Pass & Seymour FC52 Flexcor Single-Eye Support Grip, Tinned-Stainless Steel Wire, 0.53-0.73 in. Cable

Pass & Seymour FC52 Flexcor Single-Eye Support Grip, Tinned-Stainless Steel Wire, 0.53-0.73 in. Cable

(No reviews yet) Write a Review

Model: FC52

In Stock (leaves warehouse same day if ordered before 3pm ET)

$90.80
$31.56
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour FC52 Flexcor Single-Eye Support Grip, Tinned-Stainless Steel Wire, 0.53-0.73 in. Cable

The Pass & Seymour FC52 Flexcor Support Grip is a single-eye cable support grip engineered for service and bus drop applications, woven of corrosion-resistant tinned-stainless steel wire to handle cable diameters from 0.53 in. to 0.73 in. Designed to relieve direct tension from a critical electrical connection while absorbing vibration and flexing, the FC52 keeps overhead service and bus drop conductors securely supported in demanding outdoor and industrial environments. Most Flexcor products, including this grip, carry UL and/or CSA approvals, giving installers confidence in code-compliant performance on commercial and industrial jobs.

Key Features

  • Cable Diameter: Accommodates cables from 0.53 in. to 0.73 in. for a secure, properly sized grip fit.
  • Durable Construction: Woven of corrosion-resistant tinned-stainless steel wire for long service life in exposed installations.
  • Single Eye Attachment: Single-eye configuration simplifies mounting to service and bus drop hardware.
  • Bale & Mesh Dimensions: Bale length of 9 in. with a mesh length of 6.5 in. for consistent, even grip coverage along the cable.
  • Tension & Vibration Relief: Relieves direct tension from the critical connection and absorbs vibration and flexing to protect the termination.
  • Factory-Verified Approvals: Most Flexcor products carry UL and/or CSA approvals; contact the factory for specific approval information.

Certifications & Compliance

  • UL Listed
  • CSA Listed

Technical Specifications

  • Country Of Origin: Mexico
  • Product Length: 6.5 in
  • Product Line: Pass & Seymour

Typical Applications

  • Electrical Service Drop Cable Support
  • Bus Drop Cable Support
  • Vibration and Flex Absorption at Critical Connections
  • Outdoor and Overhead Cable Runs
  • Commercial and Industrial Electrical Installations

Why Pass & Seymour?

Pass & Seymour builds the Flexcor FC52 support grip from corrosion-resistant tinned-stainless steel wire and backs it with UL and/or CSA approvals on most Flexcor products, making it a dependable choice for protecting critical service and bus drop connections. By relieving tension and absorbing vibration and flexing, the FC52 helps electrical contractors deliver reliable, code-compliant cable support on both new construction and retrofit projects.

Manufacturer Resources

Spec Sheet

Product Specs

Product Type:
Support Grip
Product Material:
Tinned-Stainless Steel
Configuration:
Single Eye
Listing:
UL Listed
Standards:
UL-CSA
Department:
Electrical
Product Group:
Hangers, Supports & Fasteners
Product Subgroup:
Cable Support Systems
Product Width:
0.73 in
Product Length:
6.5 in

Pass & Seymour FC52 – Frequently Asked Questions

1) What cable diameter does the Pass & Seymour FC52 support grip fit?
The FC52 Flexcor grip is woven to grip cable from 0.53 in. to 0.73 in. outside diameter. Measure the jacket OD of the cord or cable, not the conductor size. If your cable falls outside that window the mesh will not close down evenly on it, and the grip will slip or bunch instead of spreading the load along the jacket, so you need the next size up or down in the Flexcor service and bus drop range.
2) How long is the mesh on the FC52 and why does that matter for the install?
Mesh length is 6.5 in. with a 9 in. bale. The mesh length is the working section that grips the jacket, so you need at least 6.5 in. of clear, straight cable below the attachment point before any bend, connector body, or clamp. The bale is the loop above it that reaches your support hardware, so allow for the full 9 in. when you set the height of your hook or messenger.
3) Is the Pass & Seymour FC52 grip UL listed for use on a commercial job?
UL Listed, and it also carries CSA. The specification data records the standards as UL-CSA, so it can go into installations on either side of the border where the inspector wants a listed support grip on the drop.
4) Can I use the FC52 grip outdoors on an overhead service drop?
Yes. The mesh is woven from tinned-stainless steel wire, which is what makes it suitable for exposed overhead and outdoor runs where a plain steel grip would corrode. Pass & Seymour lists service drop and bus drop cable support as the intended applications, along with outdoor and overhead cable runs on commercial and industrial jobs.
5) What does single eye mean on the FC52, and when would I need a double eye grip instead?
Single eye means the grip terminates in one closed loop at the top for hanging from a hook, clevis, or drop hardware. That is the configuration for a vertical drop, where all the load pulls in one direction, which is exactly what a service or bus drop does. Double eye or split mesh versions exist for supporting cable at a mid-span pull or where the grip has to be installed over an already terminated end. The FC52 is the closed, single eye style, so the cable end has to be fed through before it is terminated.
6) Will a support grip like the FC52 keep strain off my cord cap or connector?
That is the whole point of it. The woven mesh tightens around the jacket as load is applied, so the weight of the drop is carried by the grip and the support hardware instead of by the termination. It also absorbs vibration and flexing at the connection, which is the failure mode on bus drops over machinery. Terminate the cable after the grip is on and the eye is hung, so the connection never sees the hanging load.
7) Where is the Pass & Seymour FC52 made?
Mexico. That is the stated country of origin on the FC52 Flexcor grip, which is the line item a public agency or institutional buyer usually needs for a domestic preference or origin declaration on the submittal.
8) Is the FC52 one part number or do I have to pick options?
One configuration, ordered as FC52. There is no handing, finish, or length choice to specify. The only thing that decides whether it is the right part is your cable OD falling in the 0.53 to 0.73 in. range.
