NGP 99TDKB Extended Door Shoe with Thermoplastic Insert - Aluminum Construction with PVC Seal

NGP 99TDKB Extended Door Shoe with Thermoplastic Insert - Aluminum Construction with PVC Seal

(No reviews yet) Write a Review

Model: 99TDKB-36

In Stock (leaves warehouse same day if ordered before 3pm ET)

$144.97
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

NGP Extended Door Shoe with Thermoplastic Insert - Aluminum Construction with PVC Seal

Professional Door Sealing Solution for Commercial Applications

The NGP Extended Door Shoe combines durable aluminum alloy 6063 T5 temper construction with an environmentally friendly thermoplastic polymer seal for effective door bottom weatherization. This economical door shoe features a rigid aluminum base with soft vinyl fins in dark brown, providing reliable moisture resistance and flame resistance across a temperature range of 0 F to 140 F. The thermoplastic seal utilizes Polyvinyl Chloride (PVC) formulated with bio-based plasticizer for enhanced environmental performance.

Professional Features & Benefits

  • Temperature Performance: Operates effectively from 0 F to 140 F for reliable performance across varying climate conditions.
  • Durable Aluminum Construction: Aluminum alloy 6063 T5 temper provides exceptional strength and corrosion resistance with anodized finish protection.
  • Environmentally Friendly Seal: Thermoplastic polymer PVC formulated with bio-based plasticizer reduces environmental impact while maintaining performance.
  • Moisture and Flame Resistance: Engineered seal material provides reliable protection against moisture infiltration and meets flame resistance requirements.
  • Complete Hardware Package: Includes #6 x 3/4" stainless steel SMS fasteners for secure installation and long-term durability.
  • Customization Options: Available with notched fins (suffix "NF") for specialized applications requiring modified seal configuration.
  • Professional Installation: End caps available separately for complete installation flexibility and finished appearance.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Type: Door Shoes
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose NGP Quality?

NGP door shoes deliver professional-grade weatherization with aluminum alloy 6063 T5 temper construction and environmentally friendly thermoplastic seals rated for 0 F to 140 F temperature performance. The anodized aluminum finish and stainless steel hardware provide long-term durability and corrosion resistance. Engineered for demanding commercial applications where reliable door bottom sealing and moisture protection are essential.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Shoes
Subcategory:
Gaskets & Weatherstripping
Commercial/Residential:
Commercial
Product Category:
Door Trim and Accessories
Department:
Door Hardware

