Schlage Electronic 9691T Proximity and MIFARE Classic Smart Card Combo Thin Keyfob — gray teardrop-shaped keyfob with Schlage logo and model number embossed

Schlage Electronics 9691T MIFARE Classic + Proximity Dual-Technology Thin Keyfob, 1K Byte

(No reviews yet) Write a Review

Model: 9691T37H

In Stock (leaves warehouse same day if ordered before 3pm ET)

$247.66
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schlage 9691T MIFARE Classic + Proximity Dual-Technology Keyfob

The Schlage 9691T (formerly aptiQ 9691T) is a multi-technology keyfob that combines standard 125 kHz proximity with 13.56 MHz MIFARE Classic smart card technology. Encrypted data is mutually authenticated in communication between the credential and reader, delivering high-security access control in a single thin ISO keyfob form factor.

Ordering Note

When ordering MIFARE/proximity multi-technology credentials, you must provide the facility code (excluding 32-Bit and 37-Bit formats) and a unique start serial number (excluding 35-Bit format) to be programmed for both the proximity and smart card formats.

Technical Specifications

  • Memory: 1K byte (8K bit)
  • MIFARE Bit Format Options: 26-Bit, 32-Bit, 34-Bit, 35-Bit, 36-Bit, 37-Bit, 40-Bit, 48-Bit
  • MIFARE Facility Code Range: 0-255 (26-Bit); other bit formats vary
  • MIFARE Number Range: 0-65,435 (26-Bit); other bit formats vary
  • Proximity Bit Format Options: 26-Bit, 32-Bit, 34-Bit, 35-Bit, 36-Bit, 37-Bit
  • Proximity Facility Code Range: 0-255 (26-Bit); other bit formats vary
  • Proximity Number Range: 0-65,435 (26-Bit); other bit formats vary
  • Form Factor: ISO thin keyfob
  • HF Frequency: 13.56 MHz (MIFARE Classic)
  • LF Frequency: 125 kHz (Proximity)
  • Package Quantity: 25 keyfobs per pack

Manufacturer Resources

Product Specs

Product Group:
Electronic Access Control
Product Subgroup:
Credentials
Product Type:
Keyfobs
Subcategory:
Parts and Accessories
Parts and Accessories Type:
Credentials
Product Attribute:
Parts and Accessories
Product Category:
Electronic Access Control
Department:
Door Hardware
Package Quantity:
25

Schlage Electronics 9691T37H – Frequently Asked Questions

1) What information do I need to give when ordering Schlage 9691T keyfobs?
Two things get programmed at the factory, so you have to supply them up front: the facility code (not required for 32-Bit or 37-Bit formats) and a unique start serial number (not required for 35-Bit format). Both the proximity side and the MIFARE side are encoded to what you specify, so if your existing badges use facility code 100 on 26-Bit, the fobs need to be ordered that way. There is no field programming step that fixes it later.
2) Will a Schlage 9691T fob work on my old 125 kHz proximity readers and new smart card readers at the same time?
That's exactly what the 9691T is for. It carries 125 kHz proximity and 13.56 MHz MIFARE Classic in one fob, so a single credential opens doors on legacy prox readers and on smart card readers. That makes it the credential you hand out during a phased reader migration, where some openings have been converted and some haven't, without issuing staff two fobs. Both technologies have to be encoded to formats your panels already read.
3) What bit formats can the Schlage 9691T dual-technology keyfob be encoded in?
The MIFARE side supports 26-Bit, 32-Bit, 34-Bit, 35-Bit, 36-Bit, 37-Bit, 40-Bit and 48-Bit. The proximity side is a shorter list: 26-Bit, 32-Bit, 34-Bit, 35-Bit, 36-Bit and 37-Bit. So if your access control system runs a 40-Bit or 48-Bit card format, that can only live on the smart card side of the fob, and the prox side has to be encoded in one of the six formats above. Match both to what your panel is programmed to accept before you order.
4) What facility codes are available on the Schlage 9691T keyfob?
Preconfigured options cover 26A format with facility code 100, 102 or 235, a 37-Bit format fob with no facility code (model 9691T37H), and 37X format with facility code 100. On 26-Bit, the facility code range runs 0 to 255 and the card number range 0 to 65,435, on both the proximity and MIFARE sides. Other bit formats use different ranges. The 37-Bit option carries no facility code at all, which is normal for that format.
5) How many Schlage 9691T keyfobs come in a pack?
They ship 25 to a pack, and the whole pack is encoded to the facility code and serial range you specify. That's worth knowing when you're sizing an order for a building: a 60-tenant property needs three packs, and the third pack's serial numbers continue the sequence you set. Ordering additional packs later under the same facility code keeps everyone on one credential scheme.
6) Is the Schlage 9691T the same as the aptiQ 9691T?
Same credential, renamed. The 9691T was sold as aptiQ 9691T before Schlage consolidated the branding, so a spec written years ago calling for an aptiQ 9691T is asking for this fob. Useful when you're matching an existing badge population and the paperwork still says aptiQ.
7) How secure is a MIFARE smart card fob compared to a plain proximity card?
On the 13.56 MHz MIFARE Classic side, data is encrypted and the fob and reader mutually authenticate each other before the credential is passed. The 125 kHz proximity side works the way ordinary prox always has, so a facility that keeps the prox side live keeps that exposure until the last legacy reader is swapped. That's the argument for treating the 9691T as a transition credential and finishing the reader upgrade rather than living on it permanently.
8) Is the 9691T a card or a fob, and will it go on a keyring?
It's a keyfob, not a card, built in an ISO thin form factor so it stays slim on a ring alongside keys. If your population needs a photo ID badge that clips to a lanyard and prints, a fob is the wrong choice and you want a card credential instead. Fobs suit maintenance staff, contractors and tenants who carry keys anyway and don't need a printed badge face.
9) How much memory does the 9691T MIFARE Classic keyfob have, and does that matter for me?
1K byte, which is 8K bit, of MIFARE Classic memory. For straight door access that's more than you need, one sector holds the credential data. It matters if you're planning to use the same fob for a second application on the smart card side, like cashless vending or a library or lab system, where each application claims sectors of its own. If the plan is access control only, the capacity is not a deciding factor.
