CDVI Americas STARPB Prox Reader/Mullion/Wiegand/125khz/Black

CDVI Americas STARPB Prox Reader/Mullion/Wiegand/125khz/Black

(No reviews yet) Write a Review

Model: STARPB

In Stock (leaves warehouse same day if ordered before 3pm ET)

$228.00
$140.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

CDVI Americas STARPB Prox Reader/Mullion/Wiegand/125khz/Black

CDVI proximity card readers are recognized worldwide, having won several awards for their innovative design. CDVI has a full and varied range of proximity card readers to meet all of your needs. This includes mini, mullion, vandal-resistant and card reader/keypad combinations.

Features:

  • Reads CDVI and most popular 26-bitsWiegand card encoding.
  • High performance read range.
  • Innovative design.
  • Illuminated card reader (Blue, green and red).
  • Audible and visual feedback.
  • PCB sealed in epoxy.
  • Polycarbonate.
  • Easy to mount.

Specifications:

  • Casing Construction: Polycarbonate.
  • Card Reading Technology: 125 Khz.
  • Multi-card protocol: CDVI, HID and most popular 26-bit cards.
  • Indoor/Outdoor: Yes. (PCB sealed in epoxy).
  • Read Range: Up to 2.4" (6 cm).
  • Audible and Visual Feedback: Yes.
  • Input voltage: 12 Vdc.
  • Current Consumption: 100 mA.
  • Operating temperature: - 22°F to 158°F (- 30°C to 70°C).
  • Dimensions: 5.5"(140mm) x 1.65"(42mm) x 1.4"(23mm).
  • Certifications: RoHS, WEEE, IP53, CE FCC, R&TTE, ETL (UL294).

Finishes:

  • SOLARKPB - Black
  • SOLARKPW - White



Resources

CDVI Access Control Data Sheet

Manufacturer Resources

Product Specs

Subcategory:
Readers & Credentials
Commercial/Residential:
Commercial
Electronic:
Yes
Product Type:
Access Controllers
Product Group:
Electronic Access Controls
Product Subgroup:
Readers, Keypads and Credentials
Product Function:
Prox Reader
Product Category:
Electronic Access Control
Department:
Door Hardware