NGP 99TDKB-36 – Frequently Asked Questions

1) I need a door shoe on a fire-rated opening - can I use the NGP 99TDKB?
For a rated opening, look at the Pemko 210, a fire-rated door bottom shoe in aluminum construction at 36 inches, or the Pemko 215, a fire-rated door shoe with rain drip whose insert package is UL10C certified. The NGP 99TDKB is described as a flame-resistant thermoplastic seal on a 6063 T5 aluminum base rated 0 F to 140 F, which is a material property and not a rated-assembly listing. When the drawing calls out a fire label, specify the shoe that carries the certification - the Pemko 215 for a UL10C callout, the Pemko 210 where a 36 inch fire-rated shoe is what the opening takes.
2) What is the closest equivalent to the NGP 99TDKB extended door shoe from another manufacturer?
The Cal-Royal DS-403 is an aluminum door shoe with a vinyl insert, the same basic build as the NGP 99TDKB: a rigid aluminum extrusion carrying a flexible seal at the door bottom. The 99TDKB uses aluminum alloy 6063 T5 temper with a thermoplastic PVC seal formulated with a bio-based plasticizer, rated 0 F to 140 F, and comes in 36 inch and 48 inch lengths. The Pemko 209 is another door bottom shoe in the same role, carrying an Eco-V vinyl insert on a 1/2 inch x 1-3/8 inch profile. If you are matching what is already on the door, the Pemko 209 profile dimensions are the ones to measure against your existing shoe.
3) The door is exterior and takes driving rain - is a plain door shoe enough?
On a weather-exposed exterior opening, a shoe with an integral rain drip sheds water away from the door bottom rather than letting it run down onto the seal. The Pemko 211V is an L-shaped door shoe with a rain drip and a GREENGUARD Gold certified Eco-V insert; the Pemko 215 pairs a rain drip with a fire rating for exterior openings that are also labeled. The NGP 99TDKB is a straight extended shoe with a moisture-resistant thermoplastic PVC seal and no drip leg, which suits protected exteriors and interior openings - vestibules, corridors, stair doors - where sealing the gap is the job and shedding sheet water is not.
4) Do I need to buy screws separately for the NGP 99TDKB door shoe?
No extra fasteners needed. The 99TDKB ships with #6 x 3/4 inch stainless steel sheet metal screws. Stainless matters on a door bottom, since that is the one piece of hardware that sits in standing water and salt off the sidewalk. End caps are a separate order if you want the finished look on an exposed edge.
5) What is the temperature range on the NGP 99TDKB door shoe seal?
The thermoplastic PVC insert on the 99TDKB is rated 0 F to 140 F. That covers most of the continental US, but it is the number to check if you are gasketing a freezer vestibule, an unheated northern loading dock, or a mechanical room that runs hot. Below 0 F a vinyl fin stiffens and stops sealing against the threshold.
6) What does the NF suffix mean when ordering an NGP 99TDKB door shoe?
NF is notched fins. The standard 99TDKB has continuous soft vinyl fins along the full length; the NF version has the fins notched, which is how you clear a raised threshold feature, a stop, or an astragal that the fin would otherwise ride up on. Specify NF at time of order, it is not something you add later without cutting the insert yourself.
7) How is an NGP 99TDKB door shoe different from a door sweep?
A door shoe wraps the bottom edge of the door, so the aluminum carrier sits on the underside and the vinyl seals down to the threshold. A sweep mounts flat on the face of the door and hangs below the bottom edge. The shoe is the better answer on an exterior opening where you want the bottom edge of the leaf protected as well as sealed, and it is what the 99TDKB is. If the door bottom is already damaged or out of square, a face-mounted sweep is easier to fit.
8) Will the NGP 99TDKB door shoe hold up on an exterior door in a coastal or wet location?
The 99TDKB uses 6063 T5 aluminum with an anodized finish and stainless steel screws, which is the combination that resists corrosion at a door bottom, and the PVC insert is moisture resistant. What it does not have is a rain drip. On a door taking direct wind driven rain with no overhang, a drip profile such as the Pemko 211V L-shaped shoe with rain drip sheds water off the face of the leaf before it reaches the seal.
9) We are standardizing door bottom seals across a portfolio - what separates these door shoes from one another?
All of them mount to the bottom rail of the door as a shoe carrying a replaceable seal, so the sorting is by opening type. The NGP 99TDKB is an extended aluminum shoe with a thermoplastic PVC seal using a bio-based plasticizer, in 36 inch and 48 inch lengths with #6 x 3/4 inch stainless steel SMS fasteners included. The Pemko 209 is defined by its 1/2 inch x 1-3/8 inch profile with an Eco-V vinyl insert. The Pemko 211V adds an L shape and rain drip with a GREENGUARD Gold certified insert for indoor-air-quality specs. The Pemko 210 and Pemko 215 are the fire-rated members of the group, the 215 with UL10C certification and a rain drip. The Cal-Royal DS-403 is an aluminum shoe with a vinyl insert. For a mixed portfolio, buy the rated shoe for labeled openings and one standard shoe for everything else.
10) Our spec calls for a low-emitting certified product - does the NGP 99TDKB door shoe meet that?
For an indoor-air-quality certification callout, the Pemko 211V carries a GREENGUARD Gold certified Eco-V insert, which is the product in this group written to that kind of spec. The NGP 99TDKB takes a different environmental angle: its thermoplastic polymer PVC seal is formulated with a bio-based plasticizer to reduce environmental impact, on a 6063 T5 aluminum base. If the submittal requires a certification mark, specify the Pemko 211V; if the goal is reduced-impact seal material on a standard shoe, the 99TDKB is the direct answer.
11) I need a 48 inch door shoe - which options cover that width?
The NGP 99TDKB extended door shoe is stocked in 36 inch and 48 inch lengths, so it covers wide leaves and oversized commercial openings directly. Among the comparable shoes, the Pemko 210 fire-rated door bottom shoe is specified at 36 inches. For a wide opening on a non-rated door, the 48 inch 99TDKB is the straightforward pick - aluminum 6063 T5 with a PVC seal and #6 x 3/4 inch stainless steel SMS fasteners supplied.
12) Is an L-shaped door shoe the same thing as the NGP 99TDKB?
They are not interchangeable at the door bottom. The Pemko 211V is an L-shaped door shoe, a profile that wraps the bottom edge and carries a rain drip on the face of the door. The NGP 99TDKB is an extended door shoe - a straight aluminum 6063 T5 section with soft vinyl fins in dark brown seating under the door - and it is offered with notched fins under the NF suffix for modified seal configurations. Because the L shape changes what the shoe covers on the door face, measure the existing profile before swapping one style for the other.
13) What color is the vinyl on the NGP 99TDKB door shoe?
Dark brown soft vinyl fins on an anodized aluminum base. That is worth knowing before it goes on a building full of clear or dark bronze aluminum entrances, because the fin is visible at the bottom of the leaf. If you are matching an existing run of shoes across a property, hold one up before committing the whole fleet.
