Codelocks A3 Dual Standalone Door Controller with RFID Black Finish

Codelocks A3 Dual Standalone Door Controller with RFID Black Finish

(No reviews yet) Write a Review

Model: AL03DXBK

In Stock (leaves warehouse same day if ordered before 3pm ET)

$226.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

A3 Dual Standalone Door Controller with RFID

Surface mounted RFID MIFARE® compatible door controller with keypad. Provides proximity access for up to 600 Code/Card Clients.

The A3 Dual MIFARE® compatible door controller provides a compact, affordable proximity access control system allowing flexible entry for up to 600 users, including two Panic Clients.

Many smaller business buildings are still secured by traditional lock and key, meaning doors can be left unlocked all day leaving them open to possibilities of unauthorised persons gaining access, as well as keys going missing. The A3 Dual door controller offers you a keyless solution as a standalone product; an affordable access control system that does not require complex software purchases, external programmers or licensing costs.

Key Features

  • MIFARE® compatible
  • Configurable penalty time
  • Anti-tamper sensor
  • LED status indicators
  • Surface mount
  • Alarm connection
  • Conforms to IP66 rating

Technical Specs

  • Brand - Access by Codelocks
  • Buttons - 2 x 6
  • Clients – Smart Cards - Up to 600
  • Finish - Black
  • IP Rating - IP66
  • Keypad - 12 individual buttons
  • Lock Dimensions - 2" x 4 7⁄8" x 7⁄8"
  • Lock Material - Zinc Alloy
  • Orientation - Vertical
  • Suitable For - Internal, External
  • Supported Cards - MIFARE® Classic 13.56MHz 14443-3 Type A, MIFARE® DESFire® 13.56MHz ISO/IEC 14443 A 1-4, MIFARE Ultralite® 13.56MHz ISO/IEC 14443 A 1-3
  • User Levels - Master, User, Panic
  • User Types - Code, Card

Downloads and Documentations

Manufacturer Resources

Product Specs

Product Group:
Electronic Access Controls
Series:
A3 Door Controllers
Product Subgroup:
Controllers, Power Supplies and Transformers
Product Type:
Controllers
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Orientation:
Vertical
Product Model:
AL03 DX BK
Product Finish:
Black
Product Dimension:
2" x 4 7⁄8" x 7⁄8"
Product Category:
Electronic Access Controls
Product Substrate:
Zinc Alloy
Department:
Door Hardware

