Camden CM-1000 Series Cast Aluminum Key Switch with Surface Box

Camden CM-1000 Series Cast Aluminum Key Switch with Surface Box

(No reviews yet) Write a Review

Model: CM-1000

In Stock (leaves warehouse same day if ordered before 3pm ET)

$144.00
$119.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Camden CM-1000 Series Cast Aluminum Key Switch with Surface Boxon


Camden CM-1000 key switches offer a vandal resistant 1/4" thick aluminum faceplate and are designed for high traffic outdoor or indoor use. They are supplied with a weatherproof gasket and cast aluminum surface mount box, with a 1/2" threaded conduit opening for wall, pipe, or pedestal mounting.FEATURES
  • Supplied with heavy duty diecast surface box.
  • Accepts standard mortise cylinders ( 1" - 1-1/4" )
  • Heavy duty 1/4" thick aluminum plate.
  • Cylinder sits flush to faceplate.
  • Tamper proof screws and driver provided.
  • No set screws required.
  • Color coded 18 AWG soldered leads.
  • Heat shrink protective sleeve over contacts.
  • 3 year warranty

SPECIFICATIONS

Contact Rating: 6 A @ 30 VDC
Switch Life: 100,000 cycles
Temp Range: 32°F to 85°F (0°C to +85°C)
Std. Finish: Brushed aluminum
Dimensions: 4-1/2" x 2-3/4" x 2"
(114mm x 70mm x 51mm)

Manufacturer Resources

CM-1000_Spec Sheet_R4

Product Specs

Subcategory:
Push Buttons
Contact Type:
SPST Momentary, N/O
Warranty:
3 Year Limited
Wireless Communication:
No
Commercial/Residential:
Commercial
Product Type:
Mortise Key Switch
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Switches/Push Buttons
Lock Type:
Mortise cylinder
Product Category:
Electronic Access Control
Department:
Door Hardware

Camden Door Controls CM-1000 – Frequently Asked Questions

1) Does the Camden CM-1000 key switch come with a cylinder, or do I supply my own?
No cylinder is included. The CM-1000 accepts standard mortise cylinders from 1 inch to 1-1/4 inch, so you key it into your existing system with whatever keyway the building already uses. The cylinder sits flush to the faceplate and no set screws are required to hold it.
2) Can the CM-1000 key switch be mounted outdoors?
Yes. It's built for high traffic outdoor or indoor use, with a 1/4 inch thick vandal resistant cast aluminum faceplate, a weatherproof gasket and a cast aluminum surface mount box. Watch the temperature range though: 32 F to 85 F. In a climate that drops below freezing or runs hotter than that, it is outside the rated range.
3) Will this key switch work with a maglock or an electric strike circuit?
The CM-1000 is a SPST momentary, normally open contact rated 6 A at 30 VDC. That suits it to a momentary release input on an access control panel, door controller, or low voltage relay for a maglock or electric strike, so long as your circuit stays within 30 VDC and 6 amps. It is a dry contact switch only, so it does not itself supply power to the lock.
4) Do I need to cut into the wall to install the CM-1000?
No wall cut-in needed. The switch ships with a heavy duty diecast surface box that mounts on the face of the wall, and the box has a 1/2 inch threaded conduit opening, so it can also go on pipe or a pedestal. Overall size is 4-1/2 x 2-3/4 x 2 inches (114 x 70 x 51 mm).
5) How is the CM-1000 wired in, and are the leads pre-terminated?
Wiring is color coded 18 AWG soldered leads with a heat shrink protective sleeve over the contacts, so there are no screw terminals to work loose in an exterior box. Run your pair through the 1/2 inch conduit opening and splice to the controller input.
6) Is this key switch tough enough for a high traffic commercial entrance?
It's a commercial grade device: 1/4 inch thick vandal resistant cast aluminum plate, diecast box, and a switch rated for 100,000 cycles. Tamper proof screws and the matching driver are supplied, so the plate can't be pulled off with a standard bit.
7) What finish does the CM-1000 come in, and will it match other exterior hardware?
Standard finish is brushed aluminum on the cast aluminum plate and box, which reads close to satin chrome or US26D trim on most exterior openings. Only the one model is offered, so every unit across a site will match.
8) Does the CM-1000 need a network connection or any programming?
None. It is a hardwired mechanical key switch with an electrical contact, with no wireless communication and nothing to program. Authorization is handled entirely by the mortise cylinder you install in it, so key control stays with your existing keying system.
