NGP 119NDKB Aluminum Neoprene Door Shoe with EPDM Rubber - Dark Bronze Finish

NGP 119NDKB Aluminum Neoprene Door Shoe with EPDM Rubber - Dark Bronze Finish

(No reviews yet) Write a Review

Model: 119NDKB-36

In Stock (leaves warehouse same day if ordered before 3pm ET)

$73.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

NGP Aluminum Neoprene Door Shoe with EPDM Rubber - Dark Bronze Finish

Professional Door Bottom Sealing Solution

The NGP Aluminum Neoprene Door Shoe delivers superior door bottom sealing performance with aluminum alloy 6063 T5 temper construction and synthetic EPDM rubber in polypropylene thermoplastic matrix. This commercial-grade door shoe operates effectively in temperature ranges from -81 F to 275 F and features BHMA certification to ANSI/BHMA A156.22 performance tests for heat and cold. The dark bronze finish provides an attractive appearance while the included #6 x 3/4" stainless steel SMS fasteners ensure secure installation.

Professional Features & Benefits

  • Temperature Performance: Operates reliably from -81 F to 275 F for extreme weather applications and demanding environmental conditions.
  • Premium Construction: Aluminum alloy 6063 T5 temper frame with synthetic EPDM rubber in polypropylene thermoplastic matrix provides exceptional durability and longevity.
  • Superior Material Properties: Very good abrasion resistance, tensile strength and memory ensure consistent sealing performance over extended service life.
  • Weather Resistance: Flame-resistant and moisture-resistant design with good resistance to ozone, sunlight and aging for outdoor applications.
  • BHMA Certification: Certified to ANSI/BHMA A156.22 performance tests for heat and cold ensuring compliance with industry standards.
  • Adjustable Installation: Screw holes slotted for adjustment allow precise positioning and alignment during installation.
  • Complete Hardware: Includes #6 x 3/4" stainless steel SMS fasteners for secure mounting and corrosion resistance.
  • Professional Finish: Dark bronze finish with black EPDM rubber provides attractive appearance suitable for commercial applications.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Type: Door Shoes
  • Series: Neoprene Door Shoe Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose NGP Quality?

NGP door shoes deliver professional-grade reliability with aluminum alloy 6063 T5 temper construction and BHMA certification to ANSI/BHMA A156.22 performance standards. The synthetic EPDM rubber material provides very good abrasion resistance, tensile strength and memory for consistent long-term performance. Engineered for demanding commercial applications where dependable weathersealing and temperature performance from -81 F to 275 F is essential.

Product Specs

Product Group:
Door Trim and Accessories
Series:
Neoprene Door Shoe Series
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Shoes
Subcategory:
Gaskets & Weatherstripping
Commercial/Residential:
Commercial
Product Category:
Door Trim and Accessories
Department:
Door Hardware

