Product Specs
- Country Of Origin:
- Canada
- Csa Cert :
- LR21001
- Ip Rating:
- IP66
- Panel:
- Included
- Product Height:
- 12
- Product Material:
- Mild Steel
- Product Weight:
- 15 lbs
- Product Width:
- 12
- Reach Compliant:
- Yes
- Rohs Compliant:
- Yes
- Standards:
- csa, ul, ce, taa-compliant
- Type Rating:
- type-3r, type-12, type-13, type-4
- Ul File :
- E65324
- Usmca Compliant:
- Yes
- Product Depth:
- 6
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Subgroup:
- Weatherproof Enclosures
- Product Type:
- Hinged Cover Enclosure
Hammond Manufacturing EJ12126 – Frequently Asked Questions
1) Is the Hammond EJ12126 enclosure rated for outdoor or washdown use?
The EJ12126 Eclipse Jr. carries Type 4, Type 3R, Type 12 and Type 13 ratings, plus an IP66 rating. That covers outdoor rain and sleet exposure (3R), hose-directed water and windblown dust (Type 4 / IP66), and oil and coolant environments indoors (12/13). It is UL and CSA recognized under UL file E65324 and CSA LR21001.
2) What size is the Hammond EJ12126 Eclipse Jr. enclosure, and will a 12 x 12 backplate fit?
The EJ12126 body measures 12 inches high by 12 inches wide by 6 inches deep, so the usable mounting area behind the door is smaller than 12 x 12. You don't need to source a plate separately: a panel is included with the enclosure and it is sized to the box.
3) Is the Hammond Eclipse Jr. EJ12126 stainless steel or painted steel?
Mild steel, not stainless. For coastal, food-processing, or chemical washdown areas where chlorides attack painted carbon steel, specify a stainless Type 4X box instead. For general industrial, outdoor utility, and machine-side control panels, the mild steel Eclipse Jr. is the standard choice.
4) Is the Hammond EJ12126 TAA compliant for a government or federal job?
Yes. The EJ12126 is listed TAA-compliant and is made in Canada, a designated country, and it is also USMCA compliant. It carries UL, CSA and CE marks, and it is RoHS and REACH compliant, which covers most institutional and federal procurement checklists.
5) Does the Hammond EJ12126 come with a back panel or do I have to order one?
A mounting panel ships with it. That's a real cost difference against enclosures sold panel-less, where the backplate is a separate line item. One door, wall mount configuration.
6) How heavy is the Hammond EJ12126 and can one person hang it on a wall?
It weighs 15 lbs empty, so a single installer can set it, though with the panel and components loaded you'll want two hands and anchors rated well above that. It's a wall-mount box, not free-standing or floor-mount.
7) Can I drill conduit knockouts into the Hammond EJ12126 and keep the Type 4 rating?
Only if you use fittings rated for the environment. The EJ12126 ships without knockouts, and any hole you cut has to be sealed with a Type 4 / IP66 rated hub or cord grip to preserve the enclosure's Type 4 and IP66 performance. An ordinary locknut-and-bushing connector will drop it to a general purpose box.
8) What is the exact part number for the 12 x 12 x 6 single-door Eclipse Jr. wall mount enclosure?
EJ12126 from Hammond Manufacturing. The number reads off the dimensions: 12 high, 12 wide, 6 deep. It's the one-door wall mount version of the Eclipse Jr. line.