Codelocks AL03DXBK – Frequently Asked Questions

1) Will the Codelocks A3 Dual door controller hold up mounted outside on an exterior door?
Yes. The A3 Dual is rated IP66 and is listed as suitable for internal and external use, so rain and washdown on an exposed entry are within what the housing is built for. The body is zinc alloy in a black finish. It surface mounts, so you are not cutting a pocket into the door or frame to get it on.
2) How many users can the Codelocks A3 Dual controller hold, and can I mix codes and cards?
Up to 600 Code/Card Clients on a single A3 Dual unit, and you do not have to pick one method for the whole building. User types are Code and Card, so one tenant can be a PIN and the next a fob. Three user levels exist: Master, User and Panic, with two of the 600 reserved as Panic Clients. For a small office or a multi-tenant common door, 600 credentials covers turnover for a long time.
3) What RFID cards and fobs work with the Codelocks A3 Dual controller?
It reads MIFARE Classic 13.56MHz 14443-3 Type A, MIFARE DESFire 13.56MHz ISO/IEC 14443 A 1-4, and MIFARE Ultralite 13.56MHz ISO/IEC 14443 A 1-3. All three are 13.56MHz smart card formats. If your existing building credentials are 125kHz proximity fobs, they will not read on this unit and you would be reissuing credentials as part of the job.
4) Do I need software or a licence to run the Codelocks A3 Dual access control system?
No. It is a standalone controller, programmed at the unit itself. No management software purchase, no external programmer, and no licensing cost. That is the trade-off to understand before you commit: you administer credentials at the door rather than from a desk, which suits a handful of openings but gets tedious across a large portfolio where a networked head-end would earn its keep.
5) Is the Codelocks A3 Dual a lock, or do I still need to buy a lock for the door?
It is a controller, not a lock. The A3 Dual reads the code or card and switches the door release; the actual securing device, a strike or maglock, plus its power, is separate and has to be specified with it. Budget the opening as controller, locking device, and power supply. It does have an alarm connection and an anti-tamper sensor built in if you are tying the door into a monitored system.
6) What is the difference between the Codelocks A3 Dual door controller and the Aiphone AC-2DM-B?
The Codelocks A3 Dual is a standalone surface-mounted controller with an integrated 12-button keypad and MIFARE compatible RFID reader on the unit itself, handling up to 600 Code/Card Clients without software, external programmers or licensing costs. The Aiphone AC-2DM-B is a PoE two-door access controller from the AC Series, so it is powered and networked over Ethernet and governs two doors from one controller. Choose the A3 Dual when the credential reader and the control need to be one device at the opening; choose the AC-2DM-B when two openings are being run over a PoE network.
7) Can the Aiphone IMU-100 be used instead of a Codelocks A3 Dual controller?
They solve different problems. The IMU-100 is a controller and operation station kit for the Aiphone IM System, so it is bought as part of an IM Series intercom and entry system. The Codelocks A3 Dual is a self-contained keypad and RFID entry device rated IP66 for internal or external mounting, giving code or card entry to up to 600 users with Master, User and Panic levels and no head-end system behind it. If the door is being answered by a person at a station, the IMU-100 belongs to that architecture; if the user credentials themselves open the door, the A3 Dual does it on its own.
8) Which door controller works for an exterior door without a network drop?
The Codelocks A3 Dual conforms to an IP66 rating and is listed as suitable for internal and external use, and it operates standalone with the keypad and MIFARE compatible reader built into the surface-mounted black zinc alloy body, so no software, external programmer or licensing is involved. The Aiphone AC-2DM-B is a PoE controller, which means it depends on Ethernet reaching the controller location.
9) What stops someone standing at the keypad guessing codes on a Codelocks A3 Dual?
Penalty time, and it is configurable. After repeated wrong entries the keypad locks out for the period you set, so a passer-by cannot sit there running combinations. An anti-tamper sensor covers the other attack, prying the unit off the wall, and it can be wired to your alarm. LED status indicators tell the user what the unit is doing at the point of entry.
10) How many doors does one Codelocks A3 Dual controller run?
The A3 Dual is a single surface-mounted reader and keypad for the opening it is mounted at. If you are controlling several doors from one centrally located panel rather than putting a unit at each door, that is a different architecture. The Aiphone AC-2DM-B is a PoE two-door access controller from the AC Series and takes the multi-door panel approach.
11) I want visitors to be able to call in as well as have staff badge through. Is the A3 Dual the right choice?
No, not on its own. The A3 Dual is a credential reader with a keypad, code or card in and door released. It does not handle visitor call-in or intercom. For an entrance where a visitor needs to reach someone inside, the Aiphone IMU-100 is a controller and operation station kit for the IM Series. Plenty of buildings run both: intercom at the visitor entrance, keypad and card at the staff door.
12) Is the Codelocks A3 Dual rated for commercial use, and what does the keypad look like?
Commercial rated. The keypad is 12 individual buttons laid out 2 x 6 in a vertical format, so it reads as a column rather than the square telephone pad people expect. Worth knowing before a fleet rollout where you are training tenants on a code, the button positions are not where a phone keypad puts them.
13) Does the Codelocks A3 Dual come in any finish other than black?
Black only on the AL03 DX BK. There is one finish across the whole offering, so if you are standardizing hardware across a facility, every A3 Dual you install will match the last one. Housing is zinc alloy.
