Camden Camden SureWave CM-332 Series 2 Relay /43 Hand Icon/'Wave to Lock' Text Faceplate Touchless Switch CM-332-43

Camden SureWave CM-332 Series 2 Relay /43 Hand Icon/'Wave to Lock' Text Faceplate Touchless Switch

(No reviews yet) Write a Review

Model: CM-332/43S
From the CM-332 Series Collection
$304.00
$263.65
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$304.00
$263.65
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

SUREWAVE CM-332 SERIES HAND ICON/'WAVE TO LOCK' TEXT/WHEELCHAIR SYMBOL FACEPLATE TOUCHLESS SWITCH

CM-332 touchless switches provide ‘state of the art’ door activation and control while eliminating the spread of germs.

These line powered touchless switches offer an adjustable operating range, selectable motion sensing and relay operating modes, hold open timer(s), REX and door position inputs, and the option for a light ring and wireless transmitter.

SPECIFICATIONS

  • Finish options
    • Stainless Steel - CM-332/43S, CM-332/43S-SGLR
  • Light Ring
    • Plug-in light ring for single gang, double gang, and 6" round stainless steel faceplates
    • Red/Green /Blue controlled by switch or remotely
  • Mounting Plate Size Options
    • Single Gang - CM-332/43S, CM-332/43S-SGLR

Product Specs

Series:
CM-332
Contact Rating:
3 Amps @ 30 V
Relay Action:
Multi Function
Relay Operating Modes:
Event, Toggle
Inputs:
REX, DPS
Warranty:
3 Year Limited
Wireless Communication:
Yes
Subcategory:
Hands Free Switches
Sensor:
Active Infrared Air
Number of Relays:
2
Application:
Indoor
Commercial/Residential:
Commercial
Product Type:
Hands Free Switches
Power:
40 mA
Fail-safe / Fail-secure:
Field Selectable
Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Voltage:
12VAC/DC/24VDC/24VAC
Product Length:
5.25"
Product Height:
2"
Product Category:
Electronic Access Control
Product Weight:
0.4
Product Width:
5.5"
Collection:
CM-332 Series
Department:
Door Hardware

Camden Door Controls CM-332/43S – Frequently Asked Questions

1) What voltage does the Camden SureWave CM-332 touchless switch run on, and can it share power with my mag lock supply?
The CM-332 is line powered and accepts 12VAC/DC, 24VDC or 24VAC, drawing 40 mA. That range covers the typical 12V or 24V access control supply already feeding a mag lock or strike, so it can be picked up off the same regulated supply as long as you have 40 mA of headroom.
2) Will the CM-332 relay contacts switch my electric strike directly, or do I need a separate power controller?
Contacts are rated 3 Amps at 30 V. That handles most 12V or 24V strikes and small loads switched directly, but anything drawing more than 3 amps, or any line-voltage load, has to go through a relay or power controller. Check the inrush of your strike, not just its holding current.
3) Why does the CM-332 have two relays instead of one?
Two relays let one switch do two jobs from a single wave: fire the door operator and release the lock at the same time, or drop a mag lock on one relay while triggering an alarm shunt or an intercom on the other. Both are multi-function and each can be set for event or toggle operation.
4) Can this Camden switch be set up as a wave-to-lock button for a restroom or exam room rather than a door opener?
That is what the /43 faceplate is made for. It carries a hand icon with 'Wave to Lock' text, and the relays run in toggle mode so one wave locks and the next wave unlocks, with the status held between waves. Event mode is the alternative if you want a timed momentary release for an operator instead.
5) Does the CM-332 have inputs for a request-to-exit device and a door contact?
Both. REX and DPS inputs are built in, so a crash bar REX or motion sensor can trigger the same relay logic, and the door position switch lets the unit know whether the door is closed before it relocks. That is the wiring that makes an unattended wave-to-lock room behave correctly.
6) Can I use this Camden touchless switch on a mag lock that has to release on power failure?
Yes, the fail-safe/fail-secure behavior is field selectable, so the same unit can be configured to release a mag lock on loss of power or to hold a fail-secure strike locked. Set it at install to match the egress requirement for that opening.
7) Is the tri-color light ring worth adding on a wave to lock switch?
On a lock application it is the piece that tells the occupant the room is actually secured. The plug-in ring shows red, green or blue, controlled either by the switch itself or remotely from another device, and it is offered on single gang, double gang and 6 inch round stainless faceplates. Both with-ring and without-ring builds are ordered on the same model, so pick it at order time.
8) Can the CM-332 be mounted outside on an exterior entrance?
No. The CM-332 is rated for indoor commercial use only. For a weather-exposed entrance you need an outdoor-rated actuator instead.
9) Will the wave switch trigger every time someone walks past it in a corridor?
It uses active infrared air sensing with an adjustable operating range and selectable motion sensing, so you can tighten the detection field down to a deliberate hand wave close to the plate rather than passing foot traffic. That adjustment is the fix for nuisance activations in tight corridors.
10) Can I use the CM-332 without running wire back to the door operator?
There is an option for a wireless transmitter, so the switch can signal a receiver at the operator instead of a hard run through the frame. Useful on retrofits where you cannot get conduit across the opening. Power still has to reach the switch itself.
11) Does the CM-332 have a built-in hold open timer for the door operator?
Hold open timer functions are built into the switch, so the relay can be set to hold the operator open for a set interval rather than pulsing. Combined with two multi-function relays, you can time the lock release and the operator trigger independently.
