Dormakaba 80015-RH – Frequently Asked Questions
1) Will the Dorma 80015 spindle work with a BTS series floor closer?
The 80015 interchangeable spindle is built for Dorma BTS series floor closers. It's a replacement spindle, so it goes into an existing BTS closer body rather than being a closer itself. If your floor closer is anything other than a BTS, this is the wrong spindle.
2) Do I need to order the Dorma 80015 spindle left hand or right hand?
Handing is a real choice on the 80015, not a formality. It's offered as LH - Left Hand and RH - Right Hand, and you order to match the door. Stand outside the opening (the side you'd key from) and note which side the hinges/pivot point falls on. Model 80015 RH is the right hand version. Order the hand that matches the existing door swing setup, because the spindle drives the closer arm in one direction.
3) Is the Dorma 80015 spindle for a center hung door or an offset pivot door?
Center hung only. The 80015 is a center hung spindle, meaning the door pivots on the closer's own centerline at the floor. If your door runs on offset pivots, the spindle geometry is different and this part won't set the door where it needs to sit.
4) Can the Dorma 80015 spindle be used on a double acting door?
No. The 80015 is a single acting package, so it suits a door that swings one way only. A double acting door that swings both directions needs the double acting spindle package for the BTS closer instead.
5) Do I have to replace the whole floor closer if the spindle is worn out?
Not necessarily. The 80015 is an interchangeable replacement spindle for the BTS series, so a worn or damaged spindle can be swapped without pulling and repouring the closer case. Match three things when you order: BTS closer, center hung, single acting, and the correct hand.
6) How many spindles come in the Dorma 80015 package?
The 80015 ships as a package of 2. Worth knowing if you're doing a pair of doors, or if you want a spare on the shelf for a second opening.
7) Is the Dorma 80015 closer spindle rated for commercial traffic?
It's a commercial grade part, made for Dorma BTS floor closers in storefront, office and institutional entrances rather than residential doors. As a replacement spindle it carries the same duty as the closer it goes into.
