Emtek 15A2 Multi Point Lock Tr...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$381.00
$304.80
Emtek Emtek 15A2 Multi Point Lock Trim (Door Config #5) - Brass Plates, Modern Style (1.5" x 11"), Non-Keyed Passage EMTEK-15A2

Emtek 15A2 Multi Point Lock Trim (Door Config #5) - Brass Plates, Modern Style (1.5" x 11"), Non-Keyed Passage

(No reviews yet) Write a Review

Model: 15A2-US19
From the Brass Collection
$381.00
$304.80
Selected Finish is
Selected Lever Style is
Selected Handing is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$381.00
$304.80
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like



Specifications:

  • Backset: Adjustable 2-3/8" or 2-3/4"
  • Cross Bore: 2-1/8"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Latch Faceplate: Round or Square Corner
  • Material: Brass



Emtek 15A2 Multi Point Lock Trim (Door Config #5) - Brass Plates, Modern Style (1.5" x 11"), Non-Keyed Passage

  • Can be ordered with any Brass Levers
  • Swinging Patio Door Hardware. Set includes Plates, Handles
  • Multi Point Mortise Lock Box not included. Trims Only
  • Each Multi Point Lock Trim now includes the Spring Assist function which returns the lever to the neutral position and eliminates sagging handles.
Manufacturer Resources

Product Specs

Subcategory:
Multi Point Lock Trim
Product Group:
Mechanical Locks
Commercial/Residential:
Residential
Product Type:
Multi Point Lock Trim
Product Subgroup:
Multi Point Lock Trim
Collection:
Brass
Cylinder Position:
Below Handle
Door Configuration:
#5
Electronic:
No
Keyed:
No
Lock Type:
Multi Point Trim
Ref. Door Manufacturer(s):
Crestline, Hoppe, Hurd, KFV, Kolbe & Kolbe, Lincoln, Loewen, Paddock Lockmaster, Peachtree, Semco, Sierra, Oknoplast, Pacific, Signature, Simpson, Therma-Tru, Vetter, Willmar, Windsor, Weathershield
Series:
Modern
Theme:
Contemporary
Keyed Function:
Non-Keyed
Lock Function:
Passage
MAP Policy:
Yes
Product Model:
15A2
(CTC) Center-to-Center:
3-5/8"
Product Function:
Non-Keyed Passage
Product Size:
1-1/2" x 11"
Cylinder Classification:
Euro Profile
Product Style:
Modern
Product Material:
Brass
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Emtek 15A2-US19 – Frequently Asked Questions

1) Which patio door brands does the Emtek 15A2 multi point trim work with?
Emtek lists this trim against Crestline, Hoppe, Hurd, KFV, Kolbe & Kolbe, Lincoln, Loewen, Paddock Lockmaster, Peachtree, Semco, Sierra, Oknoplast, Pacific, Signature, Simpson, Therma-Tru, Vetter, Willmar, Windsor and Weathershield doors. Brand alone doesn't settle it, though, since those makers used several hole patterns. Confirm your door matches Configuration #5 with the cylinder below the handle at 3-5/8 inch centers.
2) Will the Emtek 15A2 trim fit my existing patio door prep?
It works to Emtek's Door Configuration #5 hole pattern, with a 3-5/8 inch center-to-center between the handle spindle and the Euro profile cylinder hole, and the cylinder sits below the handle. Measure your door: if your existing plate has a different spacing or the cylinder is above the handle, this is the wrong configuration. Cross bore is 2-1/8 inches and backset is adjustable 2-3/8 or 2-3/4 inches, door thickness 1-3/8 to 1-3/4 inches.
3) What do I have to specify when ordering Emtek 15A2 multi point trim?
Four things. Finish, from oil rubbed bronze (US10B), lifetime polished nickel (US14), satin nickel (US15), flat black (US19), polished chrome (US26), unlacquered brass (US3NL), or satin brass (US4). Lever style, from the full brass lever range (L-Square, T-Bar and R-Bar in Faceted, Hammered, Knurled, Tribeca, Straight Knurled and White Marble, plus Athena, Helios, Hermes, Luzern, Poseidon, Stuttgart and the rest). Handing, right or left. And your door thickness.
4) How big are the Emtek 15A2 plates, and will they cover my old escutcheon?
The plates measure 1-1/2 x 11 inches in the Modern style. That is a narrow contemporary plate, so if you are replacing a wider or longer traditional escutcheon it will not hide the old screw holes or finish shadow on the door face. Compare against what's on the door before you pull the old set.
5) What cylinder does the Emtek 15A2 multi point trim take?
Euro profile, mounted below the handle. That's the standard cylinder format on multi point patio gearboxes, so a Euro profile cylinder of the right length for your door thickness is what you match to. This particular trim is the non-keyed passage version.
6) Is the Emtek 15A2 trim solid brass, and how does that hold up outdoors?
Solid brass, both the plates and the levers. Brass is the substrate under every finish offered, including unlacquered brass (US3NL), which is the one that will patina with exposure rather than hold its shade. If you want a stable appearance on a sun-facing patio door, the plated finishes such as satin nickel (US15) or flat black (US19) are the steadier choice.
7) Can I match this Emtek patio door trim to the other doors in the house?
Yes, within the brass collection. The 15A2 takes any of Emtek's brass levers and comes in seven finishes, so you can carry the same lever design and the same finish code (for example US15 satin nickel or US19 flat black) across the interior doors and the patio door. Note the plate here is the Modern 1-1/2 x 11 inch shape, so the patio door will read as a plate rather than a rosette even with matching levers.
