Corbin Russwin 463F91-8 Grade 1 ED7000 Flush Bottom Strike

Corbin Russwin 4463F91-8 ED7000 Flush Bottom Strike for Crossbar Exit Devices

Commercial-Grade Flush Bottom Strike for ED7000 Crossbar Exit Devices

The Corbin Russwin ED7000 Flush Bottom Strike is a precision-engineered replacement part and accessory designed specifically for use with ED7000 Crossbar Exit Devices. Built to the exacting commercial-grade standards that Corbin Russwin is known for, this flush bottom strike ensures reliable latching performance in demanding institutional and commercial door hardware applications. Engineered for compatibility with the ED7000 Crossbar Exit Device series, this strike delivers the dependable fit and function required for professional door hardware installations.

Professional Features & Benefits

• Heavy-duty cold-forged steel chassis with electroplated corrosion resistance
• Latchbolt: stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
• Non-handed device (except double cylinder and lever trim which are handed)
• Standard bar length 36" (fits 30"–36" doors); easily field cut; optional 24" or 48"
• Standard single-point 1/4-turn hex key dogging on panic devices
• Free Wheeling levers for vandal resistance on trim
• SecureBolt® option (ED5200S): deadbolt-style latchbolt resists unauthorized entry
• Electrified options including delayed egress, electric latch retraction, and electric dogging
• UL-listed panic and 3-hour fire exit hardware; NFPA 101 and NFPA 80 compliant
• Full range of trim with Muséo® and Vineyard™ collections
• ADA compliant — lever trims and pulls comply with Americans with Disabilities Act
• PathLite™ photoluminescent touchpad cover option available
• Five-year limited warranty; ED5800 CVR certified to 3.25 million cycles

Technical Specifications

• Grade: ANSI/BHMA A156.3 Grade 1
• Handing: Non-handed standard (lever trim and double cylinder devices are handed)
• Bar Length: 36" standard (fits 30"–36" doors); optional 24" or 48"
• Door Thickness: 1-3/4" (44mm) standard; optional 2" (D200) or 2-1/4" (D214)
• Minimum Stile Width: 4-1/2" (114mm)
• Latchbolt — Rim (ED5200): Stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
• Latchbolt — SecureBolt® (ED5200S): Deadbolt-style, 3/4" (19mm) projection x 1" wide, positive deadlocking by auxiliary bolt
• Latchbolt — SVR (ED5400): Top: 3/4" throw pullman-type deadlocking; Bottom: 5/8" throw deadbolt
• Projection: 3-1/4" (83mm) active; 2-3/4" (70mm) dogged
• Dogging: Single-point 1/4-turn hex key; optional cylinder or electric dogging
• Strike: Surface-mounted 3/8" roller strike with positive locking plate and shims
• Certifications: ANSI A156.3 Grade 1; UL/cUL panic and 3-hour fire exit hardware; NFPA 101; NFPA 80; ADA; California State Fire Marshal approved
• Warranty: Five-year limited

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin door hardware accessories are built to the same commercial and institutional standards that define their full product line, including ANSI/BHMA Grade 1 mortise locks, exit devices, and electromechanical hardware. The ED7000 Flush Bottom Strike reflects that commitment to precision manufacturing and reliable performance in demanding environments. When dependable compatibility and long-term durability are required, Corbin Russwin delivers the professional-grade quality that commercial and institutional facilities depend on.
