Delta Breez Integrity - 100 CFM Fan/Edge-lit Dimmable LED Light

Delta Breez Integrity - 100 CFM Fan/Edge-lit Dimmable LED Light

(No reviews yet) Write a Review

Model: ITG100ELED
From the BreezIntegrity Collection
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$156.83
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The Builder’s Choice for Green Construction.
Delta BreezIntegrity ITG100ELED is ENERGY STAR® qualified with DC brushless motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 100 CFM and loudness rating of 1.5 Sones at 0.1 static pressure as certified by the Home Ventilating Institute (HVI); power consumption of 17.0 Watts with efficiency rating of 7.5 CFM/Watts at 0.1” static pressure; motor lock protection and self-compensating motor speed for intended airflow when static pressure is encountered. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.

Features

  • 100 CFM single speed fan for spaces up to 100 Sq. Ft.
  • brushless DC Motor outlasts typical AC motors by 2-1/2.
  • Quiet at 1.5 sones.
  • Energy star®-qualified.
  • Compact housing for easy retrofit and replacement of older bath fans.
  • 13-Watt Dimmable Edge-lit LED light (equivalent to a 60-Watt incandescent bulb), Dimmer switch not included.
  • Main light output: 1000 Lumens; 3000K; 80 CRI for high color accuracy.

Product Specs

Subcategory:
BreezIntegrity
Static Pressure:
0.1 - 0.25
Maximum CFM:
84
Sones:
1.5 - 2.0
Energy Efficiency:
7.5 - 5.9
Current:
0.47 Max
LED Light (Watt):
13
Duct Diameter:
4"
Energy Star:
Yes
Warranty:
3 Year Limited
Product Group:
Washroom/Bath
Product Subgroup:
Ventilation Fans
Collection:
BreezIntegrity
Product Voltage:
120/60
Product Height:
5-3/4"
Product Category:
Ventilation Fans
Product Width:
11-3/4"
Department:
Plumbing
Product Wattage:
17.0 - 20.0
Product Depth:
11-3/4"

Delta Breez ITG100ELED – Frequently Asked Questions

1) Will the ITG100ELED fit in the ceiling opening left by my old bath fan?
The housing measures 11-3/4 x 11-3/4 x 5-3/4 inches, and Delta builds the Integrity series with a compact housing specifically for retrofit and replacement of older bath fans. Check your joist bay depth against the 5-3/4 inch dimension before you cut, especially in a shallow bay or under a low-clearance attic.
2) Can this Delta Breez fan and light be installed over a tub or inside a shower?
Yes. The Integrity ITG100ELED is UL and cUL listed for use in a tub or shower enclosure, provided the branch circuit feeding it is GFCI protected. That GFCI requirement is on you as the installer, not something the fan supplies.
3) Do I need a dimmer switch for the LED light on the ITG100ELED, and is one included?
The 13 watt edge-lit LED is dimmable, but the dimmer switch is not included. You supply it, and it needs to be an LED-compatible dimmer. Run without a dimmer it works fine as a standard on/off light.
4) How big a bathroom will a 100 CFM Delta Breez Integrity fan handle?
It's rated for spaces up to 100 square feet as a single speed 100 CFM unit. For a larger master bath, or one with an enclosed water closet, plan on a higher CFM unit or a second fan rather than stretching this one.
5) How bright is the light, and will it be enough on its own in a small bathroom?
Main light output is 1000 lumens at 3000K with 80 CRI, which the manufacturer puts as equivalent to a 60 watt incandescent bulb. In a powder room or a small full bath that's typically the only ceiling fixture you need; over a vanity most people still add task lighting at the mirror.
6) What circuit and wiring does the Delta Breez ITG100ELED draw?
120V/60Hz, 0.47 amps max, with total power draw in the 17.0 to 20.0 watt range. That's a light enough load to share a standard 15A bathroom branch circuit, and the circuit has to be GFCI protected if the unit sits over a tub or shower.
7) Is this bath fan quiet enough for a bedroom-adjacent bathroom or a hotel guest bath?
Rated 1.5 sones at 0.1 inch static pressure and 2.0 sones at 0.25 inch, certified by the Home Ventilating Institute. At 1.5 sones it's in the range multi-family and hospitality specs usually call out. Keep the duct run short and straight with 4 inch pipe to stay near the 1.5 figure rather than the 2.0.
8) Does the Delta Breez Integrity ITG100ELED qualify for ENERGY STAR and green building credits?
Yes, it's ENERGY STAR qualified, with an efficiency rating of 7.5 CFM/Watt at 0.1 inch static pressure (5.9 CFM/Watt at higher pressure). Delta positions the Integrity line for green construction, and the 7.5 CFM/W figure is the number you'd cite on a submittal for ventilation efficiency credits.
9) Can this fan run continuously for whole-house or code-required continuous ventilation?
The DC brushless motor is engineered to run continuously for a minimum of 70,000 hours, which is what makes it suitable for continuous-run duty where a code or program requires it. It also has motor lock protection and self-compensating speed control that holds the intended airflow when static pressure rises in the duct.
10) Why does this fan list 100 CFM in the name but 84 CFM in the specs?
The 100 CFM figure is the HVI-certified airflow at 0.1 inch static pressure. The 84 CFM value is what the unit delivers at the higher 0.25 inch static pressure point, which is what you'd see with a longer duct run, flex pipe, or elbows. Size your ductwork for the number you actually need at the far end.
11) Is there an installation manual or submittal sheet for the Delta Breez ITG100ELED?
Both are published as PDFs: an installation manual and a submittal spec sheet, hosted at zensupply.com/content/pdf/delta-breez/ITG100ELED_IM.pdf and ITG100ELED_Submittal_Sheet_e.pdf. The submittal sheet is the one to hand to an inspector or attach to a spec package.
