Prodatakey R4E Four Door Controller Expansion Board, Ethernet, OSDP, Wiegand, Battery Monitoring, Optional Wireless and PoE++

Prodatakey R4E Four Door Controller Expansion Board, Ethernet, OSDP, Wiegand, Battery Monitoring, Optional Wireless and PoE++

(No reviews yet) Write a Review

Model: R4E

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,112.00
$804.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Prodatakey R4E Four Door Controller Expansion Board, Ethernet, OSDP, Wiegand, Battery Monitoring, Optional Wireless and PoE++

Red 4 controller includes built-in Ethernet connectivity and self-discovery, simplifying IP configuration and functionality. Additional plug-and-play connection options are available by simply purchasing a Red WiMAC wireless or PoE++ module kit. The Red 4 is equipped with OSDP functionality, an onboard power supply, and a fully-supervised power circuit that monitors input, output, battery voltage, and overall controller health.

Features:

  • Advanced Security: Red products lead the industry in secure communication protocols. This includes OSDP, mobile, and encrypted credential communication.
  • Self Discoverable: The red 4 will be automatically discovered by the cloud node when an ethernet cable is connected; it is not necessary to enter the IP address; the device is self-discoverable.
  • Power Monitoring: Equipped with an onboard power supply and a fully-supervised power circuit that monitors input, output, battery voltage, and overall controller health.
  • Module kits: Additional WiMAC and PoE++ plug-and-play connection kits can be added by purchasing the respective wireless or PoE kit. Plug the module into the PDK red 4 board, and it's ready to go.
  • Plug N’Play Connectivity: All PDK red devices were designed to be plug n' play. That means they're easy to install right out of the box. It's simple to add any device, no matter how large the job is.
  • System Scalability: Whether you need two doors or a thousand, the PDK red 4 controller gives you the flexibility to add more doors anytime, anywhere, on any device.



Specifications:

  • Connections:
    • Removable screw-down terminals.
    • Built-in power supply.
    • (4) Industrial-grade 2A form-C relays.
    • (4) Reader
    • (4) Input A
    • (4) Input B
  • Communication Options:
    • Ethernet.
    • WiMAC™ Wireless (2.4 GHz/ 802.15.4).
    • PoE++.
    • Encryption: AES 128bit.
    • Wireless Range: 1 Mile LoS, 450ft indoor average.
  • Environmental:
    • Temperature: - 4° ~ + 140° F /- 20° ~ + 60° C.
    • Humidity: 0 - 95% relative humidity non-condensing
  • Power:
    • 12V-24V DC Input.
    • Board powers readers and other door hardware directly from the bus.
    • Power supplies included with purchase of Red Max Controller
    • 12V 12ah backup battery not included, but must be installed to comply with UL 294.
  • Enclosure: Red Expander Boards can be mounted to any Red enclosure.

Manufacturer Resources

Product Specs

Product Subgroup:
Access Management
Product Group:
Door Controller
Subcategory:
Access Controls
Series:
R4 Series
Product Type:
Hardwired
Product Model:
Door Controller
Product Voltage:
12V-24V DC
Product Size:
7.625" x 10.4375" x 3"
Product Category:
Access Controls
Department:
Door Hardware

Prodatakey R4E – Frequently Asked Questions

1) Will the PDK Red 4 expansion board control four doors on its own, or do I need a main controller too?
The Red 4 (R4E) is an expander board, so it adds four doors to an existing PDK Red system rather than standing alone. Each board carries four form-C 2A relays, four reader ports, and four Input A plus four Input B terminals, all on removable screw-down terminals. It talks back over Ethernet and self-discovers: plug in the network cable and the cloud node finds it without you typing an IP address.
2) Can I run the PDK Red 4 controller wirelessly or over PoE instead of pulling a data line?
Ethernet is built in on the Red 4, and the wireless and PoE++ paths are add-on module kits, not on-board features. Buy the Red WiMAC wireless kit or the PoE++ kit, plug the module onto the board, and it runs. WiMAC is 2.4 GHz on 802.15.4 with about 1 mile line of sight and roughly 450 ft indoors, which is what makes it worth using between buildings on a campus where trenching a line is the alternative.
3) What power supply does the PDK R4E four door board need, and is a battery included?
Input is 12V to 24V DC, and the board has its own onboard power supply that feeds the readers and door hardware straight off the bus, so you are not adding a separate reader supply per opening. A 12V 12ah backup battery is not in the box and has to be installed for the installation to comply with UL 294. Power supplies ship with the Red Max controller, not with an expander board.
4) Does the PDK Red 4 board work with OSDP readers or only Wiegand?
Both. The Red 4 supports OSDP as well as Wiegand on its four reader ports, with AES 128-bit encryption on the communication side. If you are specifying a new install and want encrypted, supervised reader-to-controller wiring instead of legacy Wiegand, this board will take it; if you are cutting over an existing site door by door, the Wiegand readers already in place stay usable while you migrate.
5) Will the 2A relays on the PDK Red 4 drive a maglock or an electric strike directly?
There are four industrial-grade form-C relays rated 2A on the board, and the board feeds door hardware directly from its own bus at 12V to 24V DC. Form-C means you get both normally open and normally closed contacts per door, so fail-safe hardware like a maglock and fail-secure hardware like a strike both wire up without an extra relay module. Check the holding current of the specific lock against the 2A contact rating before you commit the circuit.
6) What enclosure do I need for a PDK Red expander board, and how much room does it take?
Red expander boards mount to any Red enclosure, so you are not matched to one specific can. Plan the space around 7.625 x 10.4375 x 3 inches. Remember the UL 294 battery has to live in that enclosure too, so size the can for the board plus a 12V 12ah battery rather than the board alone.
7) Can a PDK Red 4 controller board go in an unheated garage or parking structure?
Operating range on the Red 4 is -4 to +140 F (-20 to +60 C) at 0 to 95 percent relative humidity, non-condensing. That covers an unconditioned garage, a stair tower, or a mechanical room in most of the country. What it does not cover is condensing conditions, so an exterior wall location where the board sees temperature swings past dew point needs a sealed or conditioned enclosure.
8) How do I know if the backup battery on a PDK access control panel has failed?
The Red 4 runs a fully supervised power circuit that monitors input voltage, output voltage, battery voltage, and overall controller health. For an MRO or facilities team, that is the difference between finding out the battery is dead during a power outage and getting told beforehand. It is also why the 12V 12ah battery is worth installing even outside a UL 294 requirement, the board is watching it.
9) Can I add more doors to a PDK Red system later, or do I have to size it up front?
Adding doors later is the point of the Red 4 board. Each expander adds four openings to the system, mounts in any Red enclosure, and self-discovers on the network when Ethernet is connected, so growth from a two door tenant space to a multi-building campus is a matter of adding boards rather than replacing the head end. For a property manager phasing openings a floor at a time, that means the first purchase does not have to guess the final door count.
10) What is the part number for the PDK four door expansion board?
The Prodatakey R4E four door controller expansion board carries manufacturer part number AHDS30RVFD. It is the R4 Series board with built-in Ethernet, OSDP and Wiegand reader support, battery monitoring, and optional WiMAC wireless or PoE++ modules.
