • Blade-Type Brass Contacts: Unique blade-type brass contacts exert constant pressure along the entire contact surface for superior electrical connection.
  • Intermateable Design: Intermateable with competitor's plugs of like configurations, and GFCI cover/receptacle combinations are available.
  • Interchanger Compatibility: The ECP plug fits any standard non-explosionproof NEMA 5-20R or 6-20R receptacle as well as U-Line explosionproof receptacles.
  • Material Options: Available with malleable iron or aluminum receptacle and mounting box construction.

Certifications & Compliance

  • Class I, Division 1 Groups B, C, D
  • Class I, Division 2 Groups B, C, D
  • Class II, Division 1 and 2 Groups F, G
  • Class III
  • NEMA 3, 3R

Technical Specifications

  • Number of Poles: 3
  • Amperage: 20
  • Number of Wires: 2
  • Voltage: 125 Vac or 250 Vac
  • Horsepower Ratings: 1 or 2
  • Insulator Block Material: Glass-filled reinforced polyester
  • Mounting Box Entries: Dead-End or Feed-Thru
  • Plug Cable Diameter: .538 – .639

Typical Applications

  • Hazardous Location Electrical Connections
  • Stationary and Portable Electrically Operated Equipment
  • Petrochemical and Industrial Facilities
  • Outdoor and Wet-Location Installations (NEMA 3R)
  • Renovation and New Construction in Classified Areas

Why Appleton?

Appleton's U-Line Factory-Sealed plugs and receptacles combine glass-filled polyester insulators, deeply recessed brass contacts, and a triple-coat malleable iron or epoxy powder-coated aluminum finish to deliver reliable, code-compliant performance in demanding hazardous-location environments.

U-Line family note: this is the EFSR straight-blade, spring-door design with the ECP Interchanger twist-lock plug mechanism — a different design from the ECS/ECSK dead-front line and from the Contender sub-line (both sold as separate listings) — not interchangeable parts of one product.

Product Specs

Product Type:
Receptacle
Voltage Rating:
125/250V
Amperage Rating:
20A
Standards:
NEMA 3, 3R
Product Finish:
Epoxy Powder Coat
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Plugs & Connectors

