Name: Securitron R100 Surface Mounted Wireless Card Reader
Brand: Securitron
SKU: R100H-IPS-B
Price: 661.96 USD
Availability: InStock

Product Overview
FAQs

Securitron R100 Surface Mounted Wireless Card Reader

The R100 surface mounted wireless card reader offers a cost effective, aesthetically pleasing way to extend access control to glass, metal or stone surfaces without the need for cutting or drilling.A retrofit solution capable of being installed in minutes that compliments virtually any ASSA ABLOY electrified locking device. Provides flexible, robust retrofit options for entryways unlike any the industry has seen before.

FEATURES & BENEFITS

Product Features

Shortened wire pull from panel to hub provides cost benefit to installation
Online transaction audit trail capabilities
Low battery signaling and reporting
Green status LED indicator
Fully-encrypted AES 128 wireless communication
Adheres to glass surface without any connecting wires

SPECIFICATIONS

Card Technology

Card Technology (125 kHz): HID Prox®|AWID Prox|EM4102|ioProx
Card Technology (13.56 MHz): HID iCLASS®|HID iCLASS SE® (SIO®-enabled)|HID iCLASS® Seos®|HID MIFARE® SE|HID DESFire® EV1 SE|MIFARE CLASSIC|DESFire® EV1
Communication Technology: WIRELESS - Aperio
Credential Type: Card | Mobile

Electrical

Power Source: Battery Operated
Battery Backup: microUSB
Batteries Required: Yes
Batteries Included: Yes
Battery Cycles: 50000

Environmental

Maximum Operating Temperature (��F): 140
Maximum Operating Temperature (��F): 14

Dimensions

Depth (in.): 2.16
Height (in.): 4.5
Width (in.): 3.5

Shipping Weight

13.1 lbs [5.9 kg]

CERTIFICATIONS

HES K100 KS100 R100 Cabinet Lock CE Notified Body Certification
HES K100 KS100 R100 Cabinet Lock IC Certification
HES K100 KS100 R100 CabinetLock FCC-R100 Grant DXX Certification
HES K100 KS100 R100 Cabinet Lock FCC-R100 Grant Certification
ESH HES R100 Aperio WirelessAccess CE DoC Certification
ESH HES R100 Aperio WirelessAccess Anatel Certificate of Conformity
ESH HES R100 Aperio Wireless Access Anatel Certification
ESH HES R100 Aperio Hubs Wireless Access Anatel Certification
Securitron R100 Aperio Wireless Access Controls Certification

DOWNLOAD & RESOURCES

Manufacturer Resources

Product Specs

Series:: RH100 Series
Subcategory:: Surface Mounted Reader
Warranty:: 3 Year Limited
Product Group:: Electronic Access Controls
Product Subgroup:: Readers, Keypads and Credentials
Product Type:: Readers
Commercial/Residential:: Commercial
Electronic:: Yes
Product Model:: SEC-RH100
Product Category:: Electronic Access Controls
Department:: Door Hardware

Securitron R100H-IPS-B – Frequently Asked Questions

1) Can the Securitron R100 reader be mounted on a glass door without drilling?

That is what the R100 is built for. It adheres to glass, metal or stone surfaces with no cutting or drilling and no connecting wires running to it, because the reader is battery operated and talks to the hub over wireless. For a glass front installer that means no hole in the glass and no wire route through the door, which is the usual reason a card reader cannot go on a storefront entrance in the first place.

2) What is the difference between the R100 Not Factory Paired and the version factory paired with an AH20 Wiegand hub?

Two ordering choices on the R100. Factory Paired with AH20 - Wiegand Hub ships already associated with its hub, so the reader and hub arrive as a working wireless pair and you skip the pairing step on site. Not Factory Paired ships as the reader alone, which is what you want if you already have Aperio hubs in the building or you are pairing to a hub you are buying separately. If this is your first R100 on the job, take the factory paired option.

3) Will the Securitron R100 wireless reader work with my existing access control panel?

The R100 reaches your panel through an Aperio hub, not directly. The AH20 hub is a Wiegand hub, so the panel side of the connection is standard Wiegand wiring from the hub to your access control panel. The wire pull is only from the panel to the hub, and the hub to reader link is wireless with AES 128 encryption. So if your panel takes Wiegand reader inputs, the R100 drops onto it.

4) What card credentials does the Securitron R100 read, and does it handle phone credentials?

Both frequencies and mobile. At 125 kHz it reads HID Prox, AWID Prox, EM4102 and ioProx. At 13.56 MHz it reads HID iCLASS, HID iCLASS SE (SIO-enabled), HID iCLASS Seos, HID MIFARE SE, HID DESFire EV1 SE, MIFARE CLASSIC and DESFire EV1. Credential type is listed as card and mobile, so the phone-based credentials your other openings use will present to this reader too. That multi-technology span is the reason it retrofits into an existing card population without reissuing badges.

