Eaton Thermal Magnetic Circuit Breaker Four-Pole 20A 120/240V 10kAIC BR Type Quad Common Trip

Eaton BR Type Quad Circuit Breaker Four-Pole 20A 120/240V 10kAIC Common Trip

(No reviews yet) Write a Review

Model: BRDC220220

In Stock (leaves warehouse same day if ordered before 3pm ET)

$84.37
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton BR Type Quad Circuit Breaker Four-Pole 20A 120/240V 10kAIC Common Trip

Professional Four-Pole Circuit Protection with Common Trip Technology

The Eaton BR Type Quad Circuit Breaker delivers reliable four-pole circuit protection with 20A rating per pole and 120/240V operation. This thermal magnetic circuit breaker features 10kAIC interrupt rating and common trip functionality, providing coordinated protection across all four poles. The compact 1-inch quad design maximizes panel space efficiency while maintaining UL 489 certified performance for professional electrical installations.

Professional Features & Benefits

  • 20A Four-Pole Rating: Provides dual 20A protection circuits in a space-efficient quad configuration for versatile load management.
  • 10kAIC Interrupt Rating: Delivers robust fault current interruption capability for reliable protection in demanding electrical environments.
  • Common Trip Technology: Ensures coordinated breaker operation across all poles for enhanced safety and system protection.
  • BR Type Compatibility: Designed specifically for Type BR loadcenters ensuring proper fit and electrical performance.
  • UL 489 Certification: Meets rigorous safety and performance standards for professional electrical applications.
  • Thermal Magnetic Operation: Combines thermal overload and magnetic short-circuit protection for comprehensive circuit safeguarding.
  • Compact Quad Design: 1-inch quad configuration maximizes panel space utilization while providing four-pole protection.

Technical Specifications

  • Amperage Rating: (2) 20A, (2) 20A
  • Catalog Notes: Non-CTL
  • Certifications: UL 489
  • Circuit Breaker Type: BR
  • Compliances: Federal Specifications Classification W-C375
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: BR
  • Number Of Poles: Four-pole
  • Product Details: Type BR 1-Inch quad circuit breaker
  • Product Height: 3 in
  • Product Length Depth: 2 in
  • Product Weight: .78 lb
  • Product Width: 2 in
  • Trip Type: Common breaker trip
  • Used With: Type BR Loadcenters
  • Voltage Rating: 120/240 V
  • Wire Size: #14-4 AWG Cu/Al

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Residential Electrical Panels
  • Commercial Building Distribution
  • Multi-Unit Properties
  • Professional Offices
  • Retail Establishments
  • Light Industrial Facilities
  • Emergency Services Buildings

Why Choose Eaton Quality?

Eaton BR circuit breakers provide dependable electrical protection with UL 489 certification and Federal Specifications compliance. The robust thermal magnetic design and 10kAIC interrupt rating ensure reliable performance in professional electrical systems, backed by Eaton's commitment to electrical safety and quality engineering.

Manufacturer Resources

Product Specs

Amperage Rating:
(2) 20A, (2) 20A
Catalog Notes:
Non-CTL
Certifications:
UL 489
Circuit Breaker Type:
BR
Compliances:
Federal Specifications Classification W-C375
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
BR
Number Of Poles:
Four-pole
Product Details:
Type BR 1-Inch quad circuit breaker
Product Height:
3 in
Product Length Depth:
2 in
Product Weight:
.78 lb
Product Width:
2 in
Trip Type:
Common breaker trip
Used With:
Type BR Loadcenters
Voltage Rating:
120/240 V
Wire Size:
#14-4 AWG Cu/Al
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