Appleton EFSR-2023M – Frequently Asked Questions

1) Can the Appleton U-Line EFSR-2023M be used in a Class I Division 1 area?
Yes. The Appleton U-Line factory-sealed 20A plug and receptacle is classified for Class I, Division 1 and 2 Groups B, C, D; Class II, Division 1 and 2 Groups F, G; and Class III. It also carries NEMA 3 and 3R enclosure ratings, so it holds up outdoors and in wet locations. Group B coverage matters if you have hydrogen present, since plenty of hazardous-location devices stop at Groups C and D.
2) Will the Appleton ECP Interchanger plug work in a regular shop receptacle?
It will. The ECP Interchanger plug mates with any standard non-explosionproof NEMA 5-20R or 6-20R receptacle as well as U-Line explosionproof receptacles, so a portable tool or piece of equipment cordset can move between a classified area and a normal 20A outlet. The reverse is blocked on purpose: a standard plug will not mate with the U-Line receptacle, because the plug's built-in switch contacts only close when it is twisted into place.
3) What size cord will fit the Appleton U-Line ECP plug?
The plug accepts cable with an outside diameter of .538 to .639 inches. Measure the jacket OD on your cordset before ordering; anything outside that window will not seal properly in the plug's cord grip.
4) Is the Appleton EFSR the same as the Appleton ECS or Contender receptacles?
No. The EFSR is the U-Line straight-blade, spring-door design using the ECP Interchanger twist-lock plug mechanism. The ECS/ECSK dead-front line and the Contender sub-line are separate designs sold separately, and their parts are not interchangeable with EFSR components. Order the EFSR plug and receptacle together if you are building a new connection point.
5) Can a Bryant 5362B or Pass & Seymour 26352W 20A receptacle be used instead of the Appleton EFSR-2023M in a classified area?
No. The Appleton U-Line EFSR-2023M is a factory-sealed 20A plug and receptacle classified for Class I, Division 1 and 2 Groups B, C, D; Class II, Division 1 and 2 Groups F, G; Class III; and NEMA 3, 3R. The Bryant 5362B is a heavy-duty 20A/125V duplex receptacle and the Pass & Seymour 26352W is a 20A 125V heavy-duty specification grade decorator duplex receptacle - both are general-purpose wiring devices without hazardous-location classification. For a Division 1 or Division 2 area, the explosionproof U-Line device is the one that fits the requirement.
6) What voltage and horsepower can the Appleton U-Line 20A receptacle handle?
Rated 125 Vac or 250 Vac at 20 amps, 3-pole 2-wire, with 1 or 2 horsepower ratings. That horsepower rating is what lets it feed motor-driven equipment rather than just resistive or lighting loads, so it suits pumps, blowers, and portable motorized gear in classified areas.
7) Do I need a dead-end or feed-thru box for the Appleton U-Line receptacle?
Both mounting box entries are offered. Use dead-end where the receptacle is the last device on the run and the conduit enters from one side only. Use feed-thru when the circuit continues past this location to other devices. Receptacle and box come in malleable iron or aluminum construction, with an epoxy powder coat finish.
8) Will a competitor's 20A hazardous-location plug mate with the Appleton U-Line receptacle?
The Appleton U-Line EFSR-2023M is intermateable with competitors' plugs of like configurations, and the ECP Interchanger plug will also fit any standard non-explosionproof NEMA 5-20R or 6-20R receptacle as well as U-Line explosionproof receptacles. What it will not accept is a standard plug into the U-Line receptacle - that is prevented by design. Straight-blade general-purpose devices such as the Bryant 5362BI heavy-duty 20A/125V duplex are not part of that mating scheme.
9) What is the difference between the Appleton U-Line ECP plug's twist action and a Pass & Seymour Turnlok locking receptacle?
The Appleton U-Line ECP Interchanger plug has built-in switch contacts that activate when the plug is twisted into the receptacle, and it fits standard NEMA 5-20R and 6-20R receptacles while preventing standard plugs from mating with the U-Line receptacle. The Pass & Seymour 3330 Turnlok is a 30A non-NEMA single receptacle, so its twist-lock interface is a 30A non-NEMA configuration rather than a 20A straight-blade pattern with switching contacts. They are not intermateable.
10) For a 15 amp general-purpose outlet in an office or corridor, is the Appleton EFSR-2023M the wrong part?
Yes - the Appleton U-Line EFSR-2023M is a 20A device built for hazardous-location equipment with a malleable iron or aluminum receptacle and mounting box. For ordinary 15A interior use, the Eaton 5262W is an Arrow Hart heavy-duty industrial duplex rated 15A 125V in a 5-15R pattern, the Eaton 816W-BOX is a commercial specification grade 15A single receptacle, and the Pass & Seymour 3232TRW Trademaster is a tamper-resistant duplex.
11) Does the Appleton EFSR-2023M provide GFCI protection like the Pass & Seymour 2097HGI?
The Pass & Seymour 2097HGI is a hospital grade 20A duplex self-test GFCI receptacle, with the ground-fault device built into the receptacle itself. The Appleton U-Line line is offered with GFCI cover and receptacle combinations, so ground-fault protection in the U-Line family comes as a cover/receptacle assembly rather than a self-test duplex face. The 2097HGI is a general-purpose healthcare device and is not classified for hazardous locations, while the U-Line EFSR-2023M is factory-sealed for Class I, II and III areas.
12) Is a flanged locking receptacle like the Bryant 70520FR an equivalent to the Appleton U-Line EFSR-2023M for a wet outdoor location?
Not an equivalent. The Bryant 70520FR is a 7 Series NEMA flanged locking receptacle. The Appleton U-Line EFSR-2023M is rated NEMA 3 and 3R with an epoxy powder coat finish and a spring-door straight-blade design, and it is additionally classified for Class I, Division 1 and 2. If the outdoor location is also a classified area, the U-Line device is the one that covers both conditions.
13) Should I pick malleable iron or aluminum for the U-Line receptacle housing?
Malleable iron with a triple-coat finish is the tougher choice for heavy mechanical abuse and general petrochemical duty. Aluminum with an epoxy powder coat is lighter and is the usual pick where weight on the structure matters or where iron is not wanted. Both cover the same hazardous-location classifications; the difference is the housing material, not the electrical rating.
14) Is the plug on the Appleton U-Line receptacle safe to touch when energized?
Energized receptacle contacts are deeply recessed to cut the risk of accidental contact, and the plug's switch contacts only make when the plug is twisted home, so the connection is not live while you are inserting it. The insulator block is glass-filled reinforced polyester for dielectric and mechanical strength with low arc tracking, and the blade-type brass contacts hold pressure across the whole contact face.
15) For a single-outlet industrial installation, what is the difference between the Appleton EFSR-2023M and the Eaton 6450W?
The Eaton 6450W is a heavy-duty industrial specification grade decorator single receptacle accepting #14-10 AWG conductors, intended for standard wall-box installation in unclassified areas. The Appleton U-Line EFSR-2023M is a factory-sealed 20A plug and receptacle supplied with a malleable iron or aluminum receptacle and mounting box, with dead-end or feed-thru box entries, and a plug cable diameter range of .538 to .639 inch for portable equipment cords.