5) Should I use a wireless surface reader like the R100 or a hardwired wall mount reader?

It comes down to whether you can get wire to the reader side. A hardwired wall mount reader, such as the Schlage Electronics MTK15 multi-technology reader with keypad, needs a wire path from the panel to the reader location, which means conduit, a wall cavity, or drilling. Choose that when you are in new construction or a stud wall and you want no batteries in the field. The R100 is the retrofit answer: the only wire pull is panel to hub, the reader itself has no wires, and it sticks to glass, metal or stone. If your opening is an aluminium and glass storefront where nobody will let you cut the glass, the wireless reader is the only one of the two that installs.

6) Does the Securitron R100 have a keypad for PIN entry?

No. The R100 is a card and mobile credential reader, with a green status LED for feedback and nothing to key a code into. If the site needs PIN entry, or card plus PIN for a higher security door, look at a reader with a keypad instead: the Schlage Electronics MTK15 and the single-gang mount MTKB15 are both multi-technology readers with keypads that accept PIN credentials. Those are hardwired wall mount units, so you trade the no-drill glass mounting for the keypad.

7) Will the R100 reader work with the electric locks I already have on the door?

The R100 is stated to complement virtually any ASSA ABLOY electrified locking device, which is the family that includes Securitron and HES hardware. It does not release the lock itself: the reader sends the credential over the wireless link to the Aperio hub, the hub reports to your access control panel over Wiegand, and the panel drives whatever strike, mag lock or electrified exit device is on the opening. So the existing lock keeps doing the locking, and you are adding the credential reader in front of it.

8) What reader should I use instead of the Securitron R100 when the opening needs a PIN code as well as a card?

The R100 is a card and mobile credential reader only, so an opening that requires a PIN needs a keypad reader. The Schlage Electronics MTK15 is a networked multi-technology reader with keypad that accepts PIN credentials along with 125 kHz proximity cards, and the MTKB15 is a mobile-enabled multi-technology reader with keypad in black. Both are reader-with-keypad devices where the R100 is a surface mounted reader.

9) I have a glass storefront with no way to run wire to the reader location. Is a Schlage MTK15 an alternative?

No. The MTK15 is a wall mount reader and the MTKB15 mounts to a single-gang box, both of which assume a mounting point and wiring at the reader. The Securitron R100 adheres to a glass, metal or stone surface without any connecting wires and communicates over fully-encrypted AES 128 Aperio wireless, which is what makes it work on a glass front where cutting or drilling is not an option.

10) My access panel uses RS-485 to the reader. Does the Securitron R100 connect that way?

No. The R100 communicates by Aperio wireless to a hub rather than by a direct serial run, and it can be ordered factory paired with an AH20 Wiegand hub or not factory paired. For a panel expecting a serial reader connection, the Schlage Electronics MTK15 is offered in an RS-485 capable version as part number MTK15-485.

11) How much wall or glass space do I need for a surface mounted R100 reader?

Plan on a footprint of 4.5 inches high by 3.5 inches wide, with 2.16 inches of depth standing off the surface. Because it surface mounts, that depth is what projects into the doorway, so check it against door swing, sidelight mullions and any push bar or pull that sits nearby on a glass front.

12) How long do the batteries last in a Securitron R100 and how will I know when they are low?

The R100 is rated at 50,000 battery cycles, and batteries are included with it. It signals and reports low battery, so the condition comes back through the system rather than waiting for someone to be locked out at the door. There is also a microUSB battery backup connection, which is how you keep the reader alive while you swap cells. For a property manager running several of these, the low battery reporting plus the online transaction audit trail is what makes a battery powered reader maintainable across a fleet of doors.

13) Can I mount an R100 card reader outside on an exterior entrance?

Operating range runs from 14 to 140 degrees F. That covers a vestibule, a covered entry or a conditioned interior opening in most of the country, but a fully exposed exterior door in a climate that drops below 14 F in winter is outside the stated range. Check your low winter temperature at the mounting point before committing it to an unprotected outdoor face.

14) Is the R100 secure enough for a commercial building, or is the wireless link a weak point?

The reader to hub link is fully encrypted AES 128 wireless, which is what keeps the credential off the air in the clear. It is a commercial rated device, and it carries FCC, IC, CE and Anatel certifications for the radio as R100 Aperio wireless access. It also keeps an online transaction audit trail, so entries are logged back through the system rather than sitting locally in the reader.

15) How long does it take to install a Securitron R100 on an existing door?

Minutes, because there is nothing to machine. The reader adheres to the glass, metal or stone surface and needs no connecting wires, so the labour is mounting the reader, siting the hub, and running the panel-to-hub wire. Compare that against a hardwired reader, where the wire path to the reader location is the whole job. For a retrofit across a run of existing entrances, the saved wire pull is where the install cost drops.