CDVI STARPB – Frequently Asked Questions

1) Will the CDVI STARPB prox reader fit on a narrow door mullion or aluminum frame?
Yes. The STARPB is a mullion-style reader measuring 5.5 x 1.65 x 1.4 inches (140mm x 42mm x 23mm), so it mounts on the narrow face of a storefront mullion or an aluminum door frame where a square wall reader will not sit flat. That 1.65 inch width is the number to check against your mullion face before ordering.
2) Will the CDVI STARPB reader work with the HID 125 kHz prox cards we already issue?
It reads 125 kHz credentials and handles CDVI, HID and most popular 26-bit Wiegand card encoding, so an existing 26-bit HID prox fleet will read on it. What it will not do is read 13.56 MHz smart credentials (iCLASS, MIFARE, DESFire) or mobile, because it is a 125 kHz-only reader. If your building has already moved to 13.56 MHz, this is the wrong reader.
3) Can the STARPB prox reader be mounted outside on an exterior door?
Yes, it is rated for indoor or outdoor use. The PCB is sealed in epoxy and the casing is polycarbonate, with an IP53 rating and an operating range of -22F to 158F (-30C to 70C). That temperature band covers most North American exterior installs. IP53 protects against dust and falling spray, so keep it off a surface that gets pressure washed or takes driving rain head-on.
4) What power supply and wiring does the CDVI STARPB reader need?
12 Vdc in, drawing 100 mA, with a Wiegand output to the controller. Size your access control power supply for 100 mA per reader, so a two-door opening with a reader on each side needs 200 mA of headroom on the 12 Vdc bus on top of whatever the locks pull.
5) Does the STARPB reader need a separate access control panel, or does it work on its own?
It is a reader only. The STARPB puts out Wiegand and needs a controller behind it to make the unlock decision and drive the lock. If you are starting a job from scratch rather than replacing a head-end you already have, the CDVI Atrium A22KITSTB two-door kit bundles the A22 controller with two STARPB readers and 15 credentials, which gets a two-door opening running without sourcing the panel separately.
6) What is the difference between ordering a CDVI STARPB reader on its own and ordering the CDVI Americas A22KITSTB Atrium kit?
The STARPB is the reader alone: a mullion-format 125 kHz proximity reader with Wiegand output, in black. The CDVI Americas A22KITSTB Atrium 2-Door Kit is a packaged 2-door bundle built around the A22 controller with two STARPB readers and 15 credentials included. Use the standalone STARPB when the access control panel and credentials are already in place and you are adding or replacing a reader at the opening; use the A22KITSTB when the door has no controller yet and you need the panel, readers, and cards to arrive together as one system.
7) Can a Schlage CTE ENGAGE single door controller be used in place of a CDVI STARPB prox reader?
They are not interchangeable parts. The STARPB is a reader only, sending 125 kHz proximity credential data out over Wiegand to a separate access control panel. The Schlage Electronics CTE ENGAGE Single Door Controller is a controller with an integrated mobile-enabled multi-technology reader that connects by direct RS-485. Swapping the CTE in for a STARPB replaces both the reader and the door's control decision point, and the RS-485 connection does not land on a Wiegand reader input. Choose the STARPB when an existing panel expects a Wiegand reader; choose the CTE ENGAGE when the opening needs its own single-door controller and mobile credential support.
8) How close does a card have to be held to the STARPB reader?
Read range is up to 2.4 inches (6 cm). That is a present-the-card reader, not a hands-free or drive-up one. For a tenant walking up with a badge in hand it is fine; for a loading dock or gate where someone stays in a vehicle, 2.4 inches will not reach and you want a long-range reader instead.
9) Is the CDVI STARPB reader UL listed for access control?
It is ETL listed to UL294, the access control system units standard, and also carries RoHS, WEEE, IP53, CE, FCC and R&TTE. UL294 is usually what a spec or an AHJ asks for on egress and access control equipment, so this clears that line item.
10) Should I use a mullion prox reader or an all-in-one door controller with a built-in reader?
It depends on where the intelligence lives. The STARPB is a dumb Wiegand reader wired back to a panel, which is what you want when you are standardizing several doors on one controller and one credential database. An integrated unit like the Schlage CTE ENGAGE single door controller puts the controller and a mobile-enabled multi-technology reader in one housing on a direct RS-485 connection, which suits a one-off door or a retrofit where pulling wire to a panel closet is the expensive part.
11) If a site needs to read mobile phone credentials at the door, what should be used instead of a 125 kHz prox reader?
The CDVI STARPB reads CDVI, HID, and most popular 26-bit cards at 125 kHz, so it covers physical proximity cards and fobs. For an opening where the credential is a phone, the Schlage Electronics CTE ENGAGE Single Door Controller carries a mobile-enabled multi-technology reader and connects by direct RS-485. A mixed facility can run STARPB readers on the openings that stay on prox cards and place the mobile-enabled unit at the doors that need phone credentials.
12) For a two door entry with no existing access control, is a single prox reader enough?
A single CDVI STARPB covers one reader position and needs a panel behind it to make the unlock decision, since it is a reader that passes Wiegand data upstream. A two door opening with nothing installed yet is matched by the CDVI Americas A22KITSTB Atrium 2-Door Kit, which pairs the A22 controller with two STARPB readers and 15 credentials so both doors are covered by one order. Adding individual STARPB readers makes sense once that controller is in place and a third or fourth reader position opens up.
13) Does the STARPB give the user any feedback that a card was read?
Yes, both audible and visual. The card face is illuminated and changes between blue, green and red, with a beeper alongside it, so a user knows whether the credential was accepted without watching the door. That matters on a multi-family or hotel entry where you do not want tenants yanking on a door that never unlocked.
14) Is the STARPB rated for commercial use or is it a residential reader?
Commercial. The STARPB is built for commercial access control duty, with an epoxy-sealed board and a polycarbonate housing rather than a consumer enclosure, and it is intended for door hardware installs in commercial buildings.
15) What color does the CDVI STARPB come in?
The STARPB is the black version. If you need a reader to disappear against a dark bronze or black anodized storefront mullion, that is the finish to match; on a clear anodized or white frame the black unit will read as a deliberate contrast rather than a match.
