Pass & Seymour S40 Bus Drop Support Grip, Galvanized Steel

Pass & Seymour S40 Bus Drop Support Grip, Galvanized Steel

(No reviews yet) Write a Review

Model: S40

In Stock (leaves warehouse same day if ordered before 3pm ET)

$78.83
$32.27
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour S40 Bus Drop Support Grip, Galvanized Steel

The Pass & Seymour S40 is a woven galvanized steel wire support grip engineered for service and bus drop cable support. It relieves direct tension from the critical electrical connection while absorbing vibration and flexing that would otherwise stress terminations over time. The S40 is offered with either a single eye or locking bale attachment, giving installers flexibility to match the grip to the hardware and mounting configuration on the job. Built from durable woven galvanized steel wire, this support grip is designed to hold up under the ongoing mechanical loads found in service drop and bus drop applications.

Key Features

  • Durable Construction: Woven galvanized steel wire body resists corrosion while providing the strength needed to support service and bus drop cable runs.
  • Tension Relief: Relieves direct tension from the critical connection point, protecting terminations from pull-out and stress.
  • Vibration Absorption: Absorbs vibration and flexing in the cable run, reducing wear on connections over time.
  • Attachment Options: Available with either a single eye or a locking bale attachment to suit the required mounting hardware.
  • Cable Support Function: Purpose-built as a cable support grip for service drop and bus drop installations.

Technical Specifications

  • Country Of Origin: Mexico
  • Product Length: 8.25 in
  • Product Line: Pass & Seymour
  • Product Width: 0.75 in

Typical Applications

  • Electrical Service Drop Installations
  • Bus Drop Cable Support
  • Overhead Cable Runs Requiring Tension Relief
  • Vibration-Prone Cable and Conductor Runs
  • Utility and Commercial Electrical Distribution

Why Pass & Seymour?

Pass & Seymour builds the S40 support grip from woven galvanized steel wire to stand up to the mechanical demands of service and bus drop cable support, relieving tension and absorbing vibration so critical connections stay protected. With a choice of single eye or locking bale attachment, the S40 gives electrical professionals a reliable, purpose-built solution for supporting cable runs in demanding installations.

Manufacturer Resources

Spec Sheet

Product Specs

Product Material:
Galvanized Steel
Product Type:
Support Grip
Department:
Electrical
Product Group:
Hangers, Supports & Fasteners
Product Subgroup:
Cable Support Systems
Product Width:
0.75 in
Product Length:
8.25 in

Pass & Seymour S40 – Frequently Asked Questions

1) What is the Pass & Seymour S40 support grip used for?
The S40 is a woven wire cable support grip for service drop and bus drop runs. It takes the pulling load off the cable so direct tension never reaches the electrical connection, and it absorbs vibration and flexing in the run so terminations aren't worked loose over time. Typical spots are overhead cable runs and utility or commercial distribution where the conductor is hanging and moving.
2) Does the S40 come with an eye or a bale for attaching to the support hardware?
Both styles exist for the S40: a single eye version and a locking bale version. Pick based on what you're hanging it from. A single eye suits a hook, thimble or shackle already set in the structure; a locking bale is the choice when you need the attachment to close and stay captive on the support point. Decide before you order, since the attachment is part of the grip and can't be swapped after.
3) Is the S40 grip made of steel or mesh weave, and will it hold up outdoors?
Galvanized steel, woven wire construction. The zinc coating is what lets it live on an outdoor service drop without rusting out, and the woven body is what grips the cable jacket and spreads the load along its length instead of pinching one point.
4) What size is the Pass & Seymour S40 bus drop grip?
The S40 measures 8.25 inches long by 0.75 inches wide. That length is the woven mesh body, which is what determines how much of the cable jacket the grip bears on; the narrow width tells you it is sized for a single small-diameter drop cable, not a heavy multi-conductor feeder.
5) Can I use a bus drop grip instead of a strain relief connector at the box?
They do different jobs. A cord grip or strain relief connector seals and clamps the cable where it enters an enclosure. The S40 is a support grip: it hangs on the run itself and carries the weight and movement of the drop so that load never arrives at the connector or the termination. On a bus drop over a machine, you typically want both, the grip up at the support point and a proper fitting at the box.
