Eaton Main Lug Kit, 200A, Two-Pole, Stud Mount
The Eaton Main Lug Kit is a 200A, two-pole main lug assembly with stud mounting, engineered for use with Type BR Loadcenters and Circuit Breakers. Rated for 120/240V, 208Y/120, and 240V systems, this kit accepts #1 AWG-300 kcmil Cu/Al conductors, making it a versatile upgrade or replacement solution for residential and light commercial panels. It is UL Listed and backed by a 10 year warranty for dependable, code-compliant performance.
Key Features
- Amperage Rating: 200A rated main lug kit suited for high-capacity load center applications.
- Two-Pole Configuration: Two-pole design built for compatibility with Type BR loadcenter systems.
- Stud Mounting: Stud-mount connection provides a secure, code-compliant installation point.
- Wire Range: Accepts #1 AWG up to 300 kcmil Cu/Al conductors for flexible wire sizing on the job.
- Voltage Rating: Rated for 120/240V, 208Y/120, and 240V electrical systems.
- Compatibility: Designed specifically for use with Type BR Loadcenters and Circuit Breakers.
- Compact Footprint: Measures 1 in wide by 1 in deep by 1 in high for space-efficient panel installation.
Certifications & Compliance
- UL Listed
Technical Specifications
- Warranty: 10 year
- Department: Electrical
Typical Applications
- Residential and Light Commercial Electrical Panels
- Type BR Loadcenter Upgrades and Retrofits
- Main Service Entrance Wiring
- Panelboard and Load Center Wiring
- New Construction and Panel Renovation Projects
Why Eaton?
Eaton's Main Lug Kit combines a UL Listed rating with a broad #1 AWG-300 kcmil Cu/Al wire range and 200A capacity, giving electrical professionals a dependable option for Type BR loadcenter installations. Backed by a 10 year warranty, it delivers the reliability and code-compliant construction needed for demanding residential and light commercial electrical work.
Manufacturer Resources
Product Specs
- Warranty:
- 10 year
- Department:
- Electrical
- Product Length/Depth:
- 1 in
- Product Height:
- 1 in
- Product Width:
- 1 in
- Certifications:
- UL Listed
- Product Type:
- Equipment Lug Kit
- Amperage Rating:
- 200A
- Voltage Rating:
- 120/240V
- Configuration:
- Two-Pole
- Listing:
- UL Listed
- Product Group:
- Wire Connectors & Terminals
- Product Subgroup:
- Lugs & Terminals
- Product Length:
- 1 in
- Product Weight:
- 1 lb
Eaton BRL200 – Frequently Asked Questions
1) What wire size can I land in the Eaton 200A main lug kit?
The lugs take #1 AWG through 300 kcmil, copper or aluminum. That covers the usual 200A service conductor sizes, including 4/0 aluminum SER and 2/0 copper feeders, in either material without changing lugs.
2) Can an ABB A-Series main lug kit be used in an Eaton Type BR loadcenter instead of the BRL200?
No. The Eaton BRL200 main lug kit is a 200A two-pole stud-mount assembly engineered specifically for Eaton Type BR loadcenters and circuit breakers, and the mounting and bus interface are matched to that panel. The ABB A-Series main lug kit is built with pressure-type lugs for copper or aluminum bus in ABB A-Series equipment, so it belongs in that enclosure family rather than a Type BR panel. Match the lug kit to the panel line you are working in.
3) I need a three-pole main lug kit for a Type BR panel - is there an Eaton option?
Yes. Alongside the two-pole BRL200, Eaton offers the three-pole 3BRL225 under the same main lug kit family for Type BR loadcenters. Choose the two-pole version for 120/240V single-phase service and the three-pole version where a three-pole main lug landing is required. The ABB A-Series main lug kit is a separate product line intended for ABB A-Series equipment and is not an alternative for a BR panel.
4) Can I use this Eaton main lug kit on a 208Y/120 three-phase system?
The kit is rated for 120/240V, 208Y/120 and 240V systems. For a 208Y/120 three-phase panel you want the three-pole 3BRL225; the two-pole BRL200 is the single-phase 120/240V part.
5) Is the Eaton BRL200 main lug kit UL Listed for a service entrance panel?
Yes, it carries a UL Listing. It is rated 200A and is used for main service entrance wiring and panelboard feeds in residential and light commercial work.
6) Can I convert an Eaton BR main breaker panel to main lug only with this kit?
That is the job this kit is sold for. It is a 200A two-pole main lug assembly for Type BR loadcenter upgrades and retrofits, so it replaces or takes the place of the main connection point when a BR panel is being fed as a subpanel or rebuilt. Confirm the panel bus is rated 200A or higher before fitting a 200A lug kit.
7) What is the difference between the Eaton BRL200 and the ABB A-Series main lug kit?
The Eaton is a 200A two-pole stud-mount kit made for Eaton Type BR loadcenters. The ABB A-Series kit uses pressure-type lugs for copper or aluminum bus and belongs to ABB A-Series equipment. Main lug kits are not cross-brand parts, so match the kit to the panel line you actually have in the wall.
8) What is the difference between a stud-mount main lug kit and a pressure-type lug kit?
The Eaton BRL200 uses stud mounting, which gives a fixed bolted connection point in the panel for the incoming service conductors and accepts #1 AWG through 300 kcmil copper or aluminum wire. The ABB A-Series main lug kit uses pressure-type lugs that clamp the conductor against copper or aluminum bus. Both terminate service conductors; the difference is how the lug body attaches and how the conductor is secured, so confirm which style the panel bus is prepped for.
9) If I am standardizing lug kits across a facility, does UL listing differ between the Eaton and ABB kits?
The Eaton 200A main lug kit is UL Listed and carries a 200A amperage rating with a 120/240V, 208Y/120 and 240V voltage rating, which is the documentation most inspectors and facility specs ask for on a service entrance landing. The ABB A-Series main lug kit is an A-Series product with pressure-type lugs for copper or aluminum bus. Standardization here is driven by panel line more than by the lug kit itself, so specify by the loadcenter family already installed.
