OATEY 38483 Fire Rated, Single...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$391.43
$341.43
OATEY 38483 Fire Rated, Single Lever, CPVC, Hammer - Washing Machine Outlet Box, Standard Pack

OATEY 38483 Fire Rated, Single Lever, CPVC, Hammer - Washing Machine Outlet Box, Standard Pack

(No reviews yet) Write a Review

Model: 38483

In Stock (leaves warehouse same day if ordered before 3pm ET)

$391.43
$341.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Fire Rated, Single Lever, CPVC, Hammer - Washing Machine Outlet Box, Standard Pack

  • Features

    • Box made of Bulk Molding Compound (BMC) with UL-classified intumescent pads and UL-classified insulating material
    • 2" drain opening fits PVC or ABS Sch. 40 DWV pipe
    • Warnock Hersey certified, for 1-hour and 2-hour fire-rated walls
    • Adjustable metal mounting brackets, easy to remove test cap
    • Flexible valve/drain arrangement capabilities
    • Water Hammer arrestors help absorb the shock and reduce noise from fast open/close valves and ensure code compliance


38483 - spec sheet

Manufacturer Resources

Product Specs

Box Dimensions:
8-1/3"W x 5-1/2"H x 3-3/4"D
Faceplate Dimensions:
10-1/5"W x 7-2/5"H
Volume:
0.416
Department:
Plumbing
Product Group:
Plumbing Boxes
Product Subgroup:
Appliance Outlet Boxes
Product Type:
Washer Outlet Box
Product Finish:
White
Lever Type Details:
Single
Product Material:
Brass
Product Weight:
3

OATEY 38483 – Frequently Asked Questions

1) Can the Oatey 38483 washing machine outlet box be used in a 1-hour or 2-hour fire-rated wall?
Yes. The Oatey 38483 outlet box is Warnock Hersey certified for both 1-hour and 2-hour fire-rated wall assemblies. The box body is Bulk Molding Compound with UL-classified intumescent pads and UL-classified insulating material, which is what maintains the rating where the box penetrates the gypsum. That makes it the right choice for multi-family demising walls and corridor walls where a standard plastic laundry box would break the assembly.
2) Does the Oatey 38483 washer box include water hammer arrestors?
Yes, the 38483 is the hammer-arrestor version. The arrestors absorb the shock from the fast-closing solenoid valves on a washing machine, which cuts the banging in the wall and satisfies the code requirement for arrestors on quick-closing valves. If you are replacing a plain box because tenants keep reporting pipe noise, this is the model that fixes it.
3) What supply piping does the Oatey 38483 washing machine box connect to?
This is the CPVC version, so the supply stubs are made to solvent weld directly to CPVC water lines. If your rough-in is copper or PEX, you want a different connection version of the box rather than adapting at the valve.
4) Is the Oatey 38483 a single-lever or two-valve laundry box?
Single lever. One handle controls both hot and cold, so the tenant shuts off both supplies in one motion instead of forgetting one. The valves are brass. If your standard across a building is two separate quarter-turn handles, this is not a match for that look.
5) How is the Oatey 38483 laundry box secured to the framing?
It uses adjustable metal mounting brackets, so you can set the box depth to the drywall face and shift it within the bay rather than being locked to one stud position. The valve and drain arrangement is flexible too, which helps when the standpipe has to come in from a particular side.
6) What is the Oatey part number for the fire-rated CPVC single-lever washer box with hammer arrestors?
Oatey 38483, UPC 038753384832. That number specifies the whole combination: fire rated BMC box, CPVC connections, single lever valve, and built-in water hammer arrestors. Ordering by the 38483 number is the only way to be sure you get the arrestor and fire-rated version rather than a plain box.
7) What color is the Oatey 38483 washer outlet box faceplate?
White, which is the standard finish for laundry closets and matches the typical painted-wall install. Weight is about 3 pounds, so a single installer can hold it in place while fastening the brackets.
How fast can I get the OATEY 38483 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the OATEY 38483 come with a warranty?
Absolutely. The OATEY 38483 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the OATEY 38483?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