NGP 119NDKB-36 – Frequently Asked Questions

1) Will an aluminum door shoe with EPDM hold up on an exterior door in a cold climate?
Rated from -81 F to 275 F, so the EPDM insert on the 119NDKB stays flexible well past anything a North American winter produces and does not go brittle and crack the way some vinyl inserts do. The rubber is also flame resistant and moisture resistant with good resistance to ozone, sunlight and aging, and the frame is 6063 T5 aluminum. That combination is what makes it an exterior-door part rather than an interior one.
2) What is the difference between an EPDM door shoe insert and a vinyl one?
EPDM is a synthetic rubber, and on the NGP 119NDKB it is held in a polypropylene thermoplastic matrix with very good abrasion resistance, tensile strength and memory. Memory is the one that matters on a high-traffic door: the insert keeps returning to shape after being compressed thousands of times, so the seal does not flatten out and stop touching the threshold. Vinyl inserts are the common alternative - the Cal-Royal DS-403 uses a vinyl insert, and the Pemko 209, 211V and 215 use an Eco-V vinyl insert. Vinyl is standard for typical interior and moderate-duty exterior work; the EPDM version is what to reach for on doors that cycle constantly or sit in hard weather.
3) What door shoe should I use on a fire rated opening instead of the NGP 119NDKB?
For an opening where the drawing calls out a fire rated door bottom shoe, the Pemko 210 is a fire rated door bottom shoe with an Eco-V insert in 36 inch aluminum construction, and the Pemko 215 is a fire rated shoe that is UL10C certified and adds a rain drip. The NGP 119NDKB is a commercial aluminum shoe with an EPDM sweep certified to ANSI/BHMA A156.22 heat and cold performance tests. Match the shoe to what the fire door assembly requires.
4) What is the difference between the NGP 119NDKB door shoe and the Pemko 209?
Both are door bottom shoes that mount to the face of the door and carry a replaceable insert. The NGP 119NDKB uses a synthetic EPDM rubber sweep in a dark bronze aluminum shoe, with slotted screw holes for height adjustment and #6 x 3/4 inch stainless steel SMS fasteners included, and it comes in 36 inch and 48 inch lengths. The Pemko 209 carries an Eco-V vinyl insert on a 1/2 inch x 1-3/8 inch profile. If the sweep material matters to you - EPDM versus vinyl - that is the line between them.
5) I need a door shoe with a rain drip for an exterior door - what are my options?
The Pemko 211V is an L-shaped door shoe with a rain drip and a GREENGUARD Gold certified Eco-V insert, and the Pemko 215 is a fire rated shoe with a rain drip and Eco-V insert that is UL10C certified. The NGP 119NDKB is a straight aluminum shoe with an EPDM rubber sweep, flame resistant and moisture resistant with good resistance to ozone, sunlight and aging, and it holds its seal from -81 F to 275 F. Pick by whether the opening needs the drip cap to throw water off the face of the door.
6) Does the NGP 119NDKB door shoe come with mounting screws?
Yes, #6 x 3/4 inch stainless steel sheet metal screws ship with the shoe, so nothing extra is needed to fasten it to the door. The screw holes are slotted, which lets you set the height of the shoe against the threshold before you tighten down. On a door that has settled or where the floor is uneven, that adjustment is what gets an even seal across the full width instead of a gap at one end.
7) Is the NGP 119NDKB door shoe BHMA certified?
It is certified to the ANSI/BHMA A156.22 performance tests for heat and cold. If you are writing a spec for a school, hospital, or government building that calls for A156.22 gasketing, this shoe meets that reference for the heat and cold criteria. That is the certification a facilities or MRO buyer usually needs on paper before the submittal gets approved.
8) What finish is the NGP 119NDKB and will it match dark bronze storefront hardware?
Dark bronze aluminum with a black EPDM insert. That is the finish that goes with dark bronze anodized storefront and entrance framing, so on a glass front or aluminum entrance it disappears into the frame rather than drawing a bright silver line across the bottom of the door. Property managers standardizing a building on dark bronze can run the same shoe across the whole set of exterior leaves in 36 and 48 inch.
9) If I need a GREENGUARD certified door shoe instead, what should I order?
The Pemko 211V is the one to look at - it is an L-shaped door shoe with a rain drip and a GREENGUARD Gold certified Eco-V insert. That is the part to quote when a LEED submittal or an owner's low-emission materials standard drives the selection. The NGP 119NDKB is certified to the ANSI/BHMA A156.22 heat and cold tests, which speaks to weather performance rather than indoor air quality.
10) Is the Cal-Royal DS-403 the same thing as the NGP 119NDKB door shoe?
They are the same class of part - an aluminum door shoe that fastens to the door face and carries a bottom insert - but the seal material differs. The Cal-Royal DS-403 is an aluminum door shoe with a vinyl insert. The NGP 119NDKB is an aluminum alloy 6063 T5 shoe with a synthetic EPDM rubber sweep in a polypropylene thermoplastic matrix, in a dark bronze finish with black rubber. If you are matching an existing run of doors, confirm the insert material and the finish before you treat one as a drop-in for the other.
11) Which door shoe holds up best in extreme heat or cold?
The NGP 119NDKB is rated to work from -81 F to 275 F and is BHMA certified to the ANSI/BHMA A156.22 performance tests for heat and cold, with an EPDM rubber sweep that offers very good abrasion resistance, tensile strength and memory. The Pemko 209, 210, 211V and 215 are all door bottom shoes carrying Eco-V vinyl inserts. For a freezer vestibule, a rooftop mechanical room, or an unconditioned loading dock, the temperature range is the spec to compare.
12) Can I use the Pemko 211V in place of the NGP 119NDKB on the same door?
Not as a like-for-like swap. The Pemko 211V is L-shaped and carries a rain drip, so it projects off the face of the door differently than a straight shoe and can foul a threshold, a closer arm, or a storefront frame that the NGP 119NDKB clears. The 119NDKB is a straight aluminum shoe with slotted screw holes for adjustment. Check the projection at the bottom rail before substituting one profile for the other.
13) Which door shoe should I specify if my facility has a low-emitting materials requirement?
The Pemko 211V carries a GREENGUARD Gold certified Eco-V insert, which is the one in the group that names that certification. The NGP 119NDKB uses a synthetic EPDM rubber in a polypropylene thermoplastic matrix and is BHMA certified to ANSI/BHMA A156.22. If your school, healthcare, or LEED project scores indoor air quality on the submittal, that certification is the deciding line.
14) Is the NGP 119NDKB door shoe rated for commercial use or is it a residential part?
Commercial. It is built for office buildings, schools, healthcare, retail, industrial and warehouse buildings, multi-tenant residential and government facilities - openings where the door cycles all day and the seal has to survive it. Nothing stops it going on a house door, but the 6063 T5 aluminum carrier and EPDM insert are sized for commercial traffic.
